Charbroil 463320110 Grill Parts

Charbroil logo



Charbroil 463320110

Char-Broil LP gas outdoor BBQ grill with side burner



Highest quality replacement parts for your Charbroil 463320110 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463320110 owners manual and diagrams
Click the small images on the right to view Charbroil 463320110 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Charbroil 463320110-463554988930-PartsExpS1.jpg

Replacement grill parts for the Charbroil model: 463320110
This page shows all of the parts we know fit model Charbroil 463320110. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 463320110 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463320110 Burners

G431-0300-W2 / NGKT1
Click for photos
Stainless steel burner for Charbroil model 463320110.

Part Number: NGKT1 (Replaces Charbroil G431-0300-W2)
Dimensions: 14 7/8” x 1”
Material: stainless steel
Weight: 1.0

$33.61

Qty


==> All Charbroil Burners.






463320110 Burner Brackets and Carryovers

G413-0004-W2 / CBCO1
Click for photos
Stainless steel cross over tube. Channels gas between burners.

Part Number: CBCO1 (Replaces Charbroil G413-0004-W2)
Dimensions: 7
Material: stainless steel
Weight: 0.05

$15.90

Qty


==> All Charbroil Burner Brackets and Carryovers.






463320110 Cooking Grids

CG-74P-CI-X3
Click for photos
Cast iron cooking grids for Charbroil model 463320110. SET OF THREE (3) panels.
  • Porcelain treated, matte finish
  • Each panel measures 16 7/8” x 8 1/4”
  • Overall dimensions: 16 7/8 x 23 3/4”


Part Number: CG-74P-CI-X3
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 24 3/4”
Material: cast iron
Weight: 26.7

$113.22

Qty


CLA52932S
Click for photos
Heavy duty stainless steel cooking grid for Charbroil model 463320110.
  • 304 commercial grade stainless
  • Solid 5/16” stainless rods
  • Sold individually
  • Made in USA.


Part Number: CLA52932S
Dimension Front-to-Back: 16 5/8”
Dimension Side-to-Side: 12 1/4”
Material: solid 304 stainless steel rod
Weight: 6.4

$54.77

Qty


52932
Click for photos
Porcelain steel cooking grids for Charbroil model 463320110. Porcelain enameled, glossy finish. Sold as a set of two (2).

Part Number: 52932
Dimension Front-to-Back: 16 5/8”
Dimension Side-to-Side: 24 1/2”
Material: porcelain steel wire
Weight: 12.11

$100.62

Qty


66124-1PC
Click for photos
Cast iron cooking grid for Charbroil model 463320110. Porcelain treated, matte finish. Sold individually, number required varies.

Part Number: 66124-1PC
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 8 5/16”
Material: cast iron
Weight: 3.75

$26.77

Qty


CG-74P-CI
Click for photos
Cast iron cooking grid for Charbroil model 463320110. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.

Part Number: CG-74P-CI
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 8 1/4”
Material: cast iron
Weight: 8.90

$43.61

Qty


10225-T536
Click for photos
cast iron cooking grid, SOLD INDIVIDUALLY for Charbroil model 463320110.
  • Sold individually.
  • Number required varies.
  • Porcelain enameled cast iron, flat matte finish.


Part Number: 10225-T536
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 8 1/4”
Material: Cast iron
Weight: 7.6

$56.56

Qty


==> All Charbroil Cooking Grids.






463320110 Heat Plates

G430-0005-W1 / CBHP6
Click for photos
Stainless steel vented heat plate/Flame Tamer for Charbroil model 463320110.

Part Number: CBHP6 (Replaces Charbroil G430-0005-W1)
Dimension Front-to-Back: 14 5/8”
Dimension Side-to-Side: 4 1/4”
Material: stainless steel
Weight: 0.7

$23.47

Qty


==> All Charbroil Heat Plates.






463320110 Igniter Components

IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.10

Qty


G501-0010-W2 / 04430
Click for photos
Burner mounted electrode for use with 15591 and 15491 burners.
  • 39” wire with female spade connector
  • Includes adapter wire part 03198 for applications needing male spade connector on electrode.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 04430 (Replaces Charbroil G501-0010-W2)
Material: ceramic
Weight: 0.1

$12.47

Qty


G409-0021-W1 / 03342
Click for photos
Small AA battery powered push button spark generator.
  • 1.5 volt
  • Has two (2) terminals (male spade connector)
  • Uses a single AA battery (not included)
  • 03610 and 03620 wires are commonly used with this igniter (not included)
  • Requires 7/8” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03342 (Replaces Charbroil G409-0021-W1)
Weight: 0.3

$31.50

Qty


==> All Charbroil Igniter Components.






463320110 Heat indicators and Meat Thermometers

G431-0020-W2 / 00018
Click for photos
Round heat indicator.
  • Single probe
  • 1 13/16” diameter
  • Requires 3/8” mounting hole


Part Number: 00018 (Replaces Charbroil G431-0020-W2)
Dimensions: 1 13/16” x 1 13/16”
Weight: 0.1

$15.11

Qty


==> All Charbroil Heat indicators and Meat Thermometers.






463320110 Accessories

SF-1
Click for photos
Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

$15.90

Qty


00030
Click for photos
EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

$7.60

Qty


WB-7
Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

$5.96

Qty


==> All 463320110 Accessories.
