Charbroil Red Infrared 463250510 Grill Parts

Main burner assembly for Charbroil model 463250510. Stainless steel.


Part Number: 19551 (Replaces Charbroil G517-0500-W1)
Dimensions: 8 1/8” x 3”
Material: stainless steel
Weight: 0.7

Cast iron cooking grids for Charbroil model 463250510. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8” x 8 1/4”
• Overall dimensions: 16 7/8 x 23 3/4”

Part Number: CG-74P-CI-X3
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 24 3/4”
Material: cast iron
Weight: 26.7

Premium quality heavy duty stainless steel cooking grid for Charbroil model 463250510. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it. Just look at the weight of one of these grids, over 7 pounds of solid stainless each.

• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods
• Dimensions: 17” x 12 5/8”
• Made in USA.
• Sold individually.

Part Number: CLA-GS0114
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 12 5/8”
Material: stainless steel
Weight: 7.2

Cast iron cooking grid for Charbroil model 463250510. Porcelain treated, matte finish. Sold individually, number required varies.

Part Number: 66124-1PC
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 8 5/16”
Material: cast iron
Weight: 3.75

Cast iron cooking grid for Charbroil model 463250510. Porcelain enameled, glossy finish. Sold individually.

Part Number: 66162-1PC
Dimension Front-to-Back: 17 1/8”
Dimension Side-to-Side: 12 7/16”
Material: gloss cast iron
Weight: 5.1

Cast iron cooking grid for Charbroil model 463250510. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.

Part Number: CG-74P-CI
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 8 1/4”
Material: cast iron
Weight: 8.90

cast iron cooking grid, SOLD INDIVIDUALLY for Charbroil model 463250510.

• Sold individually.
• Number required varies.
• Porcelain enameled cast iron, flat matte finish.

Part Number: 10225-T536
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 8 1/4”
Material: Cast iron
Weight: 7.6

Cast iron cooking grids for Charbroil model 463250510. SET OF TWO (2) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8” x 8 1/4”
• Overall dimensions: 16 7/8 x 16 1/2”

Part Number: CG-74P-CI-X2 (Replaces Charbroil G517-0014-W1)
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 16 1/2”
Material: cast iron
Weight: 17.9

Stainless steel Trough for Charbroil model 463250510. Sold individually.

Part Number: 99551 (Replaces Charbroil G517-0800-W1)
Dimension Front-to-Back: 17 1/4”
Dimension Side-to-Side: 25 3/4”
Material: stainless steel
Weight: 10.0

electrode

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 09551 (Replaces Charbroil G511-0005-W1)
Material: ceramic
Weight: 0.1

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.

• 1.5 volt
• Has four(4) spark outlets (male spade connector)
• Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03344 (Replaces Charbroil G511-0055-W1)
Dimensions: 2” x 2 1/2”
Weight: 0.5

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152 (Replaces Charbroil G515-0017-W1A)
Dimensions: 17 3/4” x 1”
Weight: 0.1

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Aluminum foil grilling trays. Package of three.

• Heavy duty aluminum foil
• Re-usable
• Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

Stainless steel straight handle grill brush with replaceable head. Brass bristles and scarper. See part# WB-8RH for replacement grill brush heads. 18 1/2” long.
This part is currently out of stock, but more are already on the way and expected to arrive SPRING 23

Part Number: WB-8
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.8
