Backyard Grill GBC1406W-C Grill Parts

stainless steel burner for Backyard Grill model GBC1406W-C.

Part Number: 19941 (Replaces Backyard Grill 55-23-152)
Dimensions: 15 3/8” x 1”
Material: stainless steel
Weight: 1.0

Stamped porcelain steel cooking grids; set of two for Backyard Grill model GBC1406W-C.

Part Number: 51352 (Replaces Backyard Grill 55-24-045)
Dimension Front-to-Back: 15 3/4”
Dimension Side-to-Side: 21”
Material: stamped porcelain steel
Weight: 5.0

Uniflame Heat Plate for Backyard Grill model GBC1406W-C.

Part Number: UFHP4 (Replaces Backyard Grill 55-10-045)
Dimension Front-to-Back: 14 3/16”
Dimension Side-to-Side: 3 13/16”
Material: stainless steel
Weight: 0.60

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

Universal premium quality stainless steel warming rack. You simply can't buy a better quality warming rack than this, which weighs in at almost 5lbs of solid 304 grade stainless steel. This super heavy-duty warming rack was made to replace the porcelain coated steel racks found on BBQ grills made by The Great Outdoors Grill Company, but can be used in many other different grills.

• Far superior to the original porcelain coated steel rack
• Rests on your existing cooking grids.
• Solid 1/4” 304 stainless steel rods.
• Stands 3.75 inches tall.
• Made in USA.

WARNING: Before ordering this universal rack, please verify your grill has enough space to accommodate it. If you need to return, you will be responsible for return shipping, and the original out bound shipping fee will be deducted from the refund. What's required?

• Your grill needs to be at least 24” wide on the inside . The warming rack is 6.25” front to back and stands 3.75” tall.
• Notice the shape of the warming rack. Determine if the lid of your grill can easily close with the warming rack inside along with food placed on top of the rack.

  Part Number: CLA-WS0040
  Dimensions: 6 1/4” x 22 7/8”
  Material: stainless steel
  Weight: 4.8

Oval lid heat indicator. Mounts to grill with single 1.25” long threaded temperature probe in center.

Part Number: 072-6800-0 (Replaces Backyard Grill 55-24-043)
Dimensions: 2 15/16” x 1 7/8”
Material: stainless steel
Weight: 0.2

Wundersmoke Maple Chips. These unique maple wood smoking chips add distinctive maple wood flavoring to your food. For use will all grills. One 1lb bag. Comes with reusable puck.

Part Number: BP-7
Weight: 1.0

15” Stainless steel tong.

• Soft comfort grip
• Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14

Bamboo Appetizer 7” Skewers - pack of eight. Limited to supplies on hand.


Part Number: 11040
Dimensions: 7
Weight: 0.4

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Vertical.Chicken Leg and Wing Rack. Stainless steel.

A convenient stainless wire wing rack, the best way to roast chicken wings and legs on the grill without the hassle of flipping, turning or sticking. For wings and drumsticks.

Part Number: CLWR
Material: stainless steel
Weight: 1.0

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59
