Backyard Grill GBC1461W Grill Parts

Backyard Grill 5-Burner Gas Grill, Stainless Steel, Walmart# 552842986

Highest quality replacement parts for your Backyard Grill GBC1461W - Free USA shipping $49 or more* - No Sales Tax*

Backyard Grill GBC1461W owners manual and diagrams

Click the small images on the right to view Backyard Grill GBC1461W exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Backyard Grill GBC1461W-4E658638831-PartsExpS1.gif

Replacement grill parts for the Backyard Grill model: GBC1461W

All of the parts we have for Backyard Grill GBC1461W are shown on this page. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Backyard Grill grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Backyard Grill GBC1461W BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Backyard Grill model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

GBC1461W Burners

Stainless steel burner for Backyard Grill model GBC1461W.

Part Number: 19981 (Replaces Backyard Grill 55-23-014)
Dimensions: 17 7/16” x 1”
Material: stainless steel
Weight: 0.6

==> All Backyard Grill Burners.

GBC1461W Cooking Grids

Click for photos

Cast iron cooking grids for Backyard Grill model GBC1461W. Porcelain enameled, glossy finish. Sold as a set of three (3).

Part Number: 61593 (Replaces Backyard Grill 55-23-327)
Dimension Front-to-Back: 16 1/4”
Dimension Side-to-Side: 29 5/8”
Material: gloss cast iron
Weight: 11.3

==> All Backyard Grill Cooking Grids.

GBC1461W Heat Plates

Click for photos

UniFlame Grills Stainless Steel Heat Plate for Backyard Grill model GBC1461W.

Part Number: UFHP2 (Replaces Backyard Grill 55-10-156)
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 1.0

==> All Backyard Grill Heat Plates.

GBC1461W Igniter Components

Click for photos

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

==> All Backyard Grill Igniter Components.

GBC1461W Grease Trays

Click for photos

Stainless steel grease tray; has drip hole and includes grease cup and grease cup holder. Made in USA.

Part Number: CLA-DS0248 (Replaces Backyard Grill 55-11-017)
Dimensions: 15” x 28 9/16”
Material: stainless steel
Weight: 4.5

==> All Backyard Grill Grease Trays.

GBC1461W Warming Racks

Click for photos

Universal premium quality stainless steel warming rack. You simply can't buy a better quality warming rack than this, which weighs in at almost 5lbs of solid 304 grade stainless steel. This super heavy-duty warming rack was made to replace the porcelain coated steel racks found on BBQ grills made by The Great Outdoors Grill Company, but can be used in many other different grills.

Far superior to the original porcelain coated steel rack
Rests on your existing cooking grids.
Solid 1/4” 304 stainless steel rods.
Stands 3.75 inches tall.
Made in USA.

WARNING: Before ordering this universal rack, please verify your grill has enough space to accommodate it. If you need to return, you will be responsible for return shipping, and the original out bound shipping fee will be deducted from the refund. What's required?

Your grill needs to be at least 24” wide on the inside . The warming rack is 6.25” front to back and stands 3.75” tall.
Notice the shape of the warming rack. Determine if the lid of your grill can easily close with the warming rack inside along with food placed on top of the rack.

Part Number: CLA-WS0040
Dimensions: 6 1/4” x 22 7/8”
Material: stainless steel
Weight: 4.8

==> All Backyard Grill Warming Racks.

GBC1461W Heat indicators and Meat Thermometers

Click for photos

Oval lid heat indicator. Mounts to grill with single 1.25” long threaded temperature probe in center.

Part Number: 072-6800-0 (Replaces Backyard Grill 55-24-431)
Dimensions: 2 15/16” x 1 7/8”
Material: stainless steel
Weight: 0.2

==> All Backyard Grill Heat indicators and Meat Thermometers.

GBC1461W Accessories

Click for photos

16” Stainless Steel Tong/Turner Combination. 16” multi-use tool with red soft grip rubber inserts. Can be used as a turner, tong or both. Manual lock saves on storage space.

Part Number: 40240
Material: chrome steel
Weight: 0.9

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Click for photos

Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2

==> All GBC1461W Accessories.
