Sonoma SGR27LP Grill Parts

Sonoma 27" Platinum Edition gas grill

Highest quality replacement parts for your Sonoma SGR27LP - Free USA shipping $49 or more* - No Sales Tax*

Sonoma SGR27LP owners manual and diagrams

Diagrams & owners manual not available for grill model# SGR27LP. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts for the Sonoma model: SGR27LP

All of the parts we have for Sonoma SGR27LP are shown on this page. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Sonoma grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Sonoma SGR27LP BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Sonoma model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

SGR27LP Burners

Click for photos

Stainless steel triple burner set for Sonoma model SGR27LP.

Part Number: SONT3
Dimensions: 17 13/16” x 18 1/2”
Material: stainless steel
Weight: 1.6

==> All Sonoma Burners.

SGR27LP Burner Brackets and Carryovers

Click for photos

Stainless steel Z-Bar burner support bracket. Made in USA

Part Number: CLA-MS0116
Dimensions: 2” x 23”
Material: stainless steel
Weight: 0.70

==> All Sonoma Burner Brackets and Carryovers.

SGR27LP Cooking Grids

Cooking grid not known for Sonoma model SGR27LP. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Sonoma cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0

==> All Sonoma Cooking Grids.

SGR27LP Heat Plates

Click for photos

Bottom Flavor Grid for Sonoma model SGR27LP. Stainless steel. Made in USA.
This part is currently out of stock, but more are already on the way and expected to arrive early Sept

Part Number: CLA-MS0181
Dimension Front-to-Back: 12”
Dimension Side-to-Side: 5 7/16”
Material: stainless steel
Weight: 0.70

Click for photos

Stainless steel Flavor Grid for Sonoma model SGR27LP.

Part Number: SONHP1
Dimension Front-to-Back: 15 3/16”
Dimension Side-to-Side: 5 7/16”
Material: stainless steel
Weight: 0.6

==> All Sonoma Heat Plates.

SGR27LP Igniter Components

Click for photos

21” wire for side burner or other applications. Both ends are female spade connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

This part is currently out of stock, but more are already on the way and expected to arrive mid August

Part Number: 10342-T12
Dimensions: 21
Weight: 0.05

Click for photos

Ceramic electrode with mounting bracket. For use with triple burner assembly part# SONT3 and ALTT3.

Sold individually, two (2) required
Use old screws and support plate

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-25B
Weight: 0.3

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

==> All Sonoma Igniter Components.

SGR27LP Miscellaneous Repair Parts

Click for photos

Electrode heat shield. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-MS0085
Dimensions: 16 13/16
Material: stainless steel
Weight: 0.4

==> All Sonoma Miscellaneous Repair Parts.

SGR27LP Accessories

Click for photos

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

==> All SGR27LP Accessories.
