Fiesta Optima ESD45055-BC305 Grill Parts

Fiesta ESD45055-BC305

Fiesta Optima Series Twin-Burner LP gas grill with side burner

Highest quality replacement parts for your Fiesta Optima ESD45055-BC305 - Free USA shipping $49 or more* - No Sales Tax*

Fiesta ESD45055-BC305 owners manual and diagrams

Click the small images on the right to view Fiesta ESD45055-BC305 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Fiesta ESD45055-BC305-34944465594846-PartsExpS1.gif

Fiesta ESD45055-BC305-34944465594846-PartsExpS2.gif

Fiesta ESD45055-BC305-34944465594846-PartsLstS1.gif

Fiesta ESD45055-BC305-34944465594846-PartsLstS2.gif

Replacement grill parts for Fiesta Optima (ESD45055-BC305)

All of the parts we have for Fiesta ESD45055-BC305 are shown on this page. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Fiesta grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Fiesta ESD45055-BC305 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Fiesta model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

ESD45055-BC305 Burners

19202-79402

Click for photos

Stainless steel burner and venturi assembly kit for Fiesta model ESD45055-BC305. Comes with all necessary gaskets and screws.

Part Number: 19202-79402
Dimensions: 22” x 7 7/8”
Material: stainless steel
Weight: 3.5

19202

Click for photos

Stainless steel H burner for Fiesta model ESD45055-BC305. Burner consists of two pieces, which are held together by the venturi.

Part Number: 19202
Dimensions: 22” x 7 7/8”
Material: stainless steel
Weight: 2.4

==> All Fiesta Burners.

ESD45055-BC305 Venturis

SG-B

Click for photos

Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

79402

Click for photos

L-shaped venturi pair. Includes all necessary gaskets and screws/nuts.

Part Number: 79402
Dimensions: 5 1/2” x 3 1/8”
Material: zinc plated steel
Weight: 0.9

==> All Fiesta Venturis.

ESD45055-BC305 Cooking Grids

SP102A-3 / 58211

Click for photos

Porcelain steel cooking grid for Fiesta model ESD45055-BC305. Porcelain enameled, glossy finish. Sold individually.

Part Number: 58211 (Replaces Fiesta SP102A-3)
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 26 9/16”
Material: porcelain steel wire
Weight: 4.12

==> All Fiesta Cooking Grids.

ESD45055-BC305 Rock/Briquette Grates

BG-2

Click for photos

Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-2
Dimension Front-to-Back: 12”
Dimension Side-to-Side: 22 3/4”
Material: carbon steel
Weight: 3.9

==> All Fiesta Rock/Briquette Grates.

ESD45055-BC305 Heat Plates

SP25-9G-SS

Click for photos

Stainless steel version replacement for original Smart Bar SP25-9G for Fiesta model ESD45055-BC305. NOTE: The original part was porcelain coated steel. Far superior to the original, this aftermarket part is made of corrosion-resistant stainless steel for longer life.

Part Number: SP25-9G-SS
Dimension Front-to-Back: 10 1/2”
Dimension Side-to-Side: 23 3/4”
Material: stainless steel
Weight: 3.0

CLA-TS0234-X3

Click for photos

SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Fiesta model ESD45055-BC305. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0234-X3
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 5 1/8”
Material: stainless steel
Weight: 3.0

==> All Fiesta Heat Plates.

ESD45055-BC305 Igniter Components

IG-46B

Click for photos

Universal extention wire, male spade end & female round end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

04300

Click for photos

Electrode kit.

Mounting bracket
Electrode with ceramic insulator
Wire with round connector
Protective sleeve

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04300
Material: ceramic
Weight: 0.1

IG-15B

Click for photos

Universal collector box with electrode and wire. Fits most H burners, cast iron and stainless. Mounts to burner using venturi screws. Slotted construction allow universal adjustment of electrode position.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-15B
Weight: 0.3

SP9A-20

Click for photos

ELECTRODE CLIP-ON

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: SP9A-20
Weight: 0.4

==> All Fiesta Igniter Components.

ESD45055-BC305 Knobs and Handles

HANDLE 450 D LID COPPER

Part Number: SM5050-42C
Weight: 1.0

KNOB AUTO IGNITE W/VLV SWITCH*

Part Number: SP13-7
Weight: 0.1

SP9-7

Click for photos

Side burner knob.

Off position D-Value: 6 o'clock
Knob diameter: 2 3/16”
Socket diameter: 5/16”
Knob shaft: 1/8”

Part Number: SP9-7
Weight: 0.1

==> All Fiesta Knobs and Handles.

ESD45055-BC305 Warming Racks

AP-6A

Click for photos

Universal warming rack. For use on grills with at least 22” inside dimension.

Part Number: AP-6A
Dimensions: 6” x 21 1/2”
Material: Chrome steel
Weight: 1.3

==> All Fiesta Warming Racks.

ESD45055-BC305 Valves, Orifices, and Manifolds

VALVE BRACKET S/B (LONG)

Part Number: SP5007-6
Weight: 1.0

==> All Fiesta Valves, Orifices, and Manifolds.

ESD45055-BC305 Miscellaneous Repair Parts

SM68-6

Click for photos

SMART ROD 345/400/450

Part Number: SM68-6
Dimensions: 12
Weight: 0.3

==> All Fiesta Miscellaneous Repair Parts.

ESD45055-BC305 Accessories

BQ-5

Click for photos

Durable 2 5/16” round briquettes

Self-cleaning
Control flare-ups while holding an even heat pattern.
About 53 pieces, covers approximately 275 sq. inches.
Fits all gas grills

Part Number: BQ-5
Weight: 7.2

45887

Click for photos

Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

WB-1

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

==> All ESD45055-BC305 Accessories.
