Brinkmann 810-7400-S Grill Parts

Brinkmann 810-7400-S

Charmglow Porcelain 4-Burner Heavy-Duty Gas Grill

Highest quality replacement parts for your Brinkmann 810-7400-S - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-7400-S owners manual and diagrams

Click the small images on the right to view Brinkmann 810-7400-S exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Brinkmann 810-7400-S-31899269999839-PartsExpS1.gif

Replacement grill parts for the Brinkmann model: 810-7400-S

All of the parts we have for Brinkmann 810-7400-S are shown on this page. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Brinkmann grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Brinkmann 810-7400-S BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-7400-S Burners

154-6430-0 / CTB3

Click for photos

Premium grade 304 stainless burner for Brinkmann model 810-7400-S.

Part Number: CTB3 (Replaces Brinkmann 154-6430-0)
Dimensions: 15 7/8
Material: stainless steel
Weight: 1.0

FP-BR1001

Click for photos

Adjustable universal front-to-back tube burner with top-ported flame holes for Brinkmann model 810-7400-S. This burner may not work with existing ignition electrodes and back burner cross-overs.

Variable length burner adjusts from 13 1/2” to 17 1/2”.
Includes extra hardware and mounting brackets to accommodate almost all grills.
Comes with complete installation instructions and diagrams.

WARNING: Before ordering this universal burner, please verify that it will work in your grill per the specifications above. If you order this universal burner and it does not work in your grill, please review our Return Policy for ”Ordered Wrong Part.” You will be responsible for all shipping fees.

Part Number: FP-BR1001
Material: stainless steel
Weight: 0.7

==> All Brinkmann Burners.

810-7400-S Cooking Grids

115-2300-0 / CG-58P-CI

Click for photos

Cast iron cooking grid for Brinkmann model 810-7400-S. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-58P-CI (Replaces Brinkmann 115-2300-0)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 8.35

==> All Brinkmann Cooking Grids.

810-7400-S Heat Plates

600-7310-T / BMHP1

Click for photos

Stainless steel heat distribution plate for Brinkmann model 810-7400-S.

Part Number: BMHP1 (Replaces Brinkmann 600-7310-T)
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 0.7

CLA-TS0156-X3

Click for photos

SET OF THREE/3 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-7400-S. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X3
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.1

CLA-TS0156-X4

Click for photos

SET OF FOUR/4 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-7400-S. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X4
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.8

==> All Brinkmann Heat Plates.

810-7400-S Heat Shields

600-7400-F / CLA-MS0273

Click for photos

Lower heat shield. Made in USA

Part Number: CLA-MS0273 (Replaces Brinkmann 600-7400-F)
Dimensions: 12 3/16” x 22 1/16”
Material: stainless steel
Weight: 2.30

==> All Brinkmann Heat Shields.

810-7400-S Igniter Components

IG-30B

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

IG-48B

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

119-4400-5 / TS-IG3007

Click for photos

Push-button electronic igniter with three (3) spade connectors. Comes with sliver or black cap per availability. Needs (1) AA battery (not included); requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG3007 (Replaces Brinkmann 119-4400-5)
Weight: 0.2

600-7419-B / IG-23B

Click for photos

Collector box with ceramic electrode and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-23B (Replaces Brinkmann 600-7419-B)
Weight: 0.3

==> All Brinkmann Igniter Components.

810-7400-S Grease Trays

600-7503-0 / CLA-DS0275

Click for photos

Stainless steel grease tray. Includes handle, grease shield and hardware; unassembled. Made in USA.

Part Number: CLA-DS0275 (Replaces Brinkmann 600-7503-0)
Dimensions: 20 1/4” x 23 1/4”
Material: stainless steel
Weight: 8.10

==> All Brinkmann Grease Trays.

810-7400-S Heat indicators and Meat Thermometers

072-7310-0 / 22551

Click for photos

Oval lid heat indicator. Three-hole mount with two threaded studs 1 1/2” offset on center. Requires 3/8” center hole for temperature sensor probe.

Part Number: 22551 (Replaces Brinkmann 072-7310-0)
Dimensions: 2 15/16” x 1 7/8”
Weight: 0.2

==> All Brinkmann Heat indicators and Meat Thermometers.

810-7400-S Accessories

00150

Click for photos

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

FS-1

Click for photos

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

BRGG

Click for photos

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

RR-2

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

WB-3

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

==> All 810-7400-S Accessories.
