Charbroil Red Infrared 466250509 Grill Parts

Charbroil logo



Charbroil 466250509

Char-Broil LP gas outdoor BBQ grill with side burner



Highest quality replacement parts for your Charbroil Red Infrared 466250509 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 466250509 owners manual and diagrams
Click the small images on the right to view Charbroil 466250509 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Charbroil 466250509-463344949030-PartsExpS1.jpg

Replacement grill parts for Charbroil Red Infrared (466250509)
All of the parts we have for Charbroil 466250509 are shown on this page. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 466250509 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



466250509 Cooking Grids

66124-1PC
Click for photos
Cast iron cooking grid for Charbroil model 466250509. Porcelain treated, matte finish. Sold individually, number required varies.

Part Number: 66124-1PC
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 8 5/16”
Material: cast iron
Weight: 3.75

$37.52

Qty


CG-74P-CI
Click for photos
Cast iron cooking grid for Charbroil model 466250509. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.

Part Number: CG-74P-CI
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 8 1/4”
Material: cast iron
Weight: 8.90

$43.61

Qty


10225-T536
Click for photos
cast iron cooking grid, SOLD INDIVIDUALLY for Charbroil model 466250509.
  • Sold individually.
  • Number required varies.
  • Porcelain enameled cast iron, flat matte finish.


Part Number: 10225-T536
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 8 1/4”
Material: Cast iron
Weight: 7.6

$56.52

Qty


80017395 / CG-74P-CI-X3
Click for photos
Cast iron cooking grids for Charbroil model 466250509. SET OF THREE (3) panels.
  • Porcelain treated, matte finish
  • Each panel measures 16 7/8” x 8 1/4”
  • Overall dimensions: 16 7/8 x 23 3/4”


Part Number: CG-74P-CI-X3 (Replaces Charbroil 80017395)
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 24 3/4”
Material: cast iron
Weight: 26.7

$113.25

Qty


69563
Click for photos
Cast iron cooking grids for Charbroil model 466250509. Porcelain enameled, glossy finish. Sold as a set of three (3).

Part Number: 69563
Dimension Front-to-Back: 16 13/16”
Dimension Side-to-Side: 27”
Material: gloss cast iron
Weight: 19.2

$147.46

Qty


==> All Charbroil Cooking Grids.






466250509 Heat Plates

80017362 / 99551
Click for photos
Stainless steel Trough for Charbroil model 466250509. Sold individually.

Part Number: 99551 (Replaces Charbroil 80017362)
Dimension Front-to-Back: 17 1/4”
Dimension Side-to-Side: 25 3/4”
Material: stainless steel
Weight: 10.0

$146.41

Qty


99571
Click for photos
Stainless steel Trough for Charbroil model 466250509. Sold individually.

Part Number: 99571
Dimension Front-to-Back: 17 1/4”
Dimension Side-to-Side: 9 1/2”
Material: stainless steel
Weight: 4.8

$111.54

Qty


==> All Charbroil Heat Plates.






466250509 Igniter Components

03152
Click for photos
Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:
  • Push-button ignition module switch with two male spade connectors on back
  • Two 20” wires with female spade connectors
  • One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

$20.78

Qty


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.51

Qty


80016128 / 09551
Click for photos
electrode

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 09551 (Replaces Charbroil 80016128)
Material: ceramic
Weight: 0.1

$10.35

Qty


80018343 / IGEIB6-B
Click for photos
Battery powered push button igniter.
  • Has six (6) spade type male connectors.
  • Uses 1 AA battery (not supplied)
  • Requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IGEIB6-B (Replaces Charbroil 80018343)
Weight: 0.3

$34.11

Qty


==> All Charbroil Igniter Components.






466250509 Rotisserie components

RO-6
Click for photos
Heavy duty stainless steel 6 1/4” x 4” x 2 1/8” cased universal rotisserie motor. On-off switch and 3 foot cord. Maximum 25 lb. balanced load. (120V, 9W, 50/60 HZ, RPM: 2.5/2.8)

Part Number: RO-6
Material: Stainless steel case
Weight: 2.0

$85.09

Qty


==> All Charbroil Rotisserie components.






466250509 Accessories

00281
Click for photos
Cedar grilling planks adds a delicious wood-smoke flavor to foods grilled on them. Great for salmon! 11 7/8” x 5 1/4” x 5/16” 100% natural cedar. Two planks per pack.

Part Number: 00281
Dimensions: 11 7/8
Weight: .45

$8.61

Qty


40269
Click for photos
20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.


Part Number: 40269
Material: stainless steel
Weight: 0.14

SALE  $14.99
Qty


SR-7B
Click for photos
Universal 6 piece chrome plated skewer set. Designed so food does not rotate. Great for kabobs! 19 1/2” long.

Part Number: SR-7B
Dimensions: 19 1/2
Material: chrome steel
Weight: 1.0

$14.27

Qty


14950
Click for photos
Marinade Injector.

For injecting flavor and marinades into meat. Disassembles for cleaning. Stainless steel injector tip. Graduated injection chamber.



Part Number: 14950
Material: stailess steel
Weight: 0.5

$14.41

Qty


SDDPS
Click for photos
Stainless Steel Scraper for Phoenix and Holland Drip Trays

Part Number: SDDPS
Dimensions: 20
Weight: 0.30

$18.07

Qty


==> All 466250509 Accessories.
