Charbroil 464820707 Grill Parts

Kenmore Dual burner LP gas grill with side burner

Highest quality replacement parts for your Charbroil 464820707 - Free USA shipping $49 or more* - No Sales Tax*

Charbroil 464820707 owners manual and diagrams

Click the small images on the right to view Charbroil 464820707 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Charbroil 464820707-463614929230-PartsExpS1.jpg

Replacement grill parts for Charbroil model: 464820707

On this page you'll find all of the parts that fit model Charbroil 464820707. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 464820707 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

464820707 Venturis

Click for photos

Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

==> All Charbroil Venturis.

464820707 Cooking Grids

Click for photos

Porcelain steel cooking grid for Charbroil model 464820707. Porcelain enameled, glossy finish. Sold individually.

Part Number: 51091 (Replaces Charbroil 80009899)
Dimension Front-to-Back: 13 3/4”
Dimension Side-to-Side: 28 3/8”
Material: porcelain steel wire
Weight: 3.9

==> All Charbroil Cooking Grids.

464820707 Heat Plates

Click for photos

Porcelain steel heat tent for Charbroil model 464820707. Sold individually.

Part Number: 91091 (Replaces Charbroil 80009898)
Dimension Front-to-Back: 26 15/16”
Dimension Side-to-Side: 6 1/8”
Material: porcelain steel
Weight: 2.5

==> All Charbroil Heat Plates.

464820707 Igniter Components

Click for photos

20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-7B
Weight: 0.02

Click for photos

20” igniter wire with two (2) female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-18B
Weight: 0.03

Click for photos

Ignitor electrode and collector box assembly. Fits all grills equiped with the Charbroil Masterflame and MasterFlame II burner systems, including grill brands Charbroil, Coleman, Kenmore, and Thermos. Fits on our burner part numbers BBC, LBBC, TBBC, and TLBBC.

Gas collector box
Ceramic electrode and wire
Mounting hardware

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-11B
Weight: 0.3

Click for photos

Collector Box and electrode for Charbroil top ported TBBC & TLBBC burners.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-28B
Weight: 0.2

==> All Charbroil Igniter Components.

464820707 Knobs and Handles

Click for photos

Knob, Black (New Style), Fits P3/4/4, SR3, D3/4/5/2.
Also replaces part# B070286, which no longer available.

Off position D-Value: 3 o'clock
Knob diameter: 1 5/8”
Socket diameter: 5/16”
Knob shaft: 1/2”

Part Number: B070084 (Replaces Charbroil 80009706)
Weight: 0.04

Click for photos

Universal black control knob. Counter-clockwise bezel.

Off position D-Value: Selectable
Knob diameter: 2 1/16”
Socket diameter: 8mm
Knob shaft: None

Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

Click for photos

Black control knob for Fire Magic Custom, Regal, and Gourmet grills.

Off position D-Value: 6 o'clock
Knob diameter: 2”
Socket diameter: 8mm
Knob shaft: None

Part Number: 01700 (Replaces Charbroil 80000035)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

==> All Charbroil Knobs and Handles.

464820707 Heat indicators and Meat Thermometers

Click for photos

Round heat indicator.

Single probe
1 13/16” diameter
Requires 3/8” mounting hole

Part Number: 00018 (Replaces Charbroil G431-0020-W2)
Dimensions: 1 13/16” x 1 13/16”
Weight: 0.1

==> All Charbroil Heat indicators and Meat Thermometers.

464820707 Accessories

Click for photos

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

==> All 464820707 Accessories.
