Charbroil 464820907 Grill Parts

Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

Porcelain steel cooking grid for Charbroil model 464820907. Porcelain enameled, glossy finish. Sold individually.

Part Number: 51091 (Replaces Charbroil 80009899)
Dimension Front-to-Back: 13 3/4”
Dimension Side-to-Side: 28 3/8”
Material: porcelain steel wire
Weight: 3.9

Porcelain steel heat tent for Charbroil model 464820907. Sold individually.

Part Number: 91091 (Replaces Charbroil 80009181)
Dimension Front-to-Back: 26 15/16”
Dimension Side-to-Side: 6 1/8”
Material: porcelain steel
Weight: 2.5

Universal push-button piezo igniter. External grounding tab for use as ground or to power a side burner igniter.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: UP-7B (Replaces Charbroil 5156113)
Weight: 0.3

Universal 2 1/2” adaptor wire with a round female end and a male spade end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-7B
Weight: 0.02

20” igniter wire with two (2) female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-18B
Weight: 0.03

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Ignitor electrode and collector box assembly. Fits all grills equiped with the Charbroil Masterflame and MasterFlame II burner systems, including grill brands Charbroil, Coleman, Kenmore, and Thermos. Fits on our burner part numbers BBC, LBBC, TBBC, and TLBBC.

Includes:
• Gas collector box
• Ceramic electrode and wire
• Mounting hardware

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-11B
Weight: 0.3

Collector Box and electrode for Charbroil top ported TBBC & TLBBC burners.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-28B
Weight: 0.2

Snap In Piezo Ignitor. Fits Weber Genesis Silver A,B,C and Newer Spirit E310 & E320.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: UP-9B
Weight: 0.2

Knob, Black (New Style), Fits P3/4/4, SR3, D3/4/5/2.
Also replaces part# B070286, which no longer available.

• Off position D-Value: 3 o'clock
• Knob diameter: 1 5/8”
• Socket diameter: 5/16”
• Knob shaft: 1/2”

Part Number: B070084 (Replaces Charbroil 80009706)
Weight: 0.04

Universal black control knob. Counter-clockwise bezel.

• Off position D-Value: Selectable
• Knob diameter: 2 1/16”
• Socket diameter: 8mm
• Knob shaft: None

Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

Black control knob for Fire Magic Custom, Regal, and Gourmet grills.

• Off position D-Value: 6 o'clock
• Knob diameter: 2”
• Socket diameter: 8mm
• Knob shaft: None

Part Number: 01700 (Replaces Charbroil 80000035)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

Meat Claws.

Shredding pork, chicken, or beef has never been easier. Spare the fork these meat shedding claws can hold with the larger outside tines and shred fine strands of meat with the smaller inside tines. Crafted of stainless steel with an easy to use grip that can be held multiple ways.
Each claw is 8.25 in. in overall length.

Part Number: 44070
Dimensions: 8 1/4
Material: stainless steel
Weight: 0.5

Deluxe non-stick chicken and rib tumble basket. Attaches to rotisserie spit rod.

• Ideal for cooking pieces of meat or vegetables
• Self basting, easy to use
• Locks on spit rod with thumb screw (supplied)
• 6 1/2” x 10” long

Part Number: 24764
Dimensions: 6 1/2” x 10”
Weight: 1.1

Deluxe 13” basting mop with hardwood handle and cotton mop head.

Part Number: 42055
Dimensions: 13
Weight: 0.2

Porcelain Coated Square Wok Topper.
12” x 12” x 2” porcelain coated grilling wok with stainless steel handles and perforations. The single draw design improves functionality and rigidity, it also makes it much easier to clean.


Part Number: 98121
Material: porcelain steel
Weight: 1.6

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2
