Grill-Parts home

Charbroil Performance 463461406 Grill Parts

Charbroil logo



Charbroil 463461406

Char-Broil Performance Series 3-Burner LP gas grill with side burner



Highest quality replacement parts for your Charbroil Performance 463461406 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463461406 owners manual and diagrams
Diagrams & owners manual not available for grill model# 463461406. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!




Replacement grill parts to fit Charbroil Performance 463461406
This page shows all of the parts we know fit model Charbroil 463461406. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 463461406 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463461406 Burners

CBP1-CI
Click for photos
Cast iron burner for Charbroil Performance and Advantage series grills for Charbroil model 463461406. Interchangable with the stainless steel version.

Part Number: CBP1-CI
Dimensions: 13 3/4” x 3 3/8”
Material: cast iron
Weight: 6.0

$43.10


7000083 / CBP1
Click for photos
Stainless steel burner for Charbroil Performance and Advantage series grills for Charbroil model 463461406. Interchangable with the cast iron version.

Part Number: CBP1 (Replaces Charbroil 7000083)
Dimensions: 13 3/4” x 3 1/4”
Material: stainless steel
Weight: 2.0

$47.74


==> All Charbroil Burners.






463461406 Burner Brackets and Carryovers

7000279 / CBBR2
Click for photos
Burner support bracket with gas carryover tubes. For 3-burner grills.

Part Number: CBBR2 (Replaces Charbroil 7000279)
Dimensions: 19 5/16
Material: stainless steel
Weight: .35

$29.40


==> All Charbroil Burner Brackets and Carryovers.






463461406 Cooking Grids

7000027 / CG-62P-CI
Click for photos
Cast iron cooking grid for Charbroil model 463461406. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-62P-CI (Replaces Charbroil 7000027)
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 7 7/8”
Material: cast iron
Weight: 4.75

$39.89


7000028 / CG-61P-CI
Click for photos
Cast iron cooking grid for Charbroil model 463461406. Porcelain treated, matte finish. Sold individually, number required varies by grill model

Part Number: CG-61P-CI (Replaces Charbroil 7000028)
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 12”
Material: cast iron
Weight: 6.45

$59.87


==> All Charbroil Cooking Grids.






463461406 Heat Plates

7000381 / CBHP1
Click for photos
Stainless steel VapoRiser Tent for Charbroil model 463461406. Fully functional replacement without the louvered slots.

Part Number: CBHP1 (Replaces Charbroil 7000381)
Dimension Front-to-Back: 11 3/4”
Dimension Side-to-Side: 5 5/8”
Material: stainless steel
Weight: 0.7

$24.42


CLA-TS0144-X3
Click for photos
SET OF THREE/3 PACK Stainless steel heat plate for Charbroil model 463461406. Made in USA.

Note: Not identical to original, but a fully functional replacement.

Note: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0144-X3
Dimension Front-to-Back: 11 3/4”
Dimension Side-to-Side: 5 9/16”
Material: stainless steel
Weight: 1.8

$66.39


==> All Charbroil Heat Plates.






463461406 Igniter Components

IG-24B
Click for photos
Ceramic electrode for use with CBP1-CI cast iron burner.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-24B
Weight: 0.3

$8.32


==> All Charbroil Igniter Components.






463461406 Accessories

00230
Click for photos
Apple wood chips.
  • All natural wood smoke flavor
  • Great for use in BBQ's or smokers.
  • 170 cubic inches (2 lbs. approx) in resealable bag

Try with portk, lamb, poultry, and fish.

Part Number: 00230
Weight: 2.0

$8.47


40269
Click for photos
20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.

Part Number: 40269
Material: stainless steel
Weight: 0.14

$21.26


40538
Click for photos
Set of six 22” stainless steel V skewers with wood handles and silicone bezels. Silicone bezel helps the handle stay cool longer. V-shaped skewers keep food from spinning on shaft.

Part Number: 40538
Material: chrome steel
Weight: 1.1

$15.59


BB-5
Click for photos
Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

$9.36


98130
Click for photos
Porcelain Coated Round Topper.
11” diameter x 2.5” deep porcelain coated wok with stainless steel handles and perforations. Rolled edge for rigidity and safety.

Part Number: 98130
Dimensions: 11
Material: porcelain steel
Weight: 1.0

$19.15


WB-3
Click for photos
18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

$13.66


==> All 463461406 Accessories.




BBQ Part Categories


























Charbroil 463461406 -Tuesday, May 12 2026

Return to Charbroil grills main page



More Charbroil grill models we have parts for
463270914 | 463270915 | 463271009 | 463271108 | 463271309 | 463271310 | 463271311 | 463271312 | 463271313 | 463271314 | 463271315 | 463271509 | 463271510 | 463271912 | 463271913 | 463272108 | 463272509 | 463272912 | 463273012 | 463273112 | 463273614 | 463273615 | 463274419 | 463275517 | 463276016 | 463276617 | 463278418 | 4632800 | 4632801 | 4632803 | 4632804 | 4632820 | 4632823 | 4632911 | 4632912 | 4632920 | 4632922 | 463320107 | 463320108 | 463320109 | 463320110 | 463320308 | 463320707 | 463320708 | 463320709 | 463322613 | 463332718 | 463332719 | 463334613 | 463335014 | Complete list of Charbroil grill models...



*Orders for Charbroil Performance grill model 463461406 $49 and over ship free to the lower 48 states.
