Broil-Mate 4485-4 Grill Parts

Broil-Mate logo



Broil-Mate 4485-4



Highest quality replacement parts for your Broil-Mate 4485-4 - Free USA shipping $49 or more* - No Sales Tax*



Broil-Mate 4485-4 owners manual and diagrams
Click the small images on the right to view Broil-Mate 4485-4 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Broil-Mate 4485-4-466144633-PartsExpS1.gif  Broil-Mate 4485-4-466144633-PartsLstS1.gif  Broil-Mate 4485-4-466144633-PartsLstS2.gif

Replacement gas grill parts for Broil-Mate model: 4485-4
On this page you'll find all of the parts that fit model Broil-Mate 4485-4. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Broil-Mate grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Broil-Mate 4485-4 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Broil-Mate model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



4485-4 Burners

S10017
Click for photos
Genuine OEM Broil-Mate stainless steel burner and venturi assembly for Broil-Mate model 4485-4. Includes burner-mounted igniter electrode and wire part# S15500. Fully assembled.

Part Number: S10017
Dimensions: 8” x 20 1/2”
Material: Stainless steel
Weight: 3.5

$74.45


==> All Broil-Mate Burners.






4485-4 Cooking Grids

CG-21SS
Click for photos
Premium grade solid stainless steel grid with 1/4” rods for Broil-Mate model 4485-4. Sold individually, two (2) required.

Part Number: CG-21SS
Dimension Front-to-Back: 15 1/4”
Dimension Side-to-Side: 11”
Material: stainless steel
Weight: 4.00

$49.81


==> All Broil-Mate Cooking Grids.






4485-4 Heat Plates

10222-T425
Click for photos
Genuine OEM Broil-Mate stainless steel Flav-R-Wave heat plate for Broil-Mate model 4485-4. Also replaces porcelain-steel lava rock/briquette grate part# 10222-T424, which has been discontinued by the manufacturer.

Part Number: 10222-T425
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 23”
Material: Stainless steel
Weight: 3.0

$58.85


==> All Broil-Mate Heat Plates.






4485-4 Igniter Components

10342-245
Click for photos
Genuine OEM Broil-Mate electronic push-button 2-spade igniter.
  • Uses AAA battery (not included)
  • .Requires 3/4” mounting hole
  • Also replaces part# 10342-242 and 10342-249

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-245
Weight: 0.3

$19.40


10342-T14
Click for photos
Genuine OEM Broil-Mate 21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

$4.32


S15500
Click for photos
Genuine OEM Broil-Mate collector box and electrode assembly. Includes
  • burner mounted collector box (clip on)
  • ceramic electrode and 18” wire with round connector and protective sleeve.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: S15500
Weight: 0.1

$5.45


==> All Broil-Mate Igniter Components.






4485-4 Knobs and Handles

10472-K431
Click for photos

10472-K431 Control knob large. Black with stainless steel BA strip.

Genuine OEM control knob.
  • Off position D-Value: 6 o'clock
  • Knob diameter: 2 1/4”
  • Socket diameter: 5/16”
  • Knob stem: 1/2”


Part Number: 10472-K431
Weight: 0.1

$5.94


==> All Broil-Mate Knobs and Handles.






4485-4 Regulators and Hoses

HR-4B
Click for photos

Type 1 LP Regulator with 22” Pressure Hose and 3/8” Female Flare Fitting.FITS: Up to 60,000 BTUs



Part Number: HR-4B
Weight: 0.8

$35.70


==> All Broil-Mate Regulators and Hoses.






4485-4 Warming Racks

CLA-WS0192
Click for photos
Premium grade stainless steel warming rack. This rack made to replace part numbers S12205, S12206, and S12207, which are no longer available from the manufacturer. Made in USA

Part Number: CLA-WS0192
Dimensions: 10 1/2” x 23 1/8”
Material: stainless steel
Weight: 4.8

$49.62


==> All Broil-Mate Warming Racks.






4485-4 Rotisserie components

RO-4
Click for photos
Universal durable battery operated rotisserie motor. Conveniently eliminates the need for electric cords. Runs on 2 D cells (not included).

Part Number: RO-4
Weight: 1.0

$28.22


==> All Broil-Mate Rotisserie components.






4485-4 Heat indicators and Meat Thermometers

10571-6
Click for photos
Genuine OEM Broil-Mate Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

$21.20


==> All Broil-Mate Heat indicators and Meat Thermometers.






4485-4 Accessories

HOW TO GRILL The Complete Illustrated Book of Barbecue Techniques. Steve Raichlen presents a full-color, step-by-step technique book that gets to the core of the grilling experience by showing and telling exactly how it's done. With more than 1,000 photographs, if features over 100 techniques and recipes, from how to set up a three-zone fire to how to grill a perfect prime rib, to grilling pizza, shellfish, vegetables, tofu, fruit, and s'mores.

Part Number: 0-7611-2014-9
Dimensions: 8” x 9 1/4”
Material: Paperback
Weight: 3.0

$20.09


40070
Click for photos
4 Piece Stainless Steel Tool Set With Accents Turner, tong, and fork constructed of high gade, polished stainless steel, with soft grip accents. Silicone tip tongs heat resistant to 500 degrees farenheit. High quality grill brush.

Part Number: 40070
Material: stainless steel
Weight: 2.12

$39.08


00185
Click for photos


Part Number: 00185
Material: stainless
Weight: .3

$17.30


14913
Click for photos

Stainless Steel Basting Set.

Measurements inside the stainless steel bowl for accurate sauce preparation. Includes silicone basting brush.



Part Number: 14913
Material: stailess steel
Weight: 0.5

$14.41


CGT
Click for photos
Cannon Grill Towel.

Part Number: CGT
Dimensions: 16” x 25”
Weight: 0.30

$20.58


==> All 4485-4 Accessories.
