Broil King 536-33 Grill Parts

Genuine OEM Broil King stainless steel burner and venturi assembly for Broil King model 536-33.

Part Number: 10390-T301
Dimensions: 5 1/4” x 13 7/16”
Material: Stainless steel
Weight: 1.85

Genuine OEM Broil King Side Burner for Broil King model 536-33. Use air shutter to adjust for LP (less air flow) or natural gas (more air flow).

Part Number: 10390-E10
Weight: 0.4

Cooking grid not known for Broil King model 536-33. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Broil King cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0

Genuine OEM Broil King stainless steel Flav-R-Wave heat plate for Broil King model 536-33.

Part Number: 10222-T225
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 9 1/8”
Material: stainless steel
Weight: 1.85

Genuine OEM Broil King push button igniter. For two-wire grills with second wire for side burner. Wires not included.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-22
Weight: 0.2

Genuine OEM Broil King collector box and electrode assembly. Includes:

• burner mounted box with mounting screw
• ceramic electrode and 17” wire with round connector and protective sleeve
• Use with burners 10390-T401 (14102) and 10390-T501 (14212)

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T301
Weight: 0.05

Genuine OEM Broil King 21” wire for side burner or other applications. Both ends are female spade connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T12
Dimensions: 21
Weight: 0.05

Stainless steel wire grease cup holder for mini bucket #S15112 which has been discontinued and replaced with mini bucket # 4673-FC. This wire holder can also be used with tin cans for easy disposal of grease.

Part Number: S15111
Material: stainless steel
Weight: 0.02

Mini grease bucket used with wire holder S15111.

Part Number: S15112
Weight: .03

Black lid handle. Fits older GrillPro and other models which use a half-handle that is 10 3/4” long. Requires 8 3/4” mounting holes, center to center.

Part Number: 30230228
Weight: 0.45

HOSE SIDE BRNR W/.079 ORIFICE

Part Number: S13467-079
Weight: 1.0

Genuine OEM Broil King 7” cart wheel with 3/8” axel hole. Mini hub cap is # 00400251, sold separately.

Part Number: 10892-7G
Weight: .45

Wheel bolt 3.25” long; uses one hinge pin part number S21233 not included.

Part Number: 10240-13
Weight: .10

Genuine OEM Broil King warming rack.

• Front-to-back of rack itself: 9 5/8”
• Side-to-side of rack itself: 19 1/2”
• Length of rear mounting rod: 22 1/2”
• Length of front swing-away rod: 22”

Part Number: 38110174
Dimensions: 9 5/8” x 19 1/2”
Material: chrome steel
Weight: 1.4

Hinge pin clip.

Part Number: S21233
Weight: 0.01

Cotter pin

Part Number: Y-11230
Weight: 0.01

Leg plug extension.

Part Number: Y-12665
Weight: 0.1

Washer

Part Number: S21255
Weight: 0.01

SCREW-PHCP 6-32X1/4 TY-F JS500

Part Number: Y-12835
Weight: 1.0

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

15” Stainless steel tong.

• Soft comfort grip
• Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14
