Broil King 553-14 Grill Parts

Broil King 553-14

Highest quality replacement parts for your Broil King 553-14 - Free USA shipping $49 or more* - No Sales Tax*

Broil King 553-14 owners manual and diagrams

Click the small images on the right to view Broil King 553-14 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Broil King 553-14-344558633-PartsExpS1.gif

Broil King 553-14-344558633-PartsLstS1.gif

Broil King 553-14-344558633-PartsLstS2.gif

Replacement grill parts for the Broil King model: 553-14

All of the parts we have for Broil King 553-14 are shown on this page. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Broil King grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Broil King 553-14 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Broil King model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

553-14 Burners

10390-T501

Click for photos

Genuine OEM Broil King stainless steel Infinity burner assembly for Broil King model 553-14. This burner assembly does not include the electrodes. Includes:

One stainless steel Infinity burner
Twin venturi with spider exclusion screens

Part Number: 10390-T501
Dimensions: 8” x 20”
Material: Stainless steel
Weight: 3.2

==> All Broil King Burners.

553-14 Cooking Grids

10225-T423

Click for photos

Genuine OEM Broil King cooking grid for Broil King model 553-14. Right side of a 2-piece left-right pair. Left side part 10225-T422 sold separately. Porcelain enameled steel, glossy finish with 1/4” rods.

Part Number: 10225-T423
Dimension Front-to-Back: 15 5/16”
Dimension Side-to-Side: 10 3/8”
Material: Porcelain steel
Weight: 3.5

==> All Broil King Cooking Grids.

553-14 Heat Plates

10222-T425

Click for photos

Genuine OEM Broil King stainless steel Flav-R-Wave heat plate for Broil King model 553-14. Also replaces porcelain-steel part# 10222-T424, which has been discontinued by the manufacturer.

Part Number: 10222-T425
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 23”
Material: Stainless steel
Weight: 3.0

==> All Broil King Heat Plates.

553-14 Igniter Components

10342-21

Click for photos

Push button igniter. For single wire for grills with no side burner. Wires not included. Comes in black or grey as available from manufacturer.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-21
Weight: 0.05

10342-T301

Click for photos

Genuine OEM Broil King collector box and electrode assembly. Includes:

burner mounted box with mounting screw
ceramic electrode and 17” wire with round connector and protective sleeve
Use with burners 10390-T401 (14102) and 10390-T501 (14212)

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T301
Weight: 0.05

==> All Broil King Igniter Components.

553-14 Grease Trays

S15111

Click for photos

Stainless steel wire grease cup holder for mini bucket #S15112 which has been discontinued and replaced with mini bucket # 4673-FC. This wire holder can also be used with tin cans for easy disposal of grease.

Part Number: S15111
Material: stainless steel
Weight: 0.02

==> All Broil King Grease Trays.

553-14 Knobs and Handles

10472-K36

Click for photos

Genuine OEM Broil King control knob.

Off position D-Value: 6 o'clock
Knob diameter: 1 5/8”
Socket diameter: 5/16”
Knob shaft: 1/2”

Part Number: 10472-K36
Weight: 0.05

10239-7

Click for photos

Triangular handle washer. 1/8 in thick. Made of heat resistant compressed material.

Part Number: 10239-7
Dimensions: 1 1/2” x 1 1/4”
Weight: 0.05

==> All Broil King Knobs and Handles.

553-14 Regulators and Hoses

HR-4B

Click for photos

Type 1 LP Regulator with 22” Pressure Hose and 3/8” Female Flare Fitting.FITS: Up to 60,000 BTUs

Part Number: HR-4B
Dimensions: 22
Weight: 0.8

==> All Broil King Regulators and Hoses.

553-14 Wheels and Castors

10892-7G

Click for photos

Genuine OEM Broil King 7” cart wheel with 3/8” axel hole. Mini hub cap is # 00400251, sold separately.

Part Number: 10892-7G
Weight: .45

10240-13

Click for photos

Wheel bolt 3.25” long; uses one hinge pin part number S21233 not included.

Part Number: 10240-13
Weight: .10

==> All Broil King Wheels and Castors.

553-14 Heat indicators and Meat Thermometers

10571-5

Click for photos

Genuine OEM Broil King Heat indicator. About 1 7/8” wide and 1 7/16” high. The threaded stem is about 5/16” diameter and 1 1/8” long.

Part Number: 10571-5
Dimensions: 1 7/8” x 1 7/16”
Weight: 0.1

==> All Broil King Heat indicators and Meat Thermometers.

553-14 Miscellaneous Repair Parts

S21233

Click for photos

Hinge pin clip.

Part Number: S21233
Weight: 0.01

Y-6616

Click for photos

Bolt

Part Number: Y-6616
Weight: 0.02

S21346

Click for photos

Leg end cap.

Part Number: S21346
Weight: 0.1

S21255

Click for photos

Washer

Part Number: S21255
Weight: 0.01

==> All Broil King Miscellaneous Repair Parts.

553-14 Accessories

40269

Click for photos

20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.

Part Number: 40269
Material: stainless steel
Weight: 0.14

BRGG

Click for photos

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

==> All 553-14 Accessories.
