Brinkmann Pro Series 6430 810-6430-W Grill Parts

Brinkmann Pro Series 6430 - 4 Burner Heavy-Duty LP Gas Grill

Highest quality replacement parts for your Brinkmann Pro Series 6430 810-6430-W - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-6430-W owners manual and diagrams

Click the small images on the right to view Brinkmann 810-6430-W exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Brinkmann 810-6430-W-31899365999839-PartsExpS1.gif

Replacement grill parts for Brinkmann Pro Series 6430 (810-6430-W)

This page shows all of the parts we know fit model Brinkmann 810-6430-W. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Brinkmann grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Brinkmann 810-6430-W BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-6430-W Burners

Click for photos

Adjustable universal front-to-back tube burner with top-ported flame holes for Brinkmann model 810-6430-W. This burner may not work with existing ignition electrodes and back burner cross-overs.

Variable length burner adjusts from 13 1/2” to 17 1/2”.
Includes extra hardware and mounting brackets to accommodate almost all grills.
Comes with complete installation instructions and diagrams.

WARNING: Before ordering this universal burner, please verify that it will work in your grill per the specifications above. If you order this universal burner and it does not work in your grill, please review our Return Policy for ”Ordered Wrong Part.” You will be responsible for all shipping fees.

Part Number: FP-BR1001
Material: stainless steel
Weight: 0.7

Click for photos

Premium grade 304 stainless burner for Brinkmann model 810-6430-W.

Part Number: CTB3 (Replaces Brinkmann 154-6430-0)
Dimensions: 15 7/8
Material: stainless steel
Weight: 1.0

==> All Brinkmann Burners.

810-6430-W Burner Brackets and Carryovers

Click for photos

Main burner support bracket. Replaces Brinkmann OEM part# 600-6431-B. Made in USA.

Part Number: CLA-MX0046
Dimensions: 24 5/16
Material: stainless steel
Weight: 0.8

==> All Brinkmann Burner Brackets and Carryovers.

810-6430-W Cooking Grids

Click for photos

Cast iron cooking grid for Brinkmann model 810-6430-W. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-58P-CI (Replaces Brinkmann 115-6430-0)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 8.35

==> All Brinkmann Cooking Grids.

810-6430-W Heat Plates

Heat Plate/ Flame Tamer not known for Brinkmann model 810-6430-W. Our parts information for this grill model is incomplete, and we really don't know with certainty which heat plate fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the heat plates we carry for your brand grill. If we don't have the exact fit for your grill, we may have a suitable replacement part. Measure your existing part so you'll know exactly what size is needed.

If you have this grill model and know the number and dimensions of your original heat plates, click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: HP-DUMMY
Weight: 1.0

==> All Brinkmann Heat Plates.

810-6430-W Igniter Components

Click for photos

Universal battery powered push button ignitor.

1.5 volt
Has five (5) terminals (male spade connector)
Uses a single AA battery (not included))
03610 and 03620 wires are commonly used with this igniter (not included)
Requires 7/8” mounting hole
Overall dimensions: 2” x 3 3/8” x 3”
Some original igniters had an integrated ground wire. Use wire part# 03620 for this purpose.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03380
Dimensions: 3 5/16” x 2”
Weight: 0.7

==> All Brinkmann Igniter Components.

810-6430-W Heat indicators and Meat Thermometers

Click for photos

heat indicator

Part Number: 02351 (Replaces Brinkmann 072-2400-0)
Dimensions: 2 5/8” x 2 5/8”
Weight: 0.2

==> All Brinkmann Heat indicators and Meat Thermometers.

810-6430-W Accessories

Click for photos

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Click for photos

Extra long stainless steel fork with ergonomically correct handles. 20 1/2” long.

Part Number: ITF-2
Dimensions: 20 1/2
Material: stainless steel
Weight: 0.3

Click for photos

Shish-ke-bab set. 6 chrome plated 14” skewers with convenient folding rack; folds out to 10” x 13 3/4”.

Part Number: 41338
Weight: 1.1

Click for photos

Deluxe 13” basting mop with hardwood handle and cotton mop head. Great for spreading BBQ sauces, marinades, and glazes on meat and poultry.

Part Number: 42055
Dimensions: 13
Weight: 0.2

Click for photos

Porcelain Coated Square Wok Topper.
12” x 12” x 2” porcelain coated grilling wok with stainless steel handles and perforations. The single draw design improves functionality and rigidity, it also makes it much easier to clean.

Part Number: 98121
Dimensions: 12” x 12”
Material: porcelain steel
Weight: 1.6

Click for photos

Grill Mitt With Neoprene Palm.

16 in. silicone mitt diffuses heat away from the hand and washes easily. Black palm / red colored cuff. Cotton lined.
*One Size Fits Most

Part Number: 90963
Weight: 0.2

==> All 810-6430-W Accessories.
