Brinkmann 810-6355-T Grill Parts

Brinkmann 810-6355-T

Grill Zone 6355 3-Burner LP gas grill with side burner

Highest quality replacement parts for your Brinkmann 810-6355-T - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-6355-T owners manual and diagrams

Diagrams & owners manual not available for grill model# 810-6355-T. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement BBQ grill parts for Brinkmann model: 810-6355-T

All of the parts we have for Brinkmann 810-6355-T are shown on this page. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Brinkmann grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Brinkmann 810-6355-T BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-6355-T Burners

154-2300-5 / CIT-L

Click for photos

Cast iron burner for Brinkmann model 810-6355-T.

Part Number: CIT-L (Replaces Brinkmann 154-2300-5)
Dimensions: 16 1/4” x 2 3/8”
Material: cast iron
Weight: 4.0

==> All Brinkmann Burners.

810-6355-T Cooking Grids

115-2300-0 / CG-58P-CI

Click for photos

Cast iron cooking grid for Brinkmann model 810-6355-T. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-58P-CI (Replaces Brinkmann 115-2300-0)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 8.35

==> All Brinkmann Cooking Grids.

810-6355-T Heat Plates

CLA-TS0156-X3

Click for photos

SET OF THREE/3 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-6355-T. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X3
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.1

CLA-TS0156-X4

Click for photos

SET OF FOUR/4 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-6355-T. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X4
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.8

BMHP1

Click for photos

Stainless steel heat distribution plate for Brinkmann model 810-6355-T.

Part Number: BMHP1
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 0.7

==> All Brinkmann Heat Plates.

810-6355-T Igniter Components

TS-IG4010

Click for photos

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

This part is currently out of stock, but more are already on the way and expected to arrive late May

Part Number: TS-IG4010
Weight: 0.2

IGEIB4-B

Click for photos

Battery powered push button igniter.

Has four (4) spade type male connectors.
Uses 1 AAA battery (not supplied)
Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B
Weight: 0.3

IG-30B

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

IG-48B

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

600-7541-B / IG-21B

Click for photos

Collector box with ceramic igniter electrode and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-21B (Replaces Brinkmann 600-7541-B)
Weight: 0.2

==> All Brinkmann Igniter Components.

810-6355-T Accessories

00215

Click for photos

GrillPro Wood chips from genuine oak whiskey barrels.

All natural wood smoke flavor
Great for use in BBQ's or smokers.
170 cubic inches (2 lbs. approx) in resealable bag

Try with beef, burgers, pork, lamb, poultry, and fish.

Part Number: 00215
Weight: 2.0

40240

Click for photos

16” Stainless Steel Tong/Turner Combination. 16” multi-use tool with red soft grip rubber inserts. Can be used as a turner, tong or both. Manual lock saves on storage space.

Part Number: 40240
Dimensions: 16” x 4”
Material: chrome steel
Weight: 0.9

76745

Click for photos

GrillPro ® grid lifter removes both cast and stainless cooking grids.

One set of tines to remove cast and another to remove stainless cooking grids.

Stainless tip, resin handle.

Part Number: 76745
Material: stainless
Weight: .2

42055

Click for photos

Deluxe 13” basting mop with hardwood handle and cotton mop head. Great for spreading BBQ sauces, marinades, and glazes on meat and poultry.

Part Number: 42055
Dimensions: 13
Weight: 0.2

RR-2

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

CGT

Click for photos

Cannon Grill Towel.

Part Number: CGT
Dimensions: 16” x 25”
Weight: 0.30

==> All 810-6355-T Accessories.

BBQ Part Categories

Brinkmann gas grill 810-6355-T - Tuesday, May 12 2026

Return to Brinkmann grills main page

More Brinkmann grill models we have parts for

810-6345-3 | 810-6345-T | 810-6390-0 | 810-6410-T | 810-6418-0 | 810-6418-3 | 810-6419-2 | 810-6420-S | 810-6430-W | 810-6440-T | 810-6445-0 | 810-6500-F | 810-6550-S | 810-6570-F | 810-6630-B | 810-6631-F | 810-6650-T | 810-6668-0 | 810-6670-T | 810-6680-S | 810-6800-0 | 810-6800-B | 810-6805-1 | 810-6805-S | 810-6830-0 | 810-6835-1 | 810-7231-W | 810-7310-F | 810-7310-S | 810-7341-W | 810-7400-F | 810-7400-S | 810-7405-S | 810-7420-F | 810-7420-S | 810-7430-F | 810-7440-F | 810-7440-S | 810-7450-S | 810-7451-F | 810-7451-S | 810-7490-F | 810-7490-S | 810-7500-S | 810-7541-B | 810-7541-W | 810-7600-F | 810-7600-S | 810-7625-0 | Complete list of Brinkmann grill models...

*Orders for Brinkmann grill model 810-6355-T $49 and over ship free to the lower 48 states.
