Brinkmann Pro Series 4435 810-4435-1 Grill Parts

Brinkmann Pro Series 4435 - 4 Burner Gas Grill with Rotisserie

Highest quality replacement parts for your Brinkmann Pro Series 4435 810-4435-1 - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-4435-1 owners manual and diagrams

Click the small images on the right to view Brinkmann 810-4435-1 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Brinkmann 810-4435-1-31899665448839-PartsExpS1.gif

Replacement gas grill parts for Brinkmann Pro Series 4435 810-4435-1

All of the parts we have for Brinkmann 810-4435-1 are shown on this page. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Brinkmann grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Brinkmann 810-4435-1 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-4435-1 Burners

Click for photos

154-2500-0-R-X4 Cast iron burners for Brinkmann model 810-4435-1. Set of four (4). FIts some Brinkman and Grill Zone 4-Burner gas grills. May fit other grill models. This aftermarket burner replaces original burner part# 154-2500-0.

This a 4-pack of burners.

Part Number: 154-2500-0-R-X4 (Replaces Brinkmann 154-2500-0-X4)
Dimensions: 12 7/8” x 2 1/8”
Material: cast iron
Weight: 8.8

Click for photos

154-2500-0-R Cast iron burner for some Brinkmann and Grill Zone 3, 4, and 6 burner grills for Brinkmann model 810-4435-1. Sold individually.

This aftermarket part replaces original Brinkmann part# 154-2500-0.

Part Number: 154-2500-0-R (Replaces Brinkmann 154-2500-0)
Dimensions: 12 7/8” x 2 1/8”
Material: cast iron
Weight: 2.2

==> All Brinkmann Burners.

810-4435-1 Cooking Grids

Click for photos

Cast iron cooking grids for Brinkmann model 810-4435-1. SET OF TWO (2) panels.

Porcelain treated, matte finish
Each panel measures 16 15/16” x11 3/4”
Overall dimensions: 16 15/16” x23 1/2”

Part Number: CG-63P-CI-X2
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 11 3/4”
Material: cast iron
Weight: 14.30

Click for photos

Cast iron cooking grid for Brinkmann model 810-4435-1. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-63P-CI (Replaces Brinkmann 115-4425-B)
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 11 3/4”
Material: cast iron
Weight: 7.15

==> All Brinkmann Cooking Grids.

810-4435-1 Heat Plates

Click for photos

Stainless steel Flame Tamer for Brinkmann model 810-4435-1. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0001 (Replaces Brinkmann 600-4426-5)
Dimension Front-to-Back: 13 1/2”
Dimension Side-to-Side: 4 1/2”
Material: stainless steel
Weight: 0.7

Click for photos

SET OF FOUR/4 PACK Stainless steel Flame Tamer for Brinkmann model 810-4435-1. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0001-X4
Dimension Front-to-Back: 13 1/2”
Dimension Side-to-Side: 4 1/2”
Material: stainless steel
Weight: 2.8

==> All Brinkmann Heat Plates.

810-4435-1 Igniter Components

Click for photos

Push-button electronic igniter with three (3) spade connectors. Comes with sliver or black cap per availability. Needs (1) AA battery (not included); requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG3007 (Replaces Brinkmann 119-4400-5)
Weight: 0.2

==> All Brinkmann Igniter Components.

810-4435-1 Accessories

Click for photos

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.

Part Number: SSST
Material: stainless steel
Weight: 1.5

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

==> All 810-4435-1 Accessories.
