Brinkmann 810-8403-F Grill Parts

Brinkmann logo



Brinkmann 810-8403-F

Charmglow 4 Burner Stainless Steel Gas Grill



Highest quality replacement parts for your Brinkmann 810-8403-F - Free USA shipping $49 or more* - No Sales Tax*



Brinkmann 810-8403-F owners manual and diagrams
Diagrams & owners manual not available for grill model# 810-8403-F. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!




Replacement BBQ grill parts for Brinkmann model: 810-8403-F
On this page you'll find all of the parts that fit model Brinkmann 810-8403-F. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Brinkmann grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Brinkmann 810-8403-F BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



810-8403-F Burners

154-6320-0 / CTB2
Click for photos
stainless steel burner for Brinkmann model 810-8403-F.

Part Number: CTB2 (Replaces Brinkmann 154-6320-0)
Dimensions: 16 1/4
Material: stainless steel
Weight: 1.0

$38.24

Qty


FP-BR1001
Click for photos
Adjustable universal front-to-back tube burner with top-ported flame holes for Brinkmann model 810-8403-F. This burner may not work with existing ignition electrodes and back burner cross-overs.
  • Variable length burner adjusts from 13 1/2” to 17 1/2”.
  • Includes extra hardware and mounting brackets to accommodate almost all grills.
  • Comes with complete installation instructions and diagrams.

WARNING: Before ordering this universal burner, please verify that it will work in your grill per the specifications above. If you order this universal burner and it does not work in your grill, please review our Return Policy for ”Ordered Wrong Part.” You will be responsible for all shipping fees.


Part Number: FP-BR1001
Material: stainless steel
Weight: 0.7

SALE  $19.97
Qty


==> All Brinkmann Burners.






810-8403-F Cooking Grids

CG-58P-CI-X2
Click for photos
Cast iron cooking grids for Brinkmann model 810-8403-F. SET OF TWO (2) panels.
  • Porcelain treated, matte finish
  • Each panel measures 19 1/8” x 12 3/8”
  • Overall dimensions: 19 1/8” x 24 3/4”


Part Number: CG-58P-CI-X2
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 16.7

$118.96

Qty


CLA-GS0190
Click for photos

Premium quality heavy duty stainless steel cooking grid for Brinkmann model 810-8403-F. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it. Just look at the weight of one of these grids, over 8 pounds of solid stainless each.

  • 304 commercial grade stainless steel
  • Large diameter 5/16” solid stainless rods
  • Dimensions: 19 1/4” x 12 1/2”
  • Made in USA.
  • Sold individually.


Part Number: CLA-GS0190
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 12 1/2”
Material: stainless steel
Weight: 8.0

$77.54

Qty


CG-58P-CI
Click for photos
Cast iron cooking grid for Brinkmann model 810-8403-F. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-58P-CI
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 8.35

$67.49

Qty


==> All Brinkmann Cooking Grids.






810-8403-F Heat Plates

600-7310-T / BMHP1
Click for photos
Stainless steel heat distribution plate for Brinkmann model 810-8403-F.

Part Number: BMHP1 (Replaces Brinkmann 600-7310-T)
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 0.7

$21.09

Qty


CLA-TS0156-X3
Click for photos
SET OF THREE/3 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-8403-F. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X3
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.1

$58.37

Qty


CLA-TS0156-X4
Click for photos
SET OF FOUR/4 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-8403-F. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X4
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.8

$74.78

Qty


==> All Brinkmann Heat Plates.






810-8403-F Igniter Components

600-8401-B / IG-22B
Click for photos
Collector box with ceramic electrode and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-22B (Replaces Brinkmann 600-8401-B)
Weight: 0.3

$14.68

Qty


==> All Brinkmann Igniter Components.






810-8403-F Heat indicators and Meat Thermometers

072-7310-0 / 22551
Click for photos
Oval lid heat indicator. Three-hole mount with two threaded studs 1 1/2” offset on center. Requires 3/8” center hole for temperature sensor probe.

Part Number: 22551 (Replaces Brinkmann 072-7310-0)
Dimensions: 2 15/16” x 1 7/8”
Weight: 0.2

$14.41

Qty


==> All Brinkmann Heat indicators and Meat Thermometers.






810-8403-F Accessories

BP-5
Wundersmoke Mesquite Chips. These unique mesquite wood smoking chips add distinctive flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-5
Weight: 1.0

$9.75

Qty


BB-5
Click for photos
Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

$8.84

Qty


VTC-B
Click for photos
Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

$4.93

Qty


==> All 810-8403-F Accessories.
