Brinkmann Pro Series 2400 810-2400-3 Grill Parts

Brinkmann 810-2400-3

Brinkmann Pro Series 2400 Porcelain 3 Burner Gas Grill

Highest quality replacement parts for your Brinkmann Pro Series 2400 810-2400-3 - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-2400-3 owners manual and diagrams

Click the small images on the right to view Brinkmann 810-2400-3 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Brinkmann 810-2400-3-31899469995839-PartsExpS1.gif

Replacement grill parts for the Brinkmann Pro Series 2400 810-2400-3

All of the parts we have for Brinkmann 810-2400-3 are shown on this page. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Brinkmann grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Brinkmann 810-2400-3 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-2400-3 Burners

154-2400-3 / CIT-L

Click for photos

Cast iron burner for Brinkmann model 810-2400-3.

Part Number: CIT-L (Replaces Brinkmann 154-2400-3)
Dimensions: 16 1/4” x 2 3/8”
Material: cast iron
Weight: 4.0

==> All Brinkmann Burners.

810-2400-3 Burner Brackets and Carryovers

600-2400-4 / CLA-MX0048

Click for photos

Main burner support bar bracket. Made in USA.

Part Number: CLA-MX0048 (Replaces Brinkmann 600-2400-4)
Dimensions: 24 1/16
Material: carbon steel
Weight: 1.2

==> All Brinkmann Burner Brackets and Carryovers.

810-2400-3 Cooking Grids

115-2300-0 / CG-58P-CI

Click for photos

Cast iron cooking grid for Brinkmann model 810-2400-3. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-58P-CI (Replaces Brinkmann 115-2300-0)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 8.35

==> All Brinkmann Cooking Grids.

810-2400-3 Heat Plates

CLA-TS0156-X3

Click for photos

SET OF THREE/3 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-2400-3. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X3
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.1

CLA-TS0156-X4

Click for photos

SET OF FOUR/4 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-2400-3. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X4
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.8

600-2400-3 / BMHP1

Click for photos

Stainless steel heat distribution plate for Brinkmann model 810-2400-3.

Part Number: BMHP1 (Replaces Brinkmann 600-2400-3)
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 0.7

==> All Brinkmann Heat Plates.

810-2400-3 Igniter Components

119-4400-5 / TS-IG3007

Click for photos

Push-button electronic igniter with three (3) spade connectors. Comes with sliver or black cap per availability. Needs (1) AA battery (not included); requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG3007 (Replaces Brinkmann 119-4400-5)
Weight: 0.2

==> All Brinkmann Igniter Components.

810-2400-3 Regulators and Hoses

155-7600-0 / HR-4B

Click for photos

Type 1 LP Regulator with 22” Pressure Hose and 3/8” Female Flare Fitting.FITS: Up to 60,000 BTUs

Part Number: HR-4B (Replaces Brinkmann 155-7600-0)
Weight: 0.8

==> All Brinkmann Regulators and Hoses.

810-2400-3 Heat indicators and Meat Thermometers

02351

Click for photos

heat indicator

Part Number: 02351
Dimensions: 2 5/8” x 2 5/8”
Weight: 0.2

==> All Brinkmann Heat indicators and Meat Thermometers.

810-2400-3 Accessories

BP-5

Click for photos

Wundersmoke Mesquite Chips. These unique mesquite wood smoking chips add distinctive flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-5
Weight: 1.0

FS-1

Click for photos

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

00185

Click for photos

Part Number: 00185
Material: stainless
Weight: .3

42055

Click for photos

Deluxe 13” basting mop with hardwood handle and cotton mop head. Great for spreading BBQ sauces, marinades, and glazes on meat and poultry.

Part Number: 42055
Dimensions: 13
Weight: 0.2

RR-2

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

WB-3

Click for photos

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

==> All 810-2400-3 Accessories.
