Amana Igniter Components

Snap In Piezo Ignitor. Fits Weber Genesis Silver A,B,C and Newer Spirit E310 & E320.

Part Number: UP-9B
Weight: 0.2

UP-9B fits this one Amana model:
AM26LP-P

Universal 3 outlet rotary spark generator. Includes knob.

Part Number: UP-8B
Weight: 0.3

Universal push-button piezo igniter. External grounding tab for use as ground or to power a side burner igniter.

Part Number: UP-7B
Weight: 0.3

UP-7B fits this one Amana model:
AM26LP-P

Universal two outlet rotary spark generator. Includes knob and hardware.

Part Number: UP-6B
Weight: 0.3

Universal one outlet rotary spark generator. Includes knob and hardware.

Part Number: UP-5B
Weight: 0.12

Universal push-button igniter. Round male connector. Includes locking nut.

Part Number: UP-4B
Weight: 0.3

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

Part Number: TS-IG4010
Weight: 0.2

TS-IG4010 fits these 4 Amana models:
AM26LP	AM27LP	AM30	SS4

Battery powered push button igniter.

• Has six (6) spade type male connectors.
• Uses 1 AA battery (not supplied)
• Requires 7/8” mounting hole.

Part Number: IGEIB6-B
Weight: 0.3

IGEIB6-B fits these 5 Amana models:
AM30LP	AM33	AM33LP-P	AM33LP	SS5

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

Part Number: IGEIB4-B
Weight: 0.3

IGEIB4-B fits these 4 Amana models:
AM26LP	AM27LP	AM30	SS4

Universal extention wire (male spade end & female round end). For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.25

46” Wire with female spade connectors and square plastic connectors For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

IG-30B fits these 10 Amana models:
AM26LP-P AM26LP	AM27LP AM30	AM30LP AM33	AM33LP-P AM33LP	SS4 SS5

Universal collector box with electrode and wire. Fits most H burners, cast iron and stainless. Mounts to burner using venturi screws. Slotted construction allow universal adjustment of electrode position.

Part Number: IG-15B
Weight: 0.3

Ceramic electrode and 40” wire with female spade connector For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 06730
Material: ceramic
Weight: 0.1

06730 fits these 12 Amana models:
AM26LP-P AM26LP AM27LP	AM30 AM30LP-P AM30LP	AM33 AM33LP-P AM33LP	SF27 SS4 SS5

14” ground wire with female spade connector and eye connectors. For use with 1.5 volt spark generators including 03340 and 03350 For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03620
Weight: 0.1

03620 fits these 10 Amana models:
AM26LP-P AM26LP	AM27LP AM30	AM30LP AM33	AM33LP-P AM33LP	SS4 SS5

Universal battery powered push button ignitor.

• 1.5 volt
• Has five (5) terminals (male spade connector)
• Uses a single AA battery (not included))
• 03610 and 03620 wires are commonly used with this igniter (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 3”
• Some original igniters had an integrated ground wire. Use wire part# 03620 for this purpose.

. For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03380
Dimensions: 3 5/16” x 2”
Weight: 0.7

Universal three-outlet battery powered push button ignitor.

• 1.5 volt
• Has three (3) terminals (male spade connector)
• Uses a single AA battery (not included)
• 03610 and 03620 wires are commonly used with this igniter (not included)
• Requires 7/8” mounting hole

Part Number: 03333
Dimensions: 2 9/16” x 2”
Weight: 0.5

Universal 2 3/4” adaptor wire with a round female end and a male spade end that has a protective cover For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03199C
Weight: 0.05

03199C fits this one Amana model:
AM26LP-P

Universal 2 5/8” adapter wire with female round and male spade connectors. Primarily used when connecting spark generators (ignitors) to electrode wires with unlike connectors. Typically, push-button and rotory piezo spark generators have male round connectors, while battery operated electronic spark generators usually have male spade connectors.

• Can change male round to male spade
• Can change female spade to female round

ALL. For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03198
Weight: 0.05

Universal 6” jumper wire with female spade ends to close off unused pair of outlets in battery-powered spark generator, or use as an adaptor wire. Current supply has plastic protectors on each end, not shown in photo For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03197
Weight: 0.05
