Nexgrill 720-0825 Grill Parts

Nexgrill 720-0825

Highest quality replacement parts for your Nexgrill 720-0825 - Free USA shipping $49 or more* - No Sales Tax*

Nexgrill 720-0825 owners manual and diagrams

Diagrams & owners manual not available for grill model# 720-0825. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement gas grill parts for Nexgrill model: 720-0825

On this page you'll find all of the parts that fit model Nexgrill 720-0825. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Nexgrill grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Nexgrill 720-0825 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Nexgrill model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

720-0825 Burners

CBP10

Click for photos

Stainless Steel tube burner for Nexgrill model 720-0825.

Part Number: CBP10
Dimensions: 14 7/8” x 1”
Material: stainless steel
Weight: .40

==> All Nexgrill Burners.

720-0825 Cooking Grids

CG-63P-CI-X2

Click for photos

Cast iron cooking grids for Nexgrill model 720-0825. SET OF TWO (2) panels.

Porcelain treated, matte finish
Each panel measures 16 15/16” x11 3/4”
Overall dimensions: 16 15/16” x23 1/2”

Part Number: CG-63P-CI-X2
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 11 3/4”
Material: cast iron
Weight: 14.30

CG-63P-CI

Click for photos

Cast iron cooking grid for Nexgrill model 720-0825. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-63P-CI
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 11 3/4”
Material: cast iron
Weight: 7.15

==> All Nexgrill Cooking Grids.

720-0825 Heat Plates

GMNGHP1

Click for photos

Grillmaster Heat Plate for Nexgrill model 720-0825.

Part Number: GMNGHP1
Dimension Front-to-Back: 14 1/4”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 0.81

CLA-TS0157-X3

Click for photos

SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Nexgrill model 720-0825. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.
WARNING: This is the stainless steel version of 97371. The parts have the same dimensions except this version has a ”height” that is 3/16” taller than 97371. Determine if this matters to you and order the part that best replaces your old heat plate.

Part Number: CLA-TS0157-X3
Dimension Front-to-Back: 14 9/16”
Dimension Side-to-Side: 3 1/4”
Material: stainless steel
Weight: 2.16

CLA-TS0157-X4

Click for photos

SET OF FOUR/4 PACK Stainless steel heat plate/Flame Tamer for Nexgrill model 720-0825. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use..
WARNING: This is the stainless steel version of 97371. The parts have the same dimensions except this version has a ”height” that is 3/16” taller than 97371. Determine if this matters to you and order the part that best replaces your old heat plate.

Part Number: CLA-TS0157-X4
Dimension Front-to-Back: 14 9/16”
Dimension Side-to-Side: 3 1/4”
Material: stainless steel
Weight: 2.88

==> All Nexgrill Heat Plates.

720-0825 Igniter Components

IG-46B

Click for photos

Universal extention wire, male spade end & female round end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

IGEIB4-B

Click for photos

Battery powered push button igniter.

Has four (4) spade type male connectors.
Uses 1 AAA battery (not supplied)
Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B
Weight: 0.3

IG-30B

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

IG-48B

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

TS-IG4010

Click for photos

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

03750

Click for photos

20” Ignitor adapter wire with female spade connector and male round connector. Used primarily on Ducane models 7100 and 7200 to extend the wire from the 03758 collector box and electrode to the electronic spark generator (igniter).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03750
Dimensions: 1/16
Weight: 0.05

04432

Click for photos

Electrode with 24.5” wire that has a female spade/flat end. To lengthen the wire use adapter # 03198 and extension wire # 03750.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04432
Dimensions: 4”
Material: ceramic
Weight: 0.1

==> All Nexgrill Igniter Components.

720-0825 Heat indicators and Meat Thermometers

00012

Click for photos

Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.

Requires minimum 3/8” mounting hole
Single 1 3/8” probe
Threaded portion of probe stops at 1/2” from base
See photo for details

Part Number: 00012
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

==> All Nexgrill Heat indicators and Meat Thermometers.

720-0825 Accessories

SSST

Click for photos

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.

Part Number: SSST
Material: stainless steel
Weight: 1.5

00030

Click for photos

EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

WB-1

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

==> All 720-0825 Accessories.
