Charbroil Commercial 466248208 Grill Parts

Charbroil logo



Charbroil 466248208

Char-Broil Commercial Series 4-Burner LP gas grill with side burner



Highest quality replacement parts for your Charbroil Commercial 466248208 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 466248208 owners manual and diagrams
Click the small images on the right to view Charbroil 466248208 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Charbroil 466248208-463346149130-PartsExpS1.jpg

Replacement grill parts to fit Charbroil Commercial 466248208
This page shows all of the parts we know fit model Charbroil 466248208. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 466248208 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



466248208 Burners

80013421 / 15591
Click for photos
Stainless steel burner for Charbroil model 466248208. Includes screw in venturi for adjusting air flow.

Part Number: 15591 (Replaces Charbroil 80013421)
Dimensions: 15 7/8” x 1”
Material: stainless steel
Weight: 0.8

$34.77

Qty


==> All Charbroil Burners.






466248208 Burner Brackets and Carryovers

80006583 / CBCO1
Click for photos
Stainless steel cross over tube. Channels gas between burners.

Part Number: CBCO1 (Replaces Charbroil 80006583)
Dimensions: 7
Material: stainless steel
Weight: 0.05

$15.90

Qty


==> All Charbroil Burner Brackets and Carryovers.






466248208 Cooking Grids

CG-100PCI-X3
Click for photos
Cast iron cooking grids for Charbroil model 466248208. SET OF THREE (3) panels.
  • Porcelain treated, matte finish
  • Each panel measures 18 1/8” x 10”
  • Overall dimensions: 18 1/8” x 30”


Part Number: CG-100PCI-X3
Dimension Front-to-Back: 18 1/8”
Dimension Side-to-Side: 30”
Material: cast iron
Weight: 25.2

$126.79

Qty


61134

Cast iron cooking grates for Charbroil model 466248208. SET OF FOUR (4). Porcelain treated, flat matte finish. For some grill models, these cast iron grates sit atop stainless grate such as our part# 5S574.

Each panel measures:
  • 18 5/16” Front-To-Back
  • 7 3/16” Side-To-Side


Part Number: 61134
Dimension Front-to-Back: 18 5/16”
Dimension Side-to-Side: 28 3/4”
Material: matte cast iron
Weight: 22.9

$141.25

Qty


CG-100PCI
Click for photos
Cast Iron Cooking Grid - Charbroil, Kenmore for Charbroil model 466248208.

Part Number: CG-100PCI
Dimension Front-to-Back: 18 1/8”
Dimension Side-to-Side: 10”
Material: cast iron
Weight: 8.40

$49.86

Qty


G507-2300-W1 / CG-91SET
Click for photos
Grate Emitter Housing tray Charbroil with Cooking grid for Charbroil model 466248208.

Part Number: CG-91SET (Replaces Charbroil G507-2300-W1)
Dimension Front-to-Back: 18 3/8”
Dimension Side-to-Side: 7 1/16”
Material: stainless steel
Weight: 4.5

$72.83

Qty


==> All Charbroil Cooking Grids.






466248208 Heat Plates

CLA-TS0141-X4
Click for photos
SET OF FOUR/4 PACK Flame Tamer, stainless steel for Charbroil model 466248208. Made in USA.

NOTE: Sometimes shipped with protective vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0141-X4
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 3.92

$56.88

Qty


80016301 / CBHP2
Click for photos
Stainless steel heat plate/Flame Tamer for Charbroil model 466248208.

Part Number: CBHP2 (Replaces Charbroil 80016301)
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 0.7

$21.87

Qty


==> All Charbroil Heat Plates.






466248208 Igniter Components

04430
Click for photos
Burner mounted electrode for use with 15591 and 15491 burners.
  • 39” wire with female spade connector
  • Includes adapter wire part 03198 for applications needing male spade connector on electrode.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 04430
Material: ceramic
Weight: 0.1

$12.47

Qty


==> All Charbroil Igniter Components.






466248208 Heat indicators and Meat Thermometers

80006666 / 00473
Click for photos
Semi-circular, snap in heat indicator with 2 3/4” heat prob.

Part Number: 00473 (Replaces Charbroil 80006666)
Dimensions: 1 3/4” x 1 3/16”
Material: stainless steel
Weight: 0.1

$14.09

Qty


==> All Charbroil Heat indicators and Meat Thermometers.






466248208 Accessories

40240
Click for photos
16” Stainless Steel Tong/Turner Combination. 16” multi-use tool with red soft grip rubber inserts. Can be used as a turner, tong or both. Manual lock saves on storage space.

Part Number: 40240
Material: chrome steel
Weight: 0.9

$16.60

Qty


WB-8RH
Click for photos
Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2

$9.45

Qty


==> All 466248208 Accessories.
