Charbroil Commercial 465257110 Grill Parts

Stainless steel burner for Charbroil model 465257110.

Part Number: CBP5 (Replaces Charbroil G515-2200-W1)
Dimensions: 15 7/8” x 1”
Material: stainless steel
Weight: 1.0

Grate Emitter Housing tray Charbroil with Cooking grid for Charbroil model 465257110. Includes ONLY TWO PIECES (1) grate emitter housing tray and (1) cooking grid that fits into the tray. Number required varies, check your grill to be sure.

Part Number: CG-90SET
Dimension Front-to-Back: 18 3/8”
Dimension Side-to-Side: 8 11/16”
Material: stainless steel
Weight: 6.1

Infrared slotted stamped stainless steel cooking grid set that features slotted grease drain holes for improved performance for Charbroil model 465257110.

• SET OF TWO (2)
• Each panel measures 18 7/16” x 8 7/8”
• Overall dimensions: 18 7/16” x 17 3/4”

Part Number: CG-97SS-X2 (Replaces Charbroil G515-4700-W1)
Dimension Front-to-Back: 18 7/16”
Dimension Side-to-Side: 17 3/4”
Material: stamped stainless steel
Weight: 5.10

Infrared slotted stamped stainless steel cooking grid set that features slotted grease drain holes for improved performance for Charbroil model 465257110.

• SET OF THREE (3)
• Each panel measures 18 7/16” x 8 7/8”
• Overall dimensions: 18 7/16” x 26 5/8”

Part Number: CG-97SS-X3 (Replaces Charbroil G515-4800-W1)
Dimension Front-to-Back: 18 7/16”
Dimension Side-to-Side: 26 5/8”
Material: stamped stainless steel
Weight: 7.65

SET OF FOUR/4 PACK Flame Tamer, stainless steel for Charbroil model 465257110. Made in USA.

NOTE: Sometimes shipped with protective vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0141-X4
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 3.92

Stainless steel heat plate/Flame Tamer for Charbroil model 465257110.

Part Number: CBHP2 (Replaces Charbroil G501-0008-W1)
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 0.7

Universal 2 3/4” adaptor wire with a round female end and a male spade end that has a protective cover.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03199C
Weight: 0.05

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.

• 1.5 volt
• Has four(4) spark outlets (male spade connector)
• Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03344 (Replaces Charbroil G511-0055-W1)
Dimensions: 2” x 2 1/2”
Weight: 0.5

Electrode, gas collector box, and wire. The connecting wire has a flat female spade connector, which is typically used with electronic (battery operated) ignitors (see Ignition 101 in our help center).

NOTE: This electrode is also sometimes used with push-button or rotary piezo ignitors, such as our part# 03100 and 03120, which have round connectors. When connecting 01472 electrode to ignitors with round connectors, use short wire part# 03199C to convert the electrode wire from a femal spade connector to a female round connector.

Part Number: 01472 (Replaces Charbroil G515-0014-W1)
Material: ceramic
Weight: 0.1

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152 (Replaces Charbroil G515-0017-W1A)
Dimensions: 17 3/4” x 1”
Weight: 0.1

Semi-circular, snap in heat indicator with 2 3/4” heat prob.

Part Number: 00473 (Replaces Charbroil G516-0008-W1)
Dimensions: 1 3/4” x 1 3/16”
Material: stainless steel
Weight: 0.1

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

Stainless steel straight handle grill brush with replaceable head. Brass bristles and scarper. See part# WB-8RH for replacement grill brush heads. 18 1/2” long.
This part is currently out of stock, but more are already on the way and expected to arrive SPRING 23

Part Number: WB-8
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.8
