Charbroil 463631009

Char-Broil LP gas outdoor BBQ grill



Highest quality replacement parts for your Charbroil 463631009 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463631009 owners manual and diagrams
Click the small images on the right to view Charbroil 463631009 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Charbroil 463631009-463535899030-PartsExpS1.jpg

Replacement BBQ grill parts for Charbroil model: 463631009
On this page you'll find all of the parts that fit model Charbroil 463631009. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 463631009 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463631009 Cooking Grids

80009712 / CG-6
Click for photos
Chrome plated cooking grid for Charbroil model 463631009. Made in USA.

Part Number: CG-6 (Replaces Charbroil 80009712)
Dimension Front-to-Back: 13 3/4”
Dimension Side-to-Side: 20”
Material: Chrome steel
Weight: 2.9

$38.50


==> All Charbroil Cooking Grids.






463631009 Heat Plates

80008387 / 96301
Click for photos
Porcelain steel Flavor Activator for Charbroil model 463631009. Sold individually.

Part Number: 96301 (Replaces Charbroil 80008387)
Dimension Front-to-Back: 16 13/16”
Dimension Side-to-Side: 6 1/8”
Material: porcelain steel
Weight: 1.5

$28.00


==> All Charbroil Heat Plates.






463631009 Igniter Components

IG-46B
Click for photos
Universal 2 1/2” adaptor wire with a round female end and a male spade end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

$4.30


80008322 / UP-4B
Click for photos
Universal push-button igniter. Round male connector. Includes locking nut. Color can varies gray or black by manufacturer.

For more information about ignition systems and components, please see article Ignition 101 in our help center.


This part is currently out of stock, but more are already on the way and expected to arrive late May

Part Number: UP-4B (Replaces Charbroil 80008322)
Weight: 0.3

$6.98


03080
Click for photos
Electrode, collector box with connector wire that has a female spade end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03080
Material: ceramic
Weight: 0.05

$9.25


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$8.29


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.35


==> All Charbroil Igniter Components.






463631009 Heat indicators and Meat Thermometers

11381
Click for photos
Universal four piece mini thermometer set. Great gift idea.
  • 2 calibrated for steak, and 2 for chicken
  • Mini thermometers for testing doneness of individual cuts of meat
  • Silicone bezels for easy removal when hot
  • Always use caution when handling hot objects


Part Number: 11381
Weight: .25

$16.45


==> All Charbroil Heat indicators and Meat Thermometers.






463631009 Accessories

BP-7
Click for photos
Wundersmoke Maple Chips. These unique maple wood smoking chips add distinctive maple wood flavoring to your food. For use will all grills. One 1lb bag. Comes with reusable puck.

Part Number: BP-7
Weight: 1.0

$10.42


SF-1
Click for photos
Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

$15.90


24764
Click for photos
Deluxe non-stick chicken and rib tumble basket. Attaches to rotisserie spit rod.
  • Ideal for cooking pieces of meat or vegetables
  • Self basting, easy to use
  • Locks on spit rod with thumb screw (supplied)
  • 6 1/2” x 10” long


Part Number: 24764
Dimensions: 6 1/2” x 10”
Weight: 1.1

$19.30


41616
Click for photos
Rib & Roast Rack.

Reversible rib rack and roast support. Made of stainless steel with a frame that holds 6 racks of ribs and a roast support for large cuts of meat.



Part Number: 41616
Material: stainless steel
Weight: 0.5

$24.00


BRACT
Click for photos
Stainless Steel Ash Cleaning Tray For Use In Ceramic Kamado Grills

Part Number: BRACT
Weight: 1.0

$32.84


==> All 463631009 Accessories.
