Broil-Mate 786187



Highest quality replacement parts for your Broil-Mate 786187 - Free USA shipping $49 or more* - No Sales Tax*



Broil-Mate 786187 owners manual and diagrams
Click the small images on the right to view Broil-Mate 786187 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Broil-Mate 786187-321381233-PartsExpS1.gif  Broil-Mate 786187-321381233-PartsExpS2.gif  Broil-Mate 786187-321381233-PartsLstS1.gif  Broil-Mate 786187-321381233-PartsLstS2.gif

Replacement BBQ grill parts for Broil-Mate model: 786187
All of the parts we have for Broil-Mate 786187 are shown on this page. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Broil-Mate grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Broil-Mate 786187 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Broil-Mate model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



786187 Burners

22909-104
Click for photos
Genuine OEM Broil-Mate stainless steel Dual-Tube burner for Broil-Mate model 786187. This part has been slightly changed by the manufacturer to include a small bend at the end that does not affect the fit on existing grills that use this part.

Note: The adjustable air shutter on this burner should be set to 1/3 open for LP grills, 2/3 open for natural gas grills. The burner ships with the air shutter set 1/3 open for LP grills.

This burner is the same part as 22909-104NG and 22909-104LP. There is no difference in the parts, 22909-104NG has the air shutter set to 2/3 open for natural gas, 22909-104LP has the air shutter set to 1/3 open for LP.

Part Number: 22909-104
Dimensions: 17 1/8” x 1 1/4”
Material: Stainless steel
Weight: 1.0

$34.10

Qty


Side burner lid IR stainless steel for Broil-Mate model 786187. Sometimes shipped with vinyl peel-off coating; remove before use.

Part Number: 23000-253
Dimensions: 14 1/4” x 11 3/16”
Material: stainless steel
Weight: 1.6

$19.17

Qty


==> All Broil-Mate Burners.






786187 Cooking Grids

22005-181-R
Click for photos
Cast iron cooking grid for Broil-Mate model 786187.
  • Sold individually
  • Number required varies, check your grill
  • Porcelain enameled, glossy finish


Part Number: 22005-181-R
Dimension Front-to-Back: 19 1/16”
Dimension Side-to-Side: 12 1/2”
Material: Cast iron
Weight: 7.5

$59.36

Qty


==> All Broil-Mate Cooking Grids.






786187 Heat Plates

22209-904
Click for photos
Genuine OEM Broil-Mate stainless steel Flav-R-Wave heat plate / Vaporizer for Broil-Mate model 786187. The manufacturer has redesigned this Flav-R-Wave. It is still the functional OEM Broil-Mate replacement part, and it is sometimes marketed as part number 18433.

Part Number: 22209-904
Dimension Front-to-Back: 17 1/2”
Dimension Side-to-Side: 5 7/8”
Material: Stainless steel
Weight: 1.15

$21.50

Qty


==> All Broil-Mate Heat Plates.






786187 Igniter Components

10342-247
Click for photos
Genuine OEM Broil-Mate electronic push-button 4-spade igniter.
  • Uses AAA battery (not included)
  • Requires 3/4” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-247
Weight: 0.5

$18.49

Qty


22205-024
Click for photos
Genuine OEM Broil-Mate rear collector box.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 22205-024
Dimensions: 27 1/8”
Material: stainless steel
Weight: 0.9

$17.31

Qty


22225-014A
Click for photos
Genuine OEM Broil-Mate front collector box, top & bottom combo. Includes top 22215-014 and bottom 22225-014. This part has been redesigned by the manufacturer and is now a little shorter but still fully functional in the original grills. Fits 4-Burner grills.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 22225-014A
Dimensions: 21 5/8
Material: stainless steel
Weight: 1.2

$28.90

Qty


342-C539
Click for photos
Genuine OEM Broil-Mate electrode and wire - rear burner.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 342-C539
Weight: 0.1

$7.75

Qty


10342-T10
Click for photos
Genuine OEM Broil-Mate electrode and wire for side burner.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-T10
Weight: 0.3

$10.01

Qty


==> All Broil-Mate Igniter Components.






786187 Grease Trays

27249-904
Click for photos
Small grease shield used in-between each burner. Four of these replaces one grease shield # 27245-904. Four of these also replaces one grease shield # 22245-901and five of these replaces one grease shield # 27246-904. Refer to your model number and owner's manual. SOLD INDIVIDUALLY

Part Number: 27249-904
Dimensions: 6 1/2” x 6”
Material: stainless steel
Weight: .35

$7.60

Qty


22009-901
Click for photos
Genuine OEM Broil-Mate Porcelain Grease Pan.

Part Number: 22009-901
Dimensions: 6 1/2” x 5 1/8”
Weight: .45

$15.12

Qty


==> All Broil-Mate Grease Trays.






786187 Knobs and Handles

24005-12A
Click for photos
LID-HANDLE BENT 500 430 SS. NOTE: The mounting holes, center to center, are 23 1/2” apart.

Part Number: 24005-12A
Dimensions: 25
Weight: .85

$25.87

Qty


==> All Broil-Mate Knobs and Handles.






786187 Regulators and Hoses

20805-457
Click for photos
Genuine OEM Broil-Mate Gas train - rear burner

Part Number: 20805-457
Weight: 0.3

$23.18

Qty


10111-K45
Click for photos
Genuine OEM Broil-Mate NG gas hose.

Part Number: 10111-K45
Weight: 2.1

$88.71

Qty


==> All Broil-Mate Regulators and Hoses.






786187 Wheels and Castors

10892-25
Click for photos
Genuine OEM Broil-Mate caster, locking.

Part Number: 10892-25
Weight: 0.85

$12.71

Qty


==> All Broil-Mate Wheels and Castors.






786187 Warming Racks

22006-991
Click for photos
Genuine OEM Broil-Mate porcelain coated warming rack.

Part Number: 22006-991
Dimensions: 32 5/8” x 8 1/2”
Material: porcelain steel
Weight: 6.0

$50.08

Qty


==> All Broil-Mate Warming Racks.






786187 Valves, Orifices, and Manifolds

CONTROL ASSEMBLY LP 6V

Special order part. Orders for this part may not ship for 4 to 12 weeks

Part Number: 29005-474
Weight: 1.0

$146.02

Qty


==> All Broil-Mate Valves, Orifices, and Manifolds.






786187 Heat indicators and Meat Thermometers

10571-6
Click for photos
Genuine OEM Broil-Mate Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

$17.77

Qty


==> All Broil-Mate Heat indicators and Meat Thermometers.






786187 Miscellaneous Repair Parts

S21233
Click for photos
Hinge pin clip.

Part Number: S21233
Weight: 0.01

$1.08

Qty


Y-11230
Click for photos
Cotter pin

Part Number: Y-11230
Weight: 0.01

$1.08

Qty


22005-91
Click for photos
Control panel heat shield. One required per grill.

Part Number: 22005-91
Weight: 1.3

$13.06

Qty


S21255
Click for photos
Washer

Part Number: S21255
Weight: 0.01

$1.08

Qty


21039-905
Click for photos
Genuine OEM Broil-Mate caster bracket

Part Number: 21039-905
Dimensions: 22 5/8” x 4 1/2”
Weight: 2.6

$16.60

Qty


==> All Broil-Mate Miscellaneous Repair Parts.






786187 Hardware

Y-11231
Click for photos
LID BUMPER

Part Number: Y-11231
Weight: 0.01

$1.08

Qty


==> All Broil-Mate Hardware.






786187 Cart Parts

21095-445
Click for photos
LOWER BASE SMALL LP 500

Part Number: 21095-445
Weight: 8.8

$48.68

Qty


==> All Broil-Mate Cart Parts.






786187 Accessories

40259
Click for photos
15” Stainless steel tong.
  • Soft comfort grip
  • Locking mechanism


Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14

$9.92

Qty


==> All 786187 Accessories.
