Huntington Patriot 6825-67 Grill Parts

Genuine OEM Huntington stainless steel burner replaces original part number 52904-144 (52904-144LP and 52904-144NG) for Huntington model 6825-67. For LP grills, adjust air shutter to about 1/3 opened and for NG adjust about 2/3 open or more as needed.

Part Number: 52924-144
Dimensions: 15 3/4
Material: stainless steel
Weight: 0.8

Genuine OEM Huntington Side Burner for Huntington model 6825-67. Use air shutter to adjust for LP (less air flow) or natural gas (more air flow).

Part Number: 10390-E10
Weight: 0.4

COOKING GRID CAST IRON 330/440/550 (Sold individually; number required varies, check your grill for Huntington model 6825-67.)

Part Number: 52002-181
Dimension Front-to-Back: 17 3/8”
Dimension Side-to-Side: 12 3/4”
Material: cast iron
Weight: 6.75

Genuine OEM Huntington stainless steel Flav-R-Wave for Huntington model 6825-67.

Part Number: 52209-404
Dimension Front-to-Back: 15 7/8”
Dimension Side-to-Side: 6”
Material: stainless steel
Weight: 1.14

Genuine stainless steel two piece collector box assembly. Consists of both upper and lower pieces.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 52225-014A
Dimensions: 23
Material: stainless steel
Weight: 1.0

Genuine OEM Huntington electronic push-button 3-spade igniter.

• Uses AAA battery (not included)
• .Requires 3/4” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-246
Weight: 0.6

Genuine OEM Huntington electrode with 14 3/8” connector wire that has a spade female end; use with AA or AAA battery powered ignitors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-E13
Weight: 0.05

Genuine OEM Huntington 32” wire for side burner and other applications. Both ends are female spade connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T18
Dimensions: 32
Weight: 0.05

Small grease shield used in-between each burner. Four of these replaces one grease shield # 27245-904. Four of these also replaces one grease shield # 22245-901and five of these replaces one grease shield # 27246-904. Refer to your model number and owner's manual. SOLD INDIVIDUALLY

Part Number: 27249-904
Dimensions: 6 1/2” x 6”
Material: stainless steel
Weight: .35

Grease tray 440; porcelain flatte matte finish.

Part Number: 57055-901
Dimensions: 6 3/4” x 25 7/16”
Material: porcelain steel
Weight: 1.25

GREASE PAN - 330/440/550

Part Number: 52009-901
Dimensions: 5 1/8” x 6 1/2”
Weight: .40

Genuine OEM Huntington Porcelain Grease Pan.

Part Number: 22009-901
Dimensions: 6 1/2” x 5 1/8”
Weight: .45

Broil King 58” Select grill cover 67487. Broil King Select Series covers are crafted from durable and weather resistant PVC / 500 x 300 denier polyester lining. These durable covers feature:

• Hook-and-loop tabs that secure the cover around the grill
• Polyester handles for easy removal
• Hanging loops for convenient storage
• The Broil King brand logo on the front

Exact fit for models:

• Baron 440, 490 Series grills
• Crown 10, 90 Series grills, post model
• Signet 70, 90 Series grills
• Sovereign 20, 40, 70, and 90 Series grills

Dimensions:

• Side-to-Side: 58”
• Height: 46”
• Front-to-Back: 21.5”

Part Number: 67487
Weight: 3.0

Broil King 58” premium grill cover 68487. Broil King premium covers are crafted of durable water resistant PVC with heavy woven 900D polyester backing.

Exact fit for models:

• Baron 440, 490 Series grills
• Crown 10, 90 Series grills, post model
• Signet 70, 90 Series grills
• Sovereign 20, 40, 70, and 90 Series grills

Features:

• Mesh venting for enhanced air flow and moisture resistance
• Hook-and-loop closures for a superior fit
• Blue baseball stitching adds style to the extra-reinforced seams
• Molded rubber handles make the cover easy to remove

Dimensions:

• Side-to-Side: 58”
• Height: 46”
• Front-to-Back: 21.5”

Part Number: 68487
Weight: 5.0

LID-HANDLE BENT 500 430 SS. NOTE: The mounting holes, center to center, are 23 1/2” apart.

Part Number: 24005-12A
Dimensions: 25
Weight: .85

CONTROL KNOB RESIN LRG BLACK -- W/SS BA STRIP

Part Number: 10472-K431
Weight: 0.1

CONTROL KNOB SMALL W/BA STRIP.

• Off position D-Value: 6 o'clock
• Knob diameter: 1 7/8”
• Socket diameter: 5/16”
• Knob shaft: 1/2”

Part Number: 10472-K231
Weight: 0.1

Genuine OEM Huntington NG gas hose.

Part Number: 10111-K45
Weight: 2.1

Rubber castor, 3” w/plate, locking.

Part Number: 10892-23
Weight: 0.66

WARMING RACK 440 PORC (back support rod 25 5/8” and front support rod 26 3/16” warming rack 7 3/8” x 25”).

Part Number: 52005-991
Dimensions: 25 5/8
Weight: 3.3

Genuine OEM Huntington Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

Washer

Part Number: S21255
Weight: 0.01

Hinge pin clip.

Part Number: S21233
Weight: 0.01

SCREW-PHCP 6-32X1/4 TY-F JS500

Part Number: Y-12835
Weight: 1.0

LID BUMPER

Part Number: Y-11231
Weight: 0.01

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
