Patio Master 430 PT430HWB Grill Parts

Patio Master PT430HWB

Patio Master LP gas grill with side burner, Eng code PL1964-3, PL1934-32

Highest quality replacement parts for your Patio Master 430 PT430HWB - Free USA shipping $49 or more* - No Sales Tax*

Patio Master PT430HWB owners manual and diagrams

Click the small images on the right to view Patio Master PT430HWB exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Patio Master PT430HWB-504659FF631-PartsExpS1.gif

Patio Master PT430HWB-504659FF631-PartsExpS2.gif

Patio Master PT430HWB-504659FF631-PartsLstS1.gif

Replacement grill parts for the Patio Master 430 PT430HWB

This page shows all of the parts we know fit model Patio Master PT430HWB. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Patio Master grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Patio Master PT430HWB BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Patio Master model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

PT430HWB Venturis

L-shaped single venturi. Includes all necessary gaskets and screws/nuts.

Part Number: 71111 (Replaces Patio Master 35420110)
Dimensions: 7 1/8” x 4 1/2”
Material: zinc plated steel
Weight: 0.4

35420110 / V-12

Click for photos

Stainless steel corrugated tubing to resist rust and corrosion single venturi. O-Ring seat for positive gas seal. Flexible and adjustable from 8” to 11”. Gasket & screws not included, see part # SHK4, sold individually.

Part Number: V-12 (Replaces Patio Master 35420110)
Dimensions: 11
Material: stainless steel
Weight: .3

SHK4

Click for photos

Single Gasket Kit Economy Burners

Part Number: SHK4
Weight: 0.01

SG-B

Click for photos

Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

==> All Patio Master Venturis.

PT430HWB Cooking Grids

00403262 / CG-31

Click for photos

Chrome plated cooking grid for Patio Master model PT430HWB. Made in USA.

Part Number: CG-31 (Replaces Patio Master 00403262)
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 19 1/2”
Material: Chrome steel
Weight: 2.1

==> All Patio Master Cooking Grids.

PT430HWB Rock/Briquette Grates

BG-25

Click for photos

Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-25
Dimension Front-to-Back: 10”
Dimension Side-to-Side: 18 1/2”
Material: carbon steel
Weight: 3.3

==> All Patio Master Rock/Briquette Grates.

PT430HWB Igniter Components

36110126 / UP-7B

Click for photos

Universal push-button piezo igniter. External grounding tab for use as ground or to power a side burner igniter.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: UP-7B (Replaces Patio Master 36110126)
Weight: 0.3

03750

Click for photos

20” Ignitor adapter wire with female spade connector and male round connector. Used primarily on Ducane models 7100 and 7200 to extend the wire from the 03758 collector box and electrode to the electronic spark generator (igniter).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03750
Dimensions: 1/16
Weight: 0.05

03751

Click for photos

Universal adapter wire with male round and female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03751
Weight: 0.05

IG-46B

Click for photos

Universal 2 1/2” adaptor wire with a round female end and a male spade end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

IG-5B

Click for photos

Tongue style collector box for burner mounted applications. Includes preinstalled electrode with round female connector end and 20” wire. Fits on all of our Deluxe stainless H burners (LB, SB, DLB, DSB) using special mounting bracket on these burners. Will not fit on cast iron burners (see part IG-15B for cast iron burner applications).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-5B
Weight: 0.3

UP-9B

Click for photos

Snap In Piezo Ignitor. Fits Weber Genesis Silver A,B,C and Newer Spirit E310 & E320.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: UP-9B
Weight: 0.2

IG-30B

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

IG-48B

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

==> All Patio Master Igniter Components.

PT430HWB Accessories

45887

Click for photos

Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

BP-7

Click for photos

Wundersmoke Maple Chips. These unique maple wood smoking chips add distinctive maple wood flavoring to your food. For use will all grills. One 1lb bag. Comes with reusable puck.

Part Number: BP-7
Weight: 1.0

SF-1

Click for photos

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

24764

Click for photos

Deluxe non-stick chicken and rib tumble basket. Attaches to rotisserie spit rod.

Ideal for cooking pieces of meat or vegetables
Self basting, easy to use
Locks on spit rod with thumb screw (supplied)
6 1/2” x 10” long

Part Number: 24764
Dimensions: 6 1/2” x 10”
Weight: 1.1

BB-5

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

98130

Click for photos

Porcelain Coated Round Topper.
11” diameter x 2.5” deep porcelain coated wok with stainless steel handles and perforations. Rolled edge for rigidity and safety.

Part Number: 98130
Dimensions: 11
Material: porcelain steel
Weight: 1.0

WB-3

Click for photos

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

==> All PT430HWB Accessories.

BBQ Part Categories

Patio Master grill model PT430HWB - Tuesday, May 12 2026

Return to Patio Master grills main page

More Patio Master grill models we have parts for
PG4150H \| PG415H \| PG415H9 \| PG4202W \| PG430H \| PG430HWB \| PT4150H \| PT415H \| PT415H9 \| PT4202W \| PT430H \| WG4150H \| WT4150H \|

*Orders for Patio Master 430 grill model PT430HWB $49 and over ship free to the lower 48 states.
See shipping policy below for more info.
