Nexgrill 720-0830H Grill Parts

Highest quality replacement parts for your Nexgrill 720-0830H - Free USA shipping $49 or more* - No Sales Tax*

Nexgrill 720-0830H owners manual and diagrams

Diagrams & owners manual not available for grill model# 720-0830H. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts for the Nexgrill model: 720-0830H

All of the parts we have for Nexgrill 720-0830H are shown on this page. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Nexgrill grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Nexgrill 720-0830H BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Nexgrill model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

720-0830H Burners

Click for photos

Stainless steel tube burner for Nexgrill model 720-0830H.

Part Number: 10381
Dimensions: 15” x 1”
Material: stainless steel
Weight: 0.5

==> All Nexgrill Burners.

720-0830H Cooking Grids

Click for photos

Stainless steel cooking grid for Nexgrill model 720-0830H. Sold as a set of two (2).

Part Number: 5S732
Dimension Front-to-Back: 17 3/16”
Dimension Side-to-Side: 26 3/8”
Material: stainless steel clad wire
Weight: 10.3

==> All Nexgrill Cooking Grids.

720-0830H Heat Plates

Click for photos

Nexgrill Heat Tent for Nexgrill model 720-0830H.

Part Number: NGHP3
Dimension Front-to-Back: 14 5/8”
Dimension Side-to-Side: 4 1/4”
Material: stainless steel
Weight: 0.75

==> All Nexgrill Heat Plates.

720-0830H Igniter Components

Click for photos

Universal battery powered push button ignitor.

1.5 volt
Has five (5) terminals (male spade connector)
Uses a single AA battery (not included))
03610 and 03620 wires are commonly used with this igniter (not included)
Requires 7/8” mounting hole
Overall dimensions: 2” x 3 3/8” x 3”
Some original igniters had an integrated ground wire. Use wire part# 03620 for this purpose.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03380
Dimensions: 3 5/16” x 2”
Weight: 0.7

Click for photos

Burner mounted electrode, 33” wire with female spade connector (notice end of connector wire has a 90 degree bend).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04434
Dimensions: 4 3/16” x 1 1/16”
Weight: 0.1

==> All Nexgrill Igniter Components.

720-0830H Grease Trays

Click for photos

Stainless steel grease tray; is pre-assembled and includes 3 mini loaf pans for easy disposal of grease. Replaces OEM # 20002395A0. Made in USA

Part Number: CLA-DS0301
Dimensions: 14 1/8” x 25 1/2”
Material: stainless steel
Weight: 4.55

==> All Nexgrill Grease Trays.

720-0830H Accessories

Click for photos

15” Stainless steel tong.

Soft comfort grip
Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14

==> All 720-0830H Accessories.
