Lynx Professional L42PSFR-1 Grill Parts

LX-30485-CI Cast Iron Burner for the Lynx Professional model grills for Lynx model L42PSFR-1.

Fits 30”, 42”, and 54” Lynx Professional and Lynx Premier Grills. May fit other models.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 30485.

Part Number: LX-30485-CI (Replaces Lynx LX-30485)
Dimensions: 17” x 6 1/8”
Material: cast iron
Weight: 11.25

Burner air shutter for Lynx model L42PSFR-1. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-MS0060
Material: stainless steel
Weight: 0.05

Cast iron burner for Lynx grills with cast brass burners and older DCS models for Lynx model L42PSFR-1.

Part Number: CIDCSLX
Dimensions: 16” x 6 1/4”
Material: cast iron
Weight: 10.0

LX-30018-R Premium quality stainless steel cooking grate for Lynx Professional 30”, 42”, and 54” grills for Lynx model L42PSFR-1.

Fits all L30, L42, L54 models from 2002 through 2014.

• 304 commercial grade stainless steel
• Large diameter 3/8” solid stainless rods
• Made in USA.
• Sold individually.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 30018.

Part Number: LX-30018-R (Replaces Lynx LX-30018)
Dimension Front-to-Back: 21”
Dimension Side-to-Side: 13 1/2”
Material: stainless steel
Weight: 6.0

LX-30019-R Premium quality stainless steel cooking grate for Lynx Professional 42” and 54” grills for Lynx model L42PSFR-1.

Fits all L42 and L54 models from 2002 through 2014.

• 304 commercial grade stainless steel
• Large diameter 3/8” solid stainless rods
• Made in USA.
• Sold individually.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 30019.

Part Number: LX-30019-R (Replaces Lynx LX-30019)
Dimension Front-to-Back: 21”
Dimension Side-to-Side: 12”
Material: stainless steel
Weight: 6.0

LX-80015-R Stainless steel Briquette Tray for 30”, 42” and 54” Lynx Professional Series Grills. Fits all 30”, 42” and 54” Lynx models from 2002 through 2011. May fit other models.

• Holds 35 ceramic briquettes (sold seperately). See part# BQLYX.
• NOTE: See part# LX-80364-R for tray and briquette assembly.

• 30” grill uses two(2) 80015 trays
• 42” grill uses two (2) 80015 trays and one (1) 80033 tray
• 54” grill uses two (2) 80015 trays and two (2) 80033 trays

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 80015.

This part is currently out of stock, but more are already on the way and expected to arrive mid May

Part Number: LX-80015-R (Replaces Lynx LX-80015)
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 12 1/4”
Material: stainless steel
Weight: 3.45

LX-80033-R Stainless Briquette Center Tray for 42” and 54” Lynx Professional Grills.

FIts models: L42R, L42PSR, L42PSFR, L54PSR, L54PSFR. May fit other models.

Uses BQLYX briquettes.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 80033.

Part Number: LX-80033-R (Replaces Lynx LX-80033)
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 1/4”
Material: stainless steel
Weight: 3.45

Heat Plate/ Flame Tamer not known for Lynx model L42PSFR-1. Our parts information for this grill model is incomplete, and we really don't know with certainty which heat plate fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the heat plates we carry for your brand grill. If we don't have the exact fit for your grill, we may have a suitable replacement part. Measure your existing part so you'll know exactly what size is needed.

If you have this grill model and know the number and dimensions of your original heat plates, click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: HP-DUMMY
Weight: 1.0

Ceramic briquette. Briquettes collect heat and radiate it to the food on the cooking grids. They also help prevent flare-ups and keep the flames from actually touching the food allowing for more efficient and uniform heat distribution.

Designed primarily to work in stainless steel trays on Lynx, Alfresco, and other brand grills, these briquettes can be and often are used on any grill with an ordinary grate to support them.

• Individual briquettes measure 2” x 2”
• Set includes 28 ceramic briquettes
• More than one set may be required per grill model

Part Number: BQLYX (Replaces Lynx LX-90053)
Dimensions: 2” x 2”
Material: ceramic
Weight: 4.0

Ceramic briquettes 48 pieces. Fits briquette trays 94751, 92571 and and simular trays. Works in all grills designed for briquettes or lava rock. Each briquette measures 2” x 2” x 3/4".

Part Number: 41648 (Replaces Lynx LX-90053)
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.5

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

5-piece unique tennis oriented utensil set. Constructed of heavy stainless steel with ”tennis grips” on each utensil. Includes yellow tennis ball style salt & pepper shakers, along with spatula, fork and tong.

Makes a nice gift.for tennis-minded folks

Part Number: US10
Weight: 5.00

Deluxe non-stick flat spit basket. Attaches to 3/8” rotisserie rod with adjustable lid to secure food. 16”x7.5”x2”
WARNING: Before ordering, please verify that your rotisserie spit rod can fit through the .48 inch x .48 squared mounting holes. Our spit rod part numbers SR-5, SR-8 and SR-43 do fit.

Part Number: 24785
Dimensions: 7 1/2” x 16”
Weight: 1.5

Deluxe 13” basting mop with hardwood handle and cotton mop head. Great for spreading BBQ sauces, marinades, and glazes on meat and poultry.

Part Number: 42055
Dimensions: 13
Weight: 0.2

Porcelain Coated Square Wok Topper.
12” x 12” x 2” porcelain coated grilling wok with stainless steel handles and perforations. The single draw design improves functionality and rigidity, it also makes it much easier to clean.

Part Number: 98121
Dimensions: 12” x 12”
Material: porcelain steel
Weight: 1.6

Grill Mitt With Neoprene Palm.

16 in. silicone mitt diffuses heat away from the hand and washes easily. Black palm / red colored cuff. Cotton lined.
*One Size Fits Most

Part Number: 90963
Weight: 0.2
