Lynx Professional L36PSR-1 Grill Parts

Lynx logo



Lynx L36PSR-1

Lynx Professional Series 36" Built-in Grill with ProSear Burner and Rotisserie



Highest quality replacement parts for your Lynx Professional L36PSR-1 - Free USA shipping $49 or more* - No Sales Tax*



Lynx L36PSR-1 owners manual and diagrams
Diagrams & owners manual not available for grill model# L36PSR-1. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!




Replacement grill parts for Lynx Professional L36PSR-1
This page shows all of the parts we know fit model Lynx L36PSR-1. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Lynx grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Lynx L36PSR-1 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Lynx model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



L36PSR-1 Burners

LX-11012-CI Cast Iron Burner for Lynx Professional and Lynx Premier model grills for Lynx model L36PSR-1.

Fits L27, L36, L42, L54, LBQ27, LBQ36, LBQ48 Series grills. May fit other models.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx burner part 11012.



Part Number: LX-11012-CI (Replaces Lynx LX-11012)
Dimensions: 17” x 6 3/16”
Material: cast iron
Weight: 10.7

$213.43








L36PSR-1 Cooking Grids

LX-17020-R Grate for Lynx grills for Lynx model L36PSR-1.

Premium quality heavy duty stainless steel cooking grate. Our USA-made premium stainless grates are simply the best obtainable. If you're looking for the best, you've found it.

Fits all 36” and 48” Premier and Professional series grills manufactured by Lynx Grills from 1996 through 2014.

  • 304 commercial grade stainless steel
  • Large diameter 3/8” solid stainless rods
  • Dimension front-to-back: 18 1/2”
  • Dimension side-to-side: 16 1/2”
  • Made in USA.
  • Sold individually.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 17020.



Part Number: LX-17020-R (Replaces Lynx LX-17020)
Dimension Front-to-Back: 18 1/2”
Dimension Side-to-Side: 16 1/2”
Material: stainless steel
Weight: 13.4

$143.99








L36PSR-1 Rock/Briquette Grates

LX-80232-R Stainless steel Briquette Tray for 27” and 36” Lynx Professional Series Grills. Fits all 27” and 36” Lynx models from 2005 through 2010. May fit other models.

  • Retaining clips not included.
  • Holds 28 ceramic briquettes (sold seperately). See part# BQLYX.
  • NOTE: See part# LX-80363-R for tray and briquette assembly.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 80232.



Part Number: LX-80232-R (Replaces Lynx LX-80232)
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 9 11/16”
Material: stainless steel
Weight: 2.9

$89.95


LX-80363-R Stainless steel Briquette Tray and 28 briquettes for 27” and 36” Lynx Professional Series Grills. Fits all 27” and 36” Lynx models from 2005 through 2010. May fit other models.

  • Includes 28 ceramic briquettes. Retaining clips not included.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 80363.



Part Number: LX-80363-R
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 9 11/16”
Material: stainless steel
Weight: 6.9

$132.66








L36PSR-1 Heat Plates

SET OF THREE/3 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Lynx model L36PSR-1. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0215-X3
Dimension Front-to-Back: 14 1/4”
Dimension Side-to-Side:
Material: stainless steel
Weight: 1.8

$66.63








L36PSR-1 Accessories

Ceramic briquette. Briquettes collect heat and radiate it to the food on the cooking grids. They also help prevent flare-ups and keep the flames from actually touching the food allowing for more efficient and uniform heat distribution.

Designed primarily to work in stainless steel trays on Lynx, Alfresco, and other brand grills, these briquettes can be and often are used on any grill with an ordinary grate to support them.

  • Individual briquettes measure 2” x 2”
  • Set includes 28 ceramic briquettes
  • More than one set may be required per grill model


Part Number: BQLYX (Replaces Lynx LX-90053)
Dimensions: 2” x 2”
Material: ceramic
Weight: 4.0

$50.28


Ceramic briquettes 48 pieces. Fits briquette trays 94751, 92571 and and simular trays. Works in all grills designed for briquettes or lava rock. Each briquette measures 2” x 2” x 3/4".

Part Number: 41648 (Replaces Lynx LX-90053)
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.5

$81.05


Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

$24.00

SALE  $27.30

5-piece unique tennis oriented utensil set. Constructed of heavy stainless steel with ”tennis grips” on each utensil. Includes yellow tennis ball style salt & pepper shakers, along with spatula, fork and tong.

Makes a nice gift.for tennis-minded folks



Part Number: US10
Weight: 5.00

$36.78




Part Number: 00185
Material: stainless
Weight: .3

$17.30


Cast iron smoker box with six oblong venting holes. Fill with water-soaked wood chips and add smoke flavor to you food. Designed to release wood smoke.

  • Works with both charcoal and gas grills.
  • Easy to use and refill.
  • Long lasting cast iron.


Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

$27.70


Vertical.Chicken Leg and Wing Rack. Stainless steel.

A convenient stainless wire wing rack, the best way to roast chicken wings and legs on the grill without the hassle of flipping, turning or sticking. For wings and drumsticks.



Part Number: CLWR
Material: stainless steel
Weight: 1.0

$19.95


Stuffed Burger Press

The stuffed burger press is the best way to make gourmet stuffed and regular burger patties right at home. Easy to disassemble and clean.



Part Number: 24795
Weight: .3

$13.25
