Lynx Professional L27R-2 Grill Parts

Cast iron burner for Lynx grills with cast brass burners and older DCS models for Lynx model L27R-2.

Part Number: CIDCSLX
Dimensions: 16” x 6 1/4”
Material: cast iron
Weight: 10.0

Burner air shutter for Lynx model L27R-2. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-MS0060
Material: stainless steel
Weight: 0.05

LX-17012-R Grate for Lynx grills for Lynx model L27R-2.

Premium quality heavy duty stainless steel cooking grate. Our USA-made premium stainless grates are simply the best obtainable. If you're looking for the best, you've found it.

Fits all 27” and 48” Premier and Professional series grills manufactured by Lynx Grills from 1996 through 2014..

• Polished 304 commercial grade stainless steel
• Large diameter 3/8” solid stainless rods
• Dimension front-to-back: 18 1/2”
• Dimension side-to-side: 12”
• Made in USA.
• Sold individually.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 17012.

Part Number: LX-17012-R (Replaces Lynx LX-17012)
Dimension Front-to-Back: 18 1/2”
Dimension Side-to-Side: 12”
Material: stainless steel
Weight: 10.2

LX-80542-R Stainless steel Briquette Tray for 2011 and later 27” and 36” Lynx Professional Series Grills. May fit other models

• Retaining clips not included.
• Holds 28 ceramic briquettes (sold seperately). See part# BQLYX.
• NOTE: See part# LX-90165-R for tray and briquette assembly.

NOTE: Not a Lynx branded product. This is an aftermarket part designed to replace original Lynx part 80542.

Part Number: LX-80542-R (Replaces Lynx LX-80542)
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 9 11/16”
Material: stainless steel
Weight: 3.45

Heat Plate/ Flame Tamer not known for Lynx model L27R-2. Our parts information for this grill model is incomplete, and we really don't know with certainty which heat plate fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the heat plates we carry for your brand grill. If we don't have the exact fit for your grill, we may have a suitable replacement part. Measure your existing part so you'll know exactly what size is needed.

If you have this grill model and know the number and dimensions of your original heat plates, click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: HP-DUMMY
Weight: 1.0

Ceramic briquettes for Lynx and Dynasty Grills with 28 briquettes per box.

Part Number: BQLYX (Replaces Lynx LX-90053)
Dimensions: 2” x 2”
Material: ceramic
Weight: 4.0

Ceramic briquettes 48 pieces. Fits briquette trays 94751, 92571 and and simular trays. Works in all grills designed for briquettes or lava rock. Each briquette measures 2” x 2” x 3/4".

Part Number: 41648 (Replaces Lynx LX-90053)
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.5

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Aluminum foil grilling trays. Package of three.

• Heavy duty aluminum foil
• Re-usable
• Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4
