GrillPro 266964 Grill Parts

Highest quality replacement parts for your GrillPro 266964 - Free USA shipping $49 or more* - No Sales Tax*

GrillPro 266964 owners manual and diagrams

Click the small images on the right to view GrillPro 266964 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

GrillPro 266964-443303633-PartsExpS1.gif

GrillPro 266964-443303633-PartsLstS1.gif

Replacement grill parts for the GrillPro model: 266964

All of the parts we have for GrillPro 266964 are shown on this page. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for GrillPro grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct GrillPro 266964 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your GrillPro model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

266964 Burners

Click for photos

Stainless steel burner for GrillPro model 266964.

Part Number: 11061
Dimensions: 18 1/4” x 1 1/4”
Material: stainless steel
Weight: 0.8

SIDE BURNER GPB for GrillPro model 266964.

Part Number: 390-C333
Weight: 1.0

==> All GrillPro Burners.

266964 Cooking Grids

Click for photos

Genuine OEM GrillPro cast iron cooking grid for GrillPro model 266964.

Sold individually
Number required varies, check your grill
Porcelain enameled, glossy finish

Part Number: 225-C320
Dimension Front-to-Back: 19”
Dimension Side-to-Side: 8 3/8”
Material: cast iron
Weight: 4.11

==> All GrillPro Cooking Grids.

266964 Heat Plates

Click for photos

Stainless steel Flav-R-Wave for GrillPro model 266964. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0089
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 5 1/4”
Material: stainless steel
Weight: 0.8

==> All GrillPro Heat Plates.

266964 Igniter Components

Click for photos

Universal battery powered push button ignitor.

1.5 volt
Has five (5) terminals (male spade connector)
Uses a single AA battery (not included))
03610 and 03620 wires are commonly used with this igniter (not included)
Requires 7/8” mounting hole
Overall dimensions: 2” x 3 3/8” x 3”
Some original igniters had an integrated ground wire. Use wire part# 03620 for this purpose.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03380
Dimensions: 3 5/16” x 2”
Weight: 0.7

==> All GrillPro Igniter Components.

266964 Knobs and Handles

HANDLESEAT LEFT GPB

Part Number: 338-C310
Weight: 1.0

HANDLESEAT RIGHT GPB

Part Number: 338-C311
Weight: 1.0

Click for photos

Universal control knobs, set of two knobs, includes eight (8) shaft inserts to accomodate valve stem diameters of approximately 5/6” and 1/4”.

Off position D-Value: 12 or 6 or 3 or 9 o'clock
Knob diameter: 2 3/16”
Insert socket diameters: 8.25mm (.32”) and 6.10mm (.24”)
Knob shaft: Flat or 1”

Part Number: 25960
Weight: 0.20

==> All GrillPro Knobs and Handles.

266964 Warming Racks

Click for photos

Genuine OEM GrillPro warming rack

Part Number: 225-C430
Weight: 2.4

==> All GrillPro Warming Racks.

266964 Valves, Orifices, and Manifolds

Side burner valve.

Part Number: 440-C335
Weight: 1.0

==> All GrillPro Valves, Orifices, and Manifolds.

266964 Heat indicators and Meat Thermometers

Click for photos

Genuine OEM GrillPro Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

==> All GrillPro Heat indicators and Meat Thermometers.

266964 Miscellaneous Repair Parts

Click for photos

WIND SHIELD REAR BURNER GPB

Part Number: 393-C441
Weight: 0.11

==> All GrillPro Miscellaneous Repair Parts.

266964 Accessories

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Click for photos

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

Click for photos

Aluminum foil grilling trays. Package of three.

Heavy duty aluminum foil
Re-usable
Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

==> All 266964 Accessories.
