Grill Zone 810-6410-T Grill Parts

Grill Zone 6410 4-Burner LP gas grill with side burner

Highest quality replacement parts for your Grill Zone 810-6410-T - Free USA shipping $49 or more* - No Sales Tax*

Grill Zone 810-6410-T owners manual and diagrams

Click the small images on the right to view Grill Zone 810-6410-T exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Grill Zone 810-6410-T-31899368999839-PartsExpS1.gif

Grill Zone 810-6410-T-31899368999839-PartsLstS1.gif

Replacement grill parts for Grill Zone model: 810-6410-T

On this page you'll find all of the parts that fit model Grill Zone 810-6410-T. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Grill Zone grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Grill Zone 810-6410-T BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Grill Zone model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-6410-T Burners

Click for photos

Cast iron burner for Grill Zone model 810-6410-T.

Part Number: CIT-L (Replaces Grill Zone 154-4400-5)
Dimensions: 16 1/4” x 2 3/8”
Material: cast iron
Weight: 4.0

==> All Grill Zone Burners.

810-6410-T Cooking Grids

Click for photos

Cast iron cooking grids for Grill Zone model 810-6410-T. SET OF FOUR (4).

Porcelain treated, matte finish
4 panels, each 17 5/8” x 8 3/4”
Total width: 35”

Part Number: CG-73P-CI-X4 (Replaces Grill Zone 115-4400-0)
Dimension Front-to-Back: 17 5/8”
Dimension Side-to-Side: 35”
Material: cast iron
Weight: 22.20

==> All Grill Zone Cooking Grids.

810-6410-T Heat Plates

Heat Plate/ Flame Tamer not known for Grill Zone model 810-6410-T. Our parts information for this grill model is incomplete, and we really don't know with certainty which heat plate fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the heat plates we carry for your brand grill. If we don't have the exact fit for your grill, we may have a suitable replacement part. Measure your existing part so you'll know exactly what size is needed.

If you have this grill model and know the number and dimensions of your original heat plates, click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: HP-DUMMY
Weight: 1.0

==> All Grill Zone Heat Plates.

810-6410-T Igniter Components

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Click for photos

Collector box with ceramic igniter electrode and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-21B (Replaces Grill Zone 600-7541-B)
Weight: 0.2

==> All Grill Zone Igniter Components.

810-6410-T Knobs and Handles

Click for photos

Black control knob.

Off position D-Value: 12 o'clock
Knob diameter: 2 3/16”
Socket diameter: 8mm (tight fit)
Knob shaft: 3/16”

Part Number: 02500 (Replaces Grill Zone 113-6410-0)
Dimensions: 2 3/16” x 2 3/16”
Material: plastic
Weight: 0.2

==> All Grill Zone Knobs and Handles.

810-6410-T Regulators and Hoses

Click for photos

Type 1 LP Regulator with 22” Pressure Hose and 3/8” Female Flare Fitting.FITS: Up to 60,000 BTUs

Part Number: HR-4B (Replaces Grill Zone 155-7600-0)
Dimensions: 22
Weight: 0.8

==> All Grill Zone Regulators and Hoses.

810-6410-T Accessories

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Click for photos

EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

Click for photos

Aluminum foil grilling trays. Package of three.

Heavy duty aluminum foil
Re-usable
Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

==> All 810-6410-T Accessories.
