Grill Zone 810-6345-T Grill Parts

Grill Zone 6345 3-Burner LP gas grill with side burner

Highest quality replacement parts for your Grill Zone 810-6345-T - Free USA shipping $49 or more* - No Sales Tax*

Grill Zone 810-6345-T owners manual and diagrams

Click the small images on the right to view Grill Zone 810-6345-T exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Grill Zone 810-6345-T-31899356444839-PartsExpS1.gif

Grill Zone 810-6345-T-31899356444839-PartsLstS1.gif

Replacement BBQ grill parts for Grill Zone model: 810-6345-T

All of the parts we have for Grill Zone 810-6345-T are shown on this page. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Grill Zone grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Grill Zone 810-6345-T BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Grill Zone model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-6345-T Burners

Click for photos

stainless steel burner for Grill Zone model 810-6345-T.

Part Number: CTB2
Dimensions: 16 1/4
Material: stainless steel
Weight: 1.0

Click for photos

Adjustable universal front-to-back tube burner with top-ported flame holes for Grill Zone model 810-6345-T. This burner may not work with existing ignition electrodes and back burner cross-overs.

Variable length burner adjusts from 13 1/2” to 17 1/2”.
Includes extra hardware and mounting brackets to accommodate almost all grills.
Comes with complete installation instructions and diagrams.

WARNING: Before ordering this universal burner, please verify that it will work in your grill per the specifications above. If you order this universal burner and it does not work in your grill, please review our Return Policy for ”Ordered Wrong Part.” You will be responsible for all shipping fees.

Part Number: FP-BR1001
Material: stainless steel
Weight: 0.7

==> All Grill Zone Burners.

810-6345-T Burner Brackets and Carryovers

Click for photos

Main burner support bar bracket. Made in USA.

Part Number: CLA-MX0050 (Replaces Grill Zone 600-6349-0)
Dimensions: 23 15/16
Material: carbon steel
Weight: 1.2

==> All Grill Zone Burner Brackets and Carryovers.

810-6345-T Cooking Grids

Click for photos

Cast iron cooking grid for Grill Zone model 810-6345-T. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-58P-CI (Replaces Grill Zone 115-2300-0)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 8.35

==> All Grill Zone Cooking Grids.

810-6345-T Heat Plates

Click for photos

Stainless steel Flame Diffuser for Grill Zone model 810-6345-T.

Part Number: AUHP1
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 5 1/8”
Material: stainless steel
Weight: 1.0

Click for photos

SET OF THREE/3 PACK Stainless steel Flame Tamer for Grill Zone model 810-6345-T. Made in USA

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0186-X3
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 5”
Material: stainless steel
Weight: 2.7

Click for photos

SET OF FOUR/4 PACK Stainless steel Flame Tamer for Grill Zone model 810-6345-T. Made in USA

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0186-X4
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 5”
Material: stainless steel
Weight: 3.6

==> All Grill Zone Heat Plates.

810-6345-T Igniter Components

Click for photos

Battery powered push button igniter.

Has four (4) spade type male connectors.
Uses 1 AAA battery (not supplied)
Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B
Weight: 0.3

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Click for photos

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

==> All Grill Zone Igniter Components.

810-6345-T Accessories

Click for photos

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.

Part Number: SSST
Material: stainless steel
Weight: 1.5

Click for photos

15” Stainless steel tong.

Soft comfort grip
Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14

==> All 810-6345-T Accessories.
