DCS BGB48-BQR (pre 2006) Grill Parts

30639-1-R Smoker burner for DCS model BGB48-BQR (pre 2006).
Stainless steel replacement smoker burner.

Fits DCS BG36, BG48, BGGA36, BGA48, BGB36, and BGB48 Professional Series grills. Replaces original DCS part# 30639-1.

.

Part Number: DCS-30639-1-R1 (Replaces DCS DCS-30639-1)
Dimensions: 18” x 1”
Material: stainless steel
Weight: 1.0

18408-R Tube burner for DCS model BGB48-BQR (pre 2006).
Stainless steel replacement ”U” burner.

Fits BGA36, BGA48, BGB36, BGB48 Professional Series grills by Dynamic Cooking Systems.

• Replaces original DCS part# 18408.
• Premium 304 grade stainless steel
• Sold individually

Part Number: DCS-18408-R (Replaces DCS DCS-18408)
Dimensions: 19 1/4” x 6”
Material: stainless steel
Weight: 3.9

304 Stainless steel 15,000 BTU infrared rotissierie burner for DCS model BGB48-BQR (pre 2006). For use with both liquid propane (LP) and natural gas grills. Orifice not included. Use old orifice or purchase our orifice part# CLA-VL0251 for LP, or part# CLA-VB0246 for natural gas applications.

Dimensions:

• Maximum overall length, including mounting tab on one end: 20 7/8”
• Maximum width: 3 3/8”

Part Number: CLA-BS0250 (Replaces DCS DCS-12021-2)
Dimensions: 3 3/8” x 20”
Material: stainless steel and ceramic
Weight: 3.50

18369-GRID-SS Stainless steel Cooking Grid for DCS model BGB48-BQR (pre 2006). Made for early 36” and 48” DCS grills, these Stainless round rod grids are a perfect replacement for the original channeled grates. Fits BGA36-BQAR, BGA48-BQR Professional Series DCS grills by Dynamic Cooking Systems.

• One grid replaces two 18369 grates.
• Commercial 304 grade stainless steel
• Large 5/16” diameter round stainless rods
• Measures 20 1/2” x 10 3/8”
• Sold individually

Part Number: 18369-GRID-SS (Replaces DCS DCS-18369)
Dimension Front-to-Back: 20 1/2”
Dimension Side-to-Side: 10 3/8”
Material: stainless steel
Weight: 10.2

18369-GRID-PC Porcelain coated steel cooking grid for DCS model BGB48-BQR (pre 2006). Made for early 36” and 48” DCS grills, these Stainless round rod grids are a perfect replacement for the original channeled grates. Fits BGA36-BQAR, BGA48-BQR Professional Series DCS grills by Dynamic Cooking Systems.

• One grid replaces two 18369 grates.
• Large 5/16” diameter round rods
• Measures 20 1/2” x 10 7/16”
• Sold individually

Part Number: 18369-GRID-PC
Dimension Front-to-Back: 20 1/2”
Dimension Side-to-Side: 10 7/16”
Material: porcelain steel
Weight: 10.11

32291-02-R Radiant Assembly BGA/BGB or RADIANT>
Stainless steel Housing Radiant housing/Tray assembly. Fits BGA27, BGA36, BGA48, BGB36, and BGB48 Professional Series grills grills by Fisher & Paykel.

Includes:
• 32264-01 Radiant Cap
• 32218-02 Radiant

• Replaces factory part# 32291-02
• Premium grade 304 stainless steel
• Holds 18 ceramic rods (not included)
• Sold individually

NOTE: Part# 32291-02 is shown on some BGA27 models as the Radiant only, not an assembly, but is the same.

Part Number: DCS-32291-02-R (Replaces DCS DCS-32291-02)
Dimensions: 18 5/8” x 9 7/8”
Material: stainless steel
Weight: 3.3

32224-R Ceramic Radiant Rods. Sometimes called CERAMIC ROD 9.50 (PKD).
Ceramic rods for radiant tray. 18 count. Fits many DCS Professional Series grills by Dynamic Cooking Systems.

• Replaces factory part# 32224
• Round ceramic rods are 9.5” long and 9/16” in diameter
• Sold as a package of 18 rods

Also available in a package of three. See part# CLA-MC0357.

Part Number: DCS-32224-R (Replaces DCS DCS-32224)
Dimensions: 9 1/2” x 9/16”
Material: ceramic
Weight: 2.3

Ceramic radiant rods, package of three.

Part Number: CLA-MC0357
Dimensions: 9 1/2” x 9/16”
Material: ceramic
Weight: 0.6

Gas collector box assembly. Includes collector box, ceramic electrode, and wire. Fits both left and right hand side.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-33B (Replaces DCS DCS-32801)
Weight: .05

Type 1 LP Regulator with 22” Pressure Hose and 3/8” Female Flare Fitting.FITS: Up to 60,000 BTUs

Part Number: HR-4B (Replaces DCS DCS-13230)
Dimensions: 22
Weight: 0.8

Brass valve for DCS.

• For LP and natural gas grills (see below)
• Off position D-Value: 12 o'clock
• Stem diameter: 8mm
• Orifice not included

NOTE: There is a set screw in the stem that allows this valve to be used in both LP or natural gas grills. The valve is shipped with the screw set in LP position. Turn the screw counterclockwise about seven turns for natural gas use.

Part Number: 30171 (Replaces DCS DCS-13017-01)
Dimensions: 3 7/16” x 1 5/16”
Material: brass
Weight: 0.3

#55 orifice for infrared burners use on natural Gas grills. Includes brass elbow with 1/4” compression fitting.

Part Number: CLA-VB0246
Dimensions: 3 3/8” x 17 1/4”
Material: stainless steel and ceramic
Weight: 0.3

#59 brass orifice for rotisserie burner. Fits liquid propane (LP) gas grills. Includes brass elbow with 1/4” compression fitting.

Part Number: CLA-VL0251
Material: brass
Weight: 0.15

32957-R Chip Tray.
Stainless steel wood chip tray for smoker.

Fits DCS BGA36, BGA48, BGB36 and BGB48 Professional Series grills. Replaces original DCS part# 32957.

.


Part Number: DCS-32957-R (Replaces DCS DCS-32957)
Material: stainless steel
Weight: 0.40

Wundersmoke Maple Chips. These unique maple wood smoking chips add distinctive maple wood flavoring to your food. For use will all grills. One 1lb bag. Comes with reusable puck.

Part Number: BP-7
Weight: 1.0

15” Stainless steel tong.

• Soft comfort grip
• Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14

EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

Stainless steel chicken roaster. Commonly called Beer Can roasters.

• The best way to roast poultry on the grill
• For use in barbecues and ovens
• Dishwasher safe
• Includes rack, rack support, and basting brush

Part Number: 41333
Material: stainless steel
Weight: 0.10
