Kitchen Aid 720-0954G Grill Parts

Stainless steel cooking grids for Kitchen Aid model 720-0954G. Sold as a set of three (3).

Part Number: 5S773
Dimension Front-to-Back: 18 13/16”
Dimension Side-to-Side: 26 5/8”
Material: stainless steel wire
Weight: 14.3

Stainless steel Flame Tamer for Kitchen Aid model 720-0954G.


Part Number: NGHP2
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 1.0

SET OF FOUR/4 PACK Stainless steel heat plate/Flame Tamer for Kitchen Aid model 720-0954G. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0158-X4
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 3.08

SET OF FIVE/5 PACK Stainless steel heat plate/Flame Tamer for Kitchen Aid model 720-0954G. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0158-X5
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 3.85

Porcelain steel Flame Tamer for Kitchen Aid model 720-0954G. Sold individually.

Part Number: 90731
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: porcelain steel
Weight: 1.0

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger switch.

Note: Some original ignitors (spark generators) that 03352 replaces had an integrated/built-in ground wire which is not present on this part (03352). If the ignitor you are replacing has an integrated/built-in ground wire, you will also need our ground wire part 03621. Inspect your system.

• 1.5 volt
• Has five (5) spark outlets (male spade connector)
• Has two (2) male spade connectors for the button/trigger switch part 03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 2 5/8”

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/trigger switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03352
Dimensions: 3 3/8” x 2”
Weight: 0.7

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.

• 1.5 volt
• Has six (6) spark outlets (male spade connector)
• Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 2 5/8”

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03356
Dimensions: 3 3/8” x 2”
Weight: 0.7

Ground wire required when replacing spark generator for a valve-triggered electrode with a remote switch-triggered spark generator. 03621 plugs into one switch inlet; ring connects to generator neck; switch wire plugs into the other generator switch inlet

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03621
Dimensions: 1 1/8” x 1 1/8”
Weight: 0.1

electrode with connection

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04436
Material: ceramic
Weight: 1.0

Round heat indicator. Single probe. Requires 13/16” mounting hole.

Part Number: 00745
Dimensions: 3 1/8” x 3 1/8”
Weight: 0.3

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

15” Stainless steel tong.

• Soft comfort grip
• Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14
