Bull Outdoor Colt 24010 Grill Parts

Left stainless steel burner with electrode mounting bracket for Bull Outdoor model 24010. Fits all Straubelstone Steelman 24” and 36” grills.

Part Number: 162L1 (Replaces Bull Outdoor Q24-QB-L)
Dimensions: 15” x 7”
Material: stainless steel
Weight: 1.4

Right stainless steel burner with electrode mounting bracket for Bull Outdoor model 24010. Fits all Straubelstone Steelman 24” and 36” grills.

Part Number: 162R1 (Replaces Bull Outdoor Q24-QB-R)
Dimensions: 15” x 7”
Material: stainless steel
Weight: 1.4

Porcelain steel cooking grids for Bull Outdoor model 24010. Porcelain enameled, glossy finish. Sold as a set of two (2).

Part Number: 56202
Dimension Front-to-Back: 15 5/8”
Dimension Side-to-Side: 23 1/2”
Material: porcelain steel wire
Weight: 11.0

One piece stainless burner plate for Bull Outdoor model 24010.

Part Number: 96201 (Replaces Bull Outdoor Q24-BPS-2414)
Dimension Front-to-Back: 13 15/16”
Dimension Side-to-Side: 23 3/8”
Material: stainless steel
Weight: 4.5

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Battery powered push button igniter.

• Has two (2) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB2-B (Replaces Bull Outdoor Q24-CP-EI15)
Weight: 0.3

Burner mounted electrode kit for Straubelstone left burner 162L1.

• Electrode with ceramic insulator
• Mounting bracket with nut and bolt
• 16” wire with female spade connector
• Protective sleeve

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 06300 (Replaces Bull Outdoor Q24-IE-L)
Material: ceramic
Weight: 0.1

Burner mounted electrode kit for Straubelstone right burner 162R1.

• Electrode with ceramic insulator
• Mounting bracket with nut and bolt
• 16” wire with female spade connector
• Protective sleeve

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 06200 (Replaces Bull Outdoor Q24-IE-R)
Material: ceramic
Weight: 0.1

Push-button electronic igniter with two (2) spade connectors. Black cap. 1 AAA battery (not included).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG2006
Weight: 0.2

Universal premium quality stainless steel warming rack. You simply can't buy a better quality warming rack than this, which weighs in at almost 5lbs of solid 304 grade stainless steel. This super heavy-duty warming rack was made to replace the porcelain coated steel racks found on BBQ grills made by The Great Outdoors Grill Company, but can be used in many other different grills.

• Far superior to the original porcelain coated steel rack
• Rests on your existing cooking grids.
• Solid 1/4” 304 stainless steel rods.
• Stands 3.75 inches tall.
• Made in USA.

WARNING: Before ordering this universal rack, please verify your grill has enough space to accommodate it. If you need to return, you will be responsible for return shipping, and the original out bound shipping fee will be deducted from the refund. What's required?

• Your grill needs to be at least 24” wide on the inside . The warming rack is 6.25” front to back and stands 3.75” tall.
• Notice the shape of the warming rack. Determine if the lid of your grill can easily close with the warming rack inside along with food placed on top of the rack.

  Part Number: CLA-WS0040
  Dimensions: 6 1/4” x 22 7/8”
  Material: stainless steel
  Weight: 4.8

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
