Viking VGBQ300-2RT Grill Parts

PA080050-R2 U-Burner with Drip Shield for Viking model VGBQ300-2RT. Deluxe center-fed U burner.

• 304 commercial grade stainless steel.
• Includes Stainless Drip Shield B2004921-R2 (installed).
• Includes front and rear mounting brackets.

NOTE: This part is also available in more economical multipacks of two, three, and four pieces.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking burner PA080050 and Drip Shield B2004921.

Part Number: VIK-PA080050-R2 (Replaces Viking VIK-PA080050)
Dimensions: 21 3/4” x 6 3/4”
Material: stainless steel
Weight: 4.7

PA080051-R2-X2 Stainless steel Smoker/Grill Burners with Drip Shields for Viking model VGBQ300-2RT. SET OF TWO (2).

• Made of 304 commercial grade stainless steel.
• Includes SS Drip Shields B2005324-R (attached).
• Includes front and rear mounting brackets.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking Smoker Burner part PA080051 and Drip Shield part B2005324.

Part Number: VIK-PA080051-R2-X2 (Replaces Viking VIK-PA080051-X2)
Dimensions: 24
Material: stainless steel
Weight: 4.0

PA080051-R2 Stainless steel Smoker/Grill Burner with Drip Shield for Viking model VGBQ300-2RT..

• Made of 304 commercial grade stainless steel.
• Includes SS Drip Shield B2005324-R (attached).
• Includes front and rear mounting brackets.

NOTE: This part is also available in a 2-pack.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking Smoker Burner part PA080051 and Drip Shield part B2005324.

Part Number: VIK-PA080051-R2 (Replaces Viking VIK-PA080051)
Dimensions: 24
Material: stainless steel
Weight: 2.0

PA060052-R Porcelain Steel Cooking Grates for Viking model VGBQ300-2RT. Heavy duty grates with solid 5/16” rods. Porcelain enameled, glossy finish. Also known in Viking documentation as ”Full Grill Grate”, this grate fits numerous Viking grills. See part PA060068-R for a stainless version.

Each panel measures:

• 23 1/4” front-to-back
• 11 1/2” side-to-side
• Solid steel 5/16” rods

NOTE: Also available in more economical 2-packs, 3-packs, and 4-packs.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking grate part PA060052.

Part Number: VIK-PA060052-R (Replaces Viking VIK-PA060052)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 11 1/2”
Material: porcelain steel wire
Weight: 8.3

PA060068-R Premium quality heavy duty stainless steel cooking grate for Viking model VGBQ300-2RT. Also known in Viking documentation as ”FULL GRATE *SS*”, this grate fits numerous Viking grills. It is the stainless version of PA060052.

• Made in USA
• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods
• Sold individually.

Each panel measures:

• 23 1/4” front-to-back
• 11 1/2” side-to-side

NOTE: Also available in 2-packs, 3-packs, and 4-packs.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking grate part PA060068.

Part Number: VIK-PA060068-R (Replaces Viking VIK-PA060068)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 11 1/2”
Material: stainless steel
Weight: 8.6

PA060053-R-X2 Porcelain Steel Cooking Grates for Viking model VGBQ300-2RT. SET OF TWO (2) heavy duty grates with solid 5/16” rods. Porcelain enameled, glossy finish. Also known in Viking documentation as ”1/2 Grill Grate” or ”HALF GRILL GRATE”, this grate fits numerous Viking grills.

Each panel measures:

• 23 1/4” front-to-back
• 5 3/4” side-to-side

2-Piece set measures:

• 23 1/4” front-to-back
• 11 1/2” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking grate part PA060053.

Part Number: VIK-PA060053-R-X2 (Replaces Viking VIK-PA060053-X2)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 11 1/2”
Material: porcelain steel wire
Weight: 8.2

PA060053-R Porcelain Steel Cooking Grates for Viking model VGBQ300-2RT. Heavy duty grates with solid 5/16” rods. Porcelain enameled, glossy finish. Also known in Viking documentation as ”1/2 Grill Grate” or ”HALF GRILL GRATE”, this grate fits numerous Viking grills.

Each panel measures:

• 23 1/4” front-to-back
• 5 3/4” side-to-side

NOTE: Also available in more economical 2-packs..

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking grate part PA060053.

Part Number: VIK-PA060053-R (Replaces Viking VIK-PA060053)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 5 3/4”
Material: porcelain steel wire
Weight: 4.1

PA060069-R-X2 Premium quality heavy duty stainless steel cooking grates for Viking model VGBQ300-2RT. SET OF TWO (2). Also known in Viking documentation as ”Half Grate SS*”, this grate fits numerous Viking grills. It is the stainless version of PA060053. It is usually used with one or more PA060068 panels.

• Made in USA
• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods

Each panel measures:

• 23 1/4” front-to-back
• 5 3/4” side-to-side

2-Piece set measures:

• 23 1/4” front-to-back
• 11 1/2” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking grate part PA060069.

Part Number: VIK-PA060069-R-X2 (Replaces Viking VIK-PA060069-X2)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 11 1/2”
Material: stainless steel
Weight: 8.8

PA060069-R Premium quality heavy duty stainless steel cooking grate for Viking model VGBQ300-2RT. Also known in Viking documentation as ”Half Grate SS”, this grate fits numerous Viking grills. It is the stainless version of PA060052. It is usually used in pairs with one or more PA060068 panels

• Made in USA
• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods
• Sold individually.

Each panel measures:

• 23 1/4” front-to-back
• 5 3/4” side-to-side

NOTE: Also available in a more economical 2-pack..

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking grate part PA060069.

Part Number: VIK-PA060069-R (Replaces Viking VIK-PA060069)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 5 3/4”
Material: stainless steel
Weight: 4.4

E12G-SET Cast Iron Cooking Grates for Viking model VGBQ300-2RT. Complete SET OF THREE (3) panels for Viking 30” and 41” grills with side burners. Porcelain treated, flat matte finish.

Set includes:

• One (1) 002369-000-R ”FULL” grate
  Panel measures:
  • 23 1/4” front-to-back
  • 11 3/8” side-to-side

• Two (2) 002370-000-R ”HALF” grates
  Each panel measures:
  • 23 1/4” front-to-back
  • 5 3/4” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate parts 002369-000 and 002370-000.

Part Number: VIK-E12G-SET
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 22 7/8”
Material: cast iron
Weight: 19.7

PS2TG-SET Porcelain steel Cooking Grates for Viking model VGBQ300-2RT. Complete SET OF THREE (3) panels for Viking 30” and 41” grills with side burners.

• Porcelain enameled, glossy finish
• Large diameter 5/16” solid steel rods

Set includes:

• One (1) PA060052-R ”FULL” grate
  Panel measures:
  • 23 1/4” front-to-back
  • 11 1/2” side-to--side

• Two (2) PA060053-R ”HALF” grates
  Each panel measures:
  • 23 1/4” front-to-back
  • 5 3/4” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate parts PA060052 and PA060052.

Part Number: VIK-PS2TG-SET (Replaces Viking VIK-PS2-SET)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 23”
Material: porcelain steel
Weight: 16.5

SS2TG-SET Stainless steel Cooking Grates for Viking model VGBQ300-2RT. Complete SET OF THREE (3) panels for Viking 30” and 41” grills with side burners.

• Made in USA
• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods

Set includes:

• One (1) PA060068-R ”FULL” grate
  Panel measures:
  • 23 1/4” front-to-back
  • 11 1/2” side-to--side

• Two (2) PA060069-R ”HALF” grates
  Each panel measures:
  • 23 1/4” front-to-back
  • 5 3/4” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate parts PA060068 and PA060069.

Part Number: VIK-SS2TG-SET
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 23”
Material: stainless steel
Weight: 17.4

PK010061-R2-X2 Flavor Grids for Viking model VGBQ300-2RT. Set of Two (2). Fits Viking VGBQ/VGIQ E and T series grills. May fit other models.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking Flavor Grid part PK010061.

Part Number: VIK-PK010061-R2-X2 (Replaces Viking VIK-PK010061-X2)
Dimension Front-to-Back: 23 1/8”
Dimension Side-to-Side: 5 3/4”
Material: stainless steel
Weight: 5.4

PK010061-R2 Flavor Grid for Viking model VGBQ300-2RT. Fits Viking VGBQ/VGIQ E and T series grills. May fit other models.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking Flavor Grid part PK010061.

Part Number: VIK-PK010061-R2 (Replaces Viking VIK-PK010061)
Dimension Front-to-Back: 23 1/8”
Dimension Side-to-Side: 5 3/4”
Material: stainless steel
Weight: 2.7

008091-000-R-X2 SET OF TWO (2) Electrodes with m spade wide connection. Also known in Viking documentation as ”PB040288 IGNITOR KIT”. This part replaces: PB040288, PB040179

Includes short adapter wire (not shown) to convert the wide male spade conector on the electrode to a standard male spade connector. This allows the use of wires with standard spade connectors.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking part 008091-000.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: VIK-008091-000-R-X2 (Replaces Viking VIK-008091-000-X2)
Weight: 0.2

008091-000-R Electrode with m spade wide connection. Also known in Viking documentation as ”PB040288 IGNITOR KIT”. This part replaces: PB040288, PB040179

Includes short adapter wire (not shown) to convert the wide male spade conector on the electrode to a standard male spade connector. This allows the use of wires with standard spade connectors.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking part 008091-000.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: VIK-008091-000-R (Replaces Viking VIK-008091-000)
Weight: 0.1

008090-000-R Two prong Electrode. Also known in Viking documentation as ”PB040287 IGNITOR KIT”. This part also replaces parts PB040287, PB040176

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking part 008090-000.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: VIK-008090-000-R (Replaces Viking VIK-008090-000)
Weight: 0.25

20” igniter wire with two (2) female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-18B
Weight: 0.03

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

VIK-PA020036-R Spark Module. 4-Spark electronic ignition module. Requires 1 AA battery (not included).

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking grate part PA020036.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: VIK-PA020036-R (Replaces Viking VIK-PA020036)
Weight: .33

Front and back burner mounting brackets for center-fed stainless U burner part# 15481 and VIKU1. Does not include screws. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-MS0059
Material: stainless steel
Weight: 0.4

Wundersmoke Mesquite Chips. These unique mesquite wood smoking chips add distinctive flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-5
Weight: 1.0

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

Universal 6 piece chrome plated skewer set. Designed so food does not rotate. Great for kabobs! 19 1/2” long.

Part Number: SR-7B
Dimensions: 19 1/2
Material: chrome steel
Weight: 1.0

GrillPro EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

This tank gauge will monitor your propane level, while you grill, and let's you know when you're running low on gas.

The magnetic tank gauge offers fast, accurate propane level monitoring for any size LP tank. The magnetic backing makes it easy to attach, remove, and reuse across multiple tanks—perfect for grilling, camping, patio heaters, and more

Part Number: 00030
Weight: 0.1

Beer Can Chicken Roaster. Stainless steel.

Just place any 12 oz can into the center frame and put your spiced chicken cavity over the can and then put on the grill or oven, Infuses with flavors from various beverage in the can, Like Beer, Juice, Wine, etc. Your chicken will impart a different flavor! After use, the racks can be cleaned easily.

Part Number: CCR
Weight: 1.0

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2
