Viking VGBQ5300-2RE Grill Parts

E12G-SET Cast Iron Cooking Grates for Viking model VGBQ5300-2RE. Complete SET OF THREE (3) panels for Viking 30” and 41” grills with side burners. Porcelain treated, flat matte finish.

Set includes:

• One (1) 002369-000-R ”FULL” grate
  Panel measures:
  • 23 1/4” front-to-back
  • 11 3/8” side-to-side

• Two (2) 002370-000-R ”HALF” grates
  Each panel measures:
  • 23 1/4” front-to-back
  • 5 3/4” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate parts 002369-000 and 002370-000.

Part Number: VIK-E12G-SET
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 22 7/8”
Material: cast iron
Weight: 19.7

PS2TG-SET Porcelain steel Cooking Grates for Viking model VGBQ5300-2RE. Complete SET OF THREE (3) panels for Viking 30” and 41” grills with side burners.

• Porcelain enameled, glossy finish
• Large diameter 5/16” solid steel rods

Set includes:

• One (1) PA060052-R ”FULL” grate
  Panel measures:
  • 23 1/4” front-to-back
  • 11 1/2” side-to--side

• Two (2) PA060053-R ”HALF” grates
  Each panel measures:
  • 23 1/4” front-to-back
  • 5 3/4” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate parts PA060052 and PA060052.

Part Number: VIK-PS2TG-SET (Replaces Viking VIK-PS2-SET)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 23”
Material: porcelain steel
Weight: 16.5

002369-000-R Cast Iron Cooking Grate for Viking model VGBQ5300-2RE. Porcelain treated, flat matte finish. Also known in Viking documentation as ”REDESIGN BBQ GRATE - FULL”, this grate fits numerous Viking grills.

NOTE: Also sold in more economical 2, 3 and 4 packs.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate part 002369-000.

Part Number: VIK-002369-000-R (Replaces Viking VIK-002369-000)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 11 3/8”
Material: cast iron
Weight: 9.3

002370-000-R-X2 Cast Iron Cooking Grate for Viking model VGBQ5300-2RE. Porcelain treated, flat matte finish. Also known in Viking documentation as ”REDESIGN BBQ GRATE - HALF”, this grate fits numerous Viking grills. Usually two (2) of these ”HALF” grates are paired with one or more FULL grates 002369-000.

Each panel measures:

• 23 1/4” front-to-back
• 5 3/4” side-to-side

2-Piece set measures:

• 23 1/4” front-to-back
• 11 1/2” side-to-side

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate part 002370-000.

Part Number: VIK-002370-000-R-X2 (Replaces Viking VIK-002370-000-X2)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 11 1/2”
Material: cast iron
Weight: 10.4

002370-000-R Cast Iron Cooking Grate for Viking model VGBQ5300-2RE. Porcelain treated, flat matte finish. Also known in Viking documentation as ”REDESIGN BBQ GRATE - HALF”, this grate fits numerous Viking grills. Usually two (2) of these ”Half” grates are paired with one or more FULL grates 002369-000.

NOTE: Also sold in more economical 2-packs.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original VIKING grate part 002370-000.

Part Number: VIK-002370-000-R (Replaces Viking VIK-002370-000)
Dimension Front-to-Back: 23 1/4”
Dimension Side-to-Side: 5 3/4”
Material: cast iron
Weight: 5.2

032381-R Briquette Tray with briquettes. Fits Viking Ultra Premium VGBQ and VGIQ series grills. May fit other models.

NOTE: This part is also available in more economical multipacks of six and eight pieces.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking Briquette Tray part 032381.

Part Number: VIK-032381-000-R (Replaces Viking VIK-032377-000)
Dimension Front-to-Back: 21 1/2”
Dimension Side-to-Side: 5 7/16”
Material: stainless steel
Weight: 2.95

Heat Plate/ Flame Tamer not known for Viking model VGBQ5300-2RE. Our parts information for this grill model is incomplete, and we really don't know with certainty which heat plate fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the heat plates we carry for your brand grill. If we don't have the exact fit for your grill, we may have a suitable replacement part. Measure your existing part so you'll know exactly what size is needed.

If you have this grill model and know the number and dimensions of your original heat plates, click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: HP-DUMMY
Weight: 1.0

20” igniter wire with two (2) female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-18B
Weight: 0.03

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

008091-000-R-X2 SET OF TWO (2) Electrodes with m spade wide connection. Also known in Viking documentation as ”PB040288 IGNITOR KIT”. This part replaces: PB040288, PB040179

Includes short adapter wire (not shown) to convert the wide male spade conector on the electrode to a standard male spade connector. This allows the use of wires with standard spade connectors.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking part 008091-000.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: VIK-008091-000-R-X2 (Replaces Viking VIK-008091-000-X2)
Weight: 0.2

008091-000-R Electrode with m spade wide connection. Also known in Viking documentation as ”PB040288 IGNITOR KIT”. This part replaces: PB040288, PB040179

Includes short adapter wire (not shown) to convert the wide male spade conector on the electrode to a standard male spade connector. This allows the use of wires with standard spade connectors.

NOTE: Not a VIKING branded product. This is an aftermarket part designed to replace original Viking part 008091-000.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: VIK-008091-000-R (Replaces Viking VIK-008091-000)
Weight: 0.1

Universal durable battery operated rotisserie motor. Conveniently eliminates the need for electric cords. Runs on 2 D cells (not included).

Part Number: RO-4
Weight: 1.0

Maple wood chips.

• All natural wood smoke flavor
• Great for use in BBQ's or smokers.
• 170 cubic inches (2 lbs. approx) in resealable bag

Try with portk, lamb, poultry, and fish.

Part Number: 00270
Weight: 1.3

Polished stainless steel turner with an ergonomic soft grip grey handle and red accents. Great for flipping burgers or turning delicate fish fillets.

Part Number: 43108
Dimensions: 16
Material: stainless steel
Weight: 0.10

GrillPro ® grid lifter removes both cast and stainless cooking grids.

One set of tines to remove cast and another to remove stainless cooking grids.

Stainless tip, resin handle.

Part Number: 76745
Material: stainless
Weight: .2

Stainless Steel Basting Set.

Measurements inside the stainless steel bowl for accurate sauce preparation. Includes silicone basting brush.

Part Number: 14913
Material: stailess steel
Weight: 0.5

Stuffed Burger Press

The stuffed burger press is the best way to make gourmet stuffed and regular burger patties right at home. Easy to disassemble and clean.

Part Number: 24795
Weight: .3
