Smoke Hollow SH5000 Grill Parts

Smoke Hollow SH5000 Gas/Charcoal Grill with Smoker

Highest quality replacement parts for your Smoke Hollow SH5000 - Free USA shipping $49 or more* - No Sales Tax*

Smoke Hollow SH5000 owners manual and diagrams

Click the small images on the right to view Smoke Hollow SH5000 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Smoke Hollow SH5000-53F499933-PartsExpS1.gif

Smoke Hollow SH5000-53F499933-PartsLstS1.gif

Replacement grill parts to fit Smoke Hollow model: SH5000

This page shows all of the parts we know fit model Smoke Hollow SH5000. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Smoke Hollow grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Smoke Hollow SH5000 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Smoke Hollow model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

SH5000 Burners

47183T-02-R Stainless steel replacement tube burner for Smoke Hollow OEM # 47183T-02 for Smoke Hollow model SH5000. Electrode sold seperately # 04010 or # IG-20B. Includes:

SS tube burner
Electrode mounting bracket
Spider exclusion screen
Adjustable air shutter

Part Number: 47183T-02-R (Replaces Smoke Hollow 47183T-02)
Dimensions: 18 5/16” x 1”
Material: stainless steel
Weight: 0.5

==> All Smoke Hollow Burners.

SH5000 Cooking Grids

Click for photos

47183T-11-R Charcoal and Sear Burner Cooking Grid for Smoke Hollow model SH5000. Fits Smoke Hollow Pro Series grill and smoker units.

Porcelain treated cast iron, flat matte finish
Three (3) required for most models
Sold individually

This part replaces original OEM part# 47183T-11.

Part Number: 47183T-11-R (Replaces Smoke Hollow 47183T-11)
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 10 11/16”
Material: matte cast iron
Weight: 3.8

Click for photos

47183T-12-R Gas Cooking Grid for Smoke Hollow model SH5000. Fits Smoke Hollow Pro Series grill and smoker units.

Porcelain treated cast iron, flat matte finish
Two (2) required for most models
Sold individually

Relaces original OEM part# 47183T-12, which was a glossy porcelain grid.

Part Number: 47183T-12-R (Replaces Smoke Hollow 47183T-12)
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 10 11/16”
Material: matte cast iron
Weight: 3.8

==> All Smoke Hollow Cooking Grids.

SH5000 Heat Plates

Click for photos

Stainless steel replacement Heat Tent for Smoke Hollow model SH5000. Far better rust and corrosion resistance than the original porcelain steel version. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating, remove before use.

Part Number: 47183T-24-R (Replaces Smoke Hollow 47183T-24)
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 4”
Material: stainless steel
Weight: 0.80

==> All Smoke Hollow Heat Plates.

SH5000 Igniter Components

Click for photos

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

==> All Smoke Hollow Igniter Components.

SH5000 Grease Trays

Click for photos

47183T-21-R Stainless steel replacement charcoal tray for Smoke Hollow.

Replaces original OEM part# 47183T-21.

Part Number: 47183T-21-R (Replaces Smoke Hollow 47183T-21)
Dimensions: 15 1/4” x 12 7/8”
Material: stainless steel
Weight: 7.5

==> All Smoke Hollow Grease Trays.

SH5000 Rotisserie components

Click for photos

Heavy duty stainless steel 6 1/4” x 4” x 2 1/8” cased universal rotisserie motor. On-off switch and 3 foot cord. Maximum 25 lb. balanced load. (120V, 9W, 50/60 HZ, RPM: 2.5/2.8)

Part Number: RO-6
Material: Stainless steel case
Weight: 2.0

==> All Smoke Hollow Rotisserie components.

SH5000 Heat indicators and Meat Thermometers

Click for photos

Round heat indicator.

Single probe
3” diameter
Requires 3/8” mounting hole

Part Number: 00016 (Replaces Smoke Hollow TR041)
Dimensions: 3” x 3”
Weight: 0.2

==> All Smoke Hollow Heat indicators and Meat Thermometers.

SH5000 Accessories

Click for photos

Apple wood chips.

All natural wood smoke flavor
Great for use in BBQ's or smokers.
170 cubic inches (2 lbs. approx) in resealable bag

Try with portk, lamb, poultry, and fish.

Part Number: 00230
Weight: 2.0

Click for photos

20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.

Part Number: 40269
Material: stainless steel
Weight: 0.14

Click for photos

Universal 6 piece chrome plated skewer set. Designed so food does not rotate. Great for kabobs! 19 1/2” long.

Part Number: SR-7B
Dimensions: 19 1/2
Material: chrome steel
Weight: 1.0

Click for photos

Marinade Injector.

For injecting flavor and marinades into meat. Great for use with chicken, beef, pork, lamb etc. Disassembles for cleaning. Stainless steel injector tip. Graduated injection chamber. Easy to use and clean.

Part Number: 14950
Material: stailess steel
Weight: 0.5

Click for photos

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

==> All SH5000 Accessories.
