PGS K40 Grill Parts

Stainless steel twin H burner and venturi assembly for PGS model K40. Includes:

• One (1) twin SS H burner.
• Two (2) SS twist lock venturi.
• Built-in spider guards.
• Sold as assembly only, burner and venturi not available seperately.

Part Number: GG-DLB13TL
Dimensions: 19 1/2” x 8”
Weight: 3.0

Stainless steel twin H burner and venturi assembly for PGS model K40.Fits WNK and TJK grills. Includes:

• One (1) GG-DLB SS twin H burner.
• One (1) GG-DV-13 bolt-on twin venturi.
• All necessary gaskets and hardware.

Part Number: GG-DLB13
Dimensions: 8 1/4” x 20”
Material: stainless steel
Weight: 3.0

Large stainless steel twin H burner for PGS model K40.

NOTE: This burner uses bolt-in venturis, such as part GG-DV13. It does not accept twist-in type venturis.

See part GG-DLB13 for both the burner and venturi in a kit.

Part Number: GG-DLB
Dimensions: 19 1/2” x 8”
Weight: 3.0

SS twin venturi. For use with GG-DLB and HH-DSB H burners. Includes gaskets and hardware, and spider guards. Fits JNR, WNK, and TJK grills.

Part Number: GG-DV13
Material: stainless steel
Weight: 1.0

Stainless steel Sear Grid set for PGS model K40. Replaces Ducane OEM part 20172302.

The stainless steel SEAR GRID is a 2-piece die formed part with domed runners. Each runner traps and collects the heat of the briquettes thus making your grill 30% more effective than other cooking grids. The trapped heat within each runner produces wide sear marks on the meat, thus sealing in the meat’s juices.

The SEAR GRID is made of a high quality stainless steel. Due to the heat of cooking, a discoloration of the SEAR GRID is normal and will not affect the SEAR GRID in any manner.


Part Number: 534S2
Dimension Front-to-Back: 16 1/4”
Dimension Side-to-Side: 24 1/4”
Material: stamped stainless steel
Weight: 4.15

Channel Design Stainless Steel Cooking Grid for MHP Grill Models for PGS model K40. Sold individually, requires two pieces.

Part Number: GG-SSGRIDAMC
Dimension Front-to-Back: 15 3/4”
Dimension Side-to-Side: 12”
Material: stainless steel
Weight: 2.40

Heavy-duty stainless steel cooking grid for GJK, WNK, and TJK series grills for PGS model K40.

• High grade stainless
• 5/16” solid stainless rods
• Sold individually.

Part Number: GG-SS-GRID
Dimension Front-to-Back: 15 3/4”
Dimension Side-to-Side: 12”
Material: stainless steel
Weight: 6.0

Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-28
Dimension Front-to-Back: 13 5/8”
Dimension Side-to-Side: 22 1/4”
Material: carbon steel
Weight: 4.5

Battery powered push button spark generator with single round connector. Also for some side burner applications.

• Installs behind the control panel, replacing a piezo plunger.
• Fits most grills that use a push-button piezo plunger.
• Uses a single AA battery (not included).
• Requires 3/4” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03300
Dimensions: 2 7/8” x 2 1/16”
Weight: 0.3

20” Ignitor adapter wire with female spade connector and male round connector. Used primarily on Ducane models 7100 and 7200 to extend the wire from the 03758 collector box and electrode to the electronic spark generator (igniter).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03750
Dimensions: 1/16
Weight: 0.05

Universal adapter wire with male round and female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03751
Weight: 0.05

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

Tongue style collector box for burner mounted applications. Includes preinstalled electrode with round female connector end and 20” wire. Fits on all of our Deluxe stainless H burners (LB, SB, DLB, DSB) using special mounting bracket on these burners. Will not fit on cast iron burners (see part IG-15B for cast iron burner applications).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-5B
Weight: 0.3

21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-7B
Weight: 0.02

20” igniter wire with two (2) female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-18B
Weight: 0.03

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Ignitor collector box and electrode for thru casting mounts. Preassembled. Includes:

• Collector box and ceramic electrode with male spade connector
• Locking nuts and washer
• Ground lug (not shown)

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-4B
Weight: 0.3

Collector box and ceramic electrode with male spade connector. Mounts perpendicular through casting with threaded rod and locking nuts. Includes igniter ground lug, but no ground wire, see ground wire 03620.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03800
Material: ceramic
Weight: 0.2

Universal collector box with electrode and wire. Fits most H burners, cast iron and stainless. Mounts to burner using venturi screws. Slotted construction allow universal adjustment of electrode position.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-15B
Weight: 0.3

Battery powered push button igniter.

• Has two (2) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB2-B
Weight: 0.3

Main control knob for JNR, WNK, TJK.

• Off position D-Value: 6 o'clock
• Knob diameter: 1 7/8”
• Socket diameter: 5/16”
• Knob shaft: 1/4”

Part Number: GG-K10
Weight: 0.2

High quality, long lasting ceramic briquettes. 59 flat top pyramid-shaped briquettes per box. Placed 1/2” apart, 59 briquetes will cover about 368 square inches. This is an area roughly 15” x 24”.

• Top quality product
• Each briquette measure 2” x 2”
• Self cleaning
• Great heat distibution, retains heat longer
• Can be used on all grills that use briquettes or lava rock
• Use a single layer (multiple layers can reduce temperatures)

NOTE: These high quality ceramic briquetes are available in 59 count, 70 count, and 90 count qantities.

• 59 briquetes covers an area apprimately 15” x 24”
• 70 briquetes covers an area apprimately 17” x 26”
• 90 briquetes covers an area apprimately 17” x 33”

Part Number: CLA-AC0394
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.65

BBQ'er choice porcelain grill briquets. The finest available.

• Self-Cleaning Porcelain Briquettes.
• Made of fired porcelain for even heat transfer.
• Virtually indestructible.
• About 56 pieces covers approximately 310 square inches.
• Made in USA.

NOTE: MHP model TJK requires two (2) bags.

Part Number: BQ-3A
Weight: 4.2

Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Extra long stainless steel fork with ergonomically correct handles. 20 1/2” long.

Part Number: ITF-2
Dimensions: 20 1/2
Material: stainless steel
Weight: 0.3

Universal 6 piece chrome plated skewer set. Designed so food does not rotate. Great for kabobs! 19 1/2” long.

Part Number: SR-7B
Dimensions: 19 1/2
Material: chrome steel
Weight: 1.0

Stainless Steel Basting Set.

Measurements inside the stainless steel bowl for accurate sauce preparation. Includes silicone basting brush.

Part Number: 14913
Material: stailess steel
Weight: 0.5

Aluminum foil grilling trays. Package of three.

• Heavy duty aluminum foil
• Re-usable
• Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4
