Member's Mark B09SMG1-3F Grill Parts

Member's Mark logo



Member's Mark B09SMG1-3F

Members Mark Modular Model B09SMG1-3F LP Gas Grill



Highest quality replacement parts for your Member's Mark B09SMG1-3F - Free USA shipping $49 or more* - No Sales Tax*



Member's Mark B09SMG1-3F owners manual and diagrams
Click the small images on the right to view Member's Mark B09SMG1-3F exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Members Mark B09SMG1-3F-369000E885D839-PartsExpS1.gif  Members Mark B09SMG1-3F-369000E885D839-PartsLstS1.gif

Replacement BBQ grill parts for Member's Mark model: B09SMG1-3F
On this page you'll find all of the parts that fit model Member's Mark B09SMG1-3F. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Member's Mark grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Member's Mark B09SMG1-3F BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Member's Mark model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



B09SMG1-3F Burners

SCTB1
Click for photos
Stainless steel burner for Member's Mark model B09SMG1-3F.

Part Number: SCTB1
Dimensions: 15 3/8
Material: stainless steel
Weight: 0.43

$39.38

Qty


SCTB2
Click for photos
Stainless steel burner for Member's Mark model B09SMG1-3F.

Part Number: SCTB2
Dimensions: 15 1/2” x 4 3/4”
Material: stainless steel
Weight: 1.0

$31.83

Qty


16231-X3
Click for photos

Stainless steel tube burners for Member's Mark model B09SMG1-3F. SET OF THREE (3).

Includes:
  • SS tube burner
  • Electrode mounting bracket
  • Spider exclusion screen
  • Adjustable air shutter.


Part Number: 16231-X3
Dimensions: 15 3/8” x 1”
Material: stainless steel
Weight: 0.15

$90.70

Qty


==> All Member's Mark Burners.






B09SMG1-3F Cooking Grids

CG-70P-CI
Click for photos
Cast iron cooking grid for Member's Mark model B09SMG1-3F. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-70P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 11 1/2”
Material: cast iron
Weight: 8.2

$64.00

Qty


CG-72P-CI
Click for photos
Cast iron cooking grid for Member's Mark model B09SMG1-3F. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-72P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 9 1/2”
Material: cast iron
Weight: 6.45

$51.52

Qty


5S463
Click for photos
Stainless steel cooking grids (set of 3) for Member's Mark model B09SMG1-3F.

Part Number: 5S463
Dimension Front-to-Back: 18 5/8”
Dimension Side-to-Side: 30 3/4”
Material: stainless steel tubes
Weight: 9.0

$123.84

Qty


==> All Member's Mark Cooking Grids.






B09SMG1-3F Heat Plates

SCHP3
Click for photos
Stainless steel heat plate for Member's Mark model B09SMG1-3F.

Part Number: SCHP3
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 4 5/8”
Material: stainless steel
Weight: 1.0

$42.48

Qty


SCHP2
Click for photos
Stainless steel heat plate for Member's Mark model B09SMG1-3F.

Part Number: SCHP2
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 8 1/8”
Material: stainless steel
Weight: 1.3

$38.46

Qty


CLA-TS0151-X3
Click for photos
SET OF THREE/3 PACK Stainless steel heat diffuser for Member's Mark model B09SMG1-3F. On some grill models it is also known as a Flame Tamer. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0151-X3
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 8 1/16”
Material: stainless steel
Weight: 4.05

$97.97

Qty


96421-X3
Click for photos
Stainless steel heat diffusers for Member's Mark model B09SMG1-3F. SET OF THREE (3). On some grill models it is also known as a Flame Tamer.

Part Number: 96421-X3
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 4 5/8”
Material: stainless steel
Weight: 2.55

$84.87

Qty


==> All Member's Mark Heat Plates.






B09SMG1-3F Igniter Components

IGEIB6-B
Click for photos
Battery powered push button igniter.
  • Has six (6) spade type male connectors.
  • Uses 1 AA battery (not supplied)
  • Requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IGEIB6-B
Weight: 0.3

$31.52

Qty


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.10

Qty


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.00

Qty


IG-31B
Click for photos
Electrode to Fit Many Import Grills Including some Kenmore, BBQ Pro, Sam's Club, K-Mart, Etc….

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-31B
Weight: .05

$7.10

Qty


03610-X4
Click for photos
Ignition connection wires used to connect battery powered spark generators to electrodes. SET OF FOUR (4) 47” wires.

  • Each wire has female spade connectors on one end and square plastic connectors on the other
  • Square plastice connector attaches to spark generator
  • Female spade connector ataches to electrode

NOTE: For more information on grill ignition systems, including how to connect electrodes to spark generators/ignitors, see article Ignition 101 in our help center.



Part Number: 03610-X4
Weight: 0.2

$32.32

Qty


04022-X3
Click for photos

Burner mounted electrodes with male spade connectors. SET OF THREE (3). Includes small mounting bolts and nuts.

  • Wire not included. Commonly used with wire part# 03610.
  • Female spade connector on wire connects to male spade connector of electrode.
  • If used with existing wire, confirm connecting end of wire is a female spade connector
  • Usually, one electrode required per burner

NOTE: Electrodes provide the spark that ignites the gas when the ignitor button is depressed, or the knob is turned. They're the spark plug of the grill. ==> For more information on grill ignition systems, including how to connect electrodes to spark generators/ignitors, see article Ignition 101 in our help center.



Part Number: 04022-X3
Material: ceramic
Weight: 0.3

$19.69

Qty


==> All Member's Mark Igniter Components.






B09SMG1-3F Heat indicators and Meat Thermometers

22551
Click for photos
Oval lid heat indicator. Three-hole mount with two threaded studs 1 1/2” offset on center. Requires 3/8” center hole for temperature sensor probe.

Part Number: 22551
Dimensions: 2 15/16” x 1 7/8”
Weight: 0.2

$14.41

Qty


==> All Member's Mark Heat indicators and Meat Thermometers.






B09SMG1-3F Accessories

00150
Click for photos
Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

$25.42

Qty


40240
Click for photos
16” Stainless Steel Tong/Turner Combination. 16” multi-use tool with red soft grip rubber inserts. Can be used as a turner, tong or both. Manual lock saves on storage space.

Part Number: 40240
Material: chrome steel
Weight: 0.9

$16.60

Qty


BB-5
Click for photos
Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

$8.84

Qty


RR-2
Click for photos
Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0

$13.30
SALE  $7.73
Qty


WB-8RH
Click for photos
Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2

$9.45

Qty


==> All B09SMG1-3F Accessories.
