Kenmore 119.16126010 Grill Parts

stainless steel straight pipe burner for Kenmore model 119.16126010.

Part Number: 11621 (Replaces Kenmore SD0050-A)
Dimensions: 12 1/4” x 1”
Material: stainless steel
Weight: 0.7

Cooking grid not known for Kenmore model 119.16126010. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Kenmore cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0

Heat Plate for Kenmore Grills for Kenmore model 119.16126010.

Part Number: KENHP6 (Replaces Kenmore S1007-012E-015)
Dimension Front-to-Back: 11 7/8”
Dimension Side-to-Side: 4 1/8”
Material: stainless steel
Weight: 1.0

SET OF THREE/3 PACK Stainless steel heat diffuser for Kenmore model 119.16126010.

Replaces OEM part# S1007-012E-015
• Stainless steel
• Made in USA

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0213-X3
Dimension Front-to-Back: 11 13/16”
Dimension Side-to-Side: 4 1/4”
Material: stainless steel
Weight: 1.8

Stainless steel heat diffuser for Kenmore model 119.16126010.

Replaces OEM part# S1007-012E-015
• Stainless steel
• Made in USA

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0213
Dimension Front-to-Back: 11 13/16”
Dimension Side-to-Side: 4 1/4”
Material: stainless steel
Weight: 0.60

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010 (Replaces Kenmore SE9012)
Weight: 0.2

Electrode to Fit Many Import Grills Including some Kenmore, BBQ Pro, Sam's Club, K-Mart, Etc….

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-31B (Replaces Kenmore SE9009)
Weight: .05

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B (Replaces Kenmore SE0131B)
Weight: 0.3

Universal three-outlet battery powered push button ignitor.

• 1.5 volt
• Has three (3) terminals (male spade connector)
• Uses a single AA battery (not included)
• 03610 and 03620 wires are commonly used with this igniter (not included)
• Requires 7/8” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03333 (Replaces Kenmore ASMB0084-04)
Dimensions: 2 9/16” x 2”
Weight: 0.5

Push-button electronic igniter with three (3) spade connectors. Comes with sliver or black cap per availability. Needs (1) AA battery (not included); requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG3007
Weight: 0.2

Control knob
* Fits many Home Depot/Charmglow models
* Unique two tone design
* May require a 5/64” Allen wrench to remove the old knob and to install the new knob.

• Off position D-Value: 12:00 o'clock
• Knob diameter: 2 5/16”
• Socket diameter: 5 /16”
• Knob shaft: none (flat)

Part Number: K-14B (Replaces Kenmore PLABS0090-001)
Dimensions: 2 1/4
Weight: 0.1

Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.

• Requires minimum 3/8” mounting hole
• Single 1 3/8” probe
• Threaded portion of probe stops at 1/2” from base
• See photo for details

Part Number: 00012 (Replaces Kenmore SE9001)
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

Stainless steel straight handle grill brush with replaceable head. Brass bristles and scarper. See part# WB-8RH for replacement grill brush heads. 18 1/2” long.
This part is currently out of stock, but more are already on the way and expected to arrive SPRING 23

Part Number: WB-8
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.8
