Orifice for infrared burners with starter hole #63 if you need to drill the hole. Includes brass elbow with 1/4” compression fitting.

NOTE: If you need the orifice pre-drilled for Natural Gas or LP Gas, during check-out, in the message box, please state that you need the orifice drilled for Natural Gas #55 or for LP Gas #59.

Part Number: CLA-VB0245
Dimensions: 3 3/8” x 17 1/4”
Material: stainless steel and ceramic
Weight: 0.3

CLA-VB0245 fits these 2 Frontgate models:
FG48E-BQRCL	FG48E-BQRCN

Brass valve for DCS.

• For LP and natural gas grills (see below)
• Off position D-Value: 12 o'clock
• Stem diameter: 8mm
• Orifice not included

NOTE: There is a set screw in the stem that allows this valve to be used in both LP or natural gas grills. The valve is shipped with the screw set in LP position. Turn the screw counterclockwise about seven turns for natural gas use.

Part Number: 30171
Dimensions: 3 7/16” x 1 5/16”
Material: brass
Weight: 0.3

30171 fits these 4 Frontgate models:
FG48D-BQARL	FG48D-BQARN	FG48E-BQRCL	FG48E-BQRCN
