Charbroil 466440509 Grill Parts

Charbroil logo



Charbroil 466440509

Char-Broil LP gas outdoor BBQ grill with side burner



Highest quality replacement parts for your Charbroil 466440509 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 466440509 owners manual and diagrams
Click the small images on the right to view Charbroil 466440509 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Charbroil 466440509-463366949030-PartsExpS1.jpg

Replacement grill parts for Charbroil model: 466440509
This page shows all of the parts we know fit model Charbroil 466440509. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 466440509 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



466440509 Burners

80009947 / CBP6
Click for photos
Stainless steel burner for Charbroil model 466440509.

Part Number: CBP6 (Replaces Charbroil 80009947)
Dimensions: 14 3/8” x 1”
Material: stainless steel
Weight: 1.0

$38.24

Qty


==> All Charbroil Burners.






466440509 Burner Brackets and Carryovers

80009028 / CBCO1
Click for photos
Stainless steel cross over tube. Channels gas between burners.

Part Number: CBCO1 (Replaces Charbroil 80009028)
Dimensions: 7
Material: stainless steel
Weight: 0.05

$15.90

Qty


==> All Charbroil Burner Brackets and Carryovers.






466440509 Cooking Grids

80018559 / 50193
Click for photos
Channel formed U-shaped porcelain steel cooking grids for Charbroil model 466440509. Channel formed means rolled steel stamped into a U-shape; is not solid round rods. Porcelain enameled, glossy finish. Sold as a set of three (3).

Part Number: 50193 (Replaces Charbroil 80018559)
Dimension Front-to-Back: 16 13/16”
Dimension Side-to-Side: 28 5/16”
Material: porcelain steel channels
Weight: 6.7

$85.75

Qty


==> All Charbroil Cooking Grids.






466440509 Heat Plates

80008530 / CBHP6
Click for photos
Stainless steel vented heat plate/Flame Tamer for Charbroil model 466440509.

Part Number: CBHP6 (Replaces Charbroil 80008530)
Dimension Front-to-Back: 14 5/8”
Dimension Side-to-Side: 4 1/4”
Material: stainless steel
Weight: 0.7

$23.47

Qty


==> All Charbroil Heat Plates.






466440509 Igniter Components

TS-IG4010
Click for photos
Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: TS-IG4010
Weight: 0.2

$18.48

Qty


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.51

Qty


80009029 / 04430
Click for photos
Burner mounted electrode for use with 15591 and 15491 burners.
  • 39” wire with female spade connector
  • Includes adapter wire part 03198 for applications needing male spade connector on electrode.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 04430 (Replaces Charbroil 80009029)
Material: ceramic
Weight: 0.1

$12.47

Qty


80019100 / IGEIB4-B
Click for photos
Battery powered push button igniter.
  • Has four (4) spade type male connectors.
  • Uses 1 AAA battery (not supplied)
  • Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IGEIB4-B (Replaces Charbroil 80019100)
Weight: 0.3

$34.08

Qty


IG-19B
Click for photos
Burner-mounted ceramic electrode, wire, and mounting bracket.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-19B
Weight: 0.1

$12.93

Qty


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.35

Qty


==> All Charbroil Igniter Components.






466440509 Heat indicators and Meat Thermometers

4157171 / 00018
Click for photos
Round heat indicator.
  • Single probe
  • 1 13/16” diameter
  • Requires 3/8” mounting hole


Part Number: 00018 (Replaces Charbroil 4157171)
Dimensions: 1 13/16” x 1 13/16”
Weight: 0.1

$15.82

Qty


11381
Click for photos
Universal four piece mini thermometer set. Great gift idea.
  • 2 calibrated for steak, and 2 for chicken
  • Mini thermometers for testing doneness of individual cuts of meat
  • Silicone bezels for easy removal when hot
  • Always use caution when handling hot objects


Part Number: 11381
Weight: .25

$16.45

Qty


==> All Charbroil Heat indicators and Meat Thermometers.






466440509 Accessories

00281
Click for photos
Cedar grilling planks adds a delicious wood-smoke flavor to foods grilled on them. Great for salmon! 11 7/8” x 5 1/4” x 5/16” 100% natural cedar. Two planks per pack.

Part Number: 00281
Dimensions: 11 7/8
Weight: .45

$8.61

Qty


40269
Click for photos
20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.


Part Number: 40269
Material: stainless steel
Weight: 0.14

SALE  $14.99
Qty


40538
Click for photos
Set of six 22” stainless steel V skewers with wood handles and silicone bezels. Silicone bezel helps the handle stay cool longer. V-shaped skewers keep food from spinning on shaft.

Part Number: 40538
Material: chrome steel
Weight: 1.1

$15.59

Qty


JPT
Click for photos

Stainless steel jalapeno pepper tray.Cook all the heat from a jalapeρo and you’re left with a fabulous taste of the southwest that leaves your taste buds singing for hours.

  • Constructed of 304 stainless steel
  • Measures 9-1/2” x 6-1/2”
  • Holds up-to 24 jalapeρo peppers
  • American-Made


Part Number: JPT
Dimensions: 14 1/4” x 6”
Material: stainless steel
Weight: 0.6

$33.12

Qty


SDDPS
Click for photos
Stainless Steel Scraper for Phoenix and Holland Drip Trays

Part Number: SDDPS
Dimensions: 20
Weight: 0.30

$18.07

Qty


==> All 466440509 Accessories.




BBQ Part Categories

























Charbroil grill 466440509 - Tuesday, Oct 7 2025
