Charbroil Terrace 464232004 Grill Parts

Char-Broil Terrace Series 3-Burner LP gas BBQ grill

Highest quality replacement parts for your Charbroil Terrace 464232004 - Free USA shipping $49 or more* - No Sales Tax*

Charbroil 464232004 owners manual and diagrams

Diagrams & owners manual not available for grill model# 464232004. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts for Charbroil Terrace (464232004)

This page shows all of the parts we know fit model Charbroil 464232004. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 464232004 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

464232004 Burners

Click for photos

Cast iron burner for Charbroil model 464232004.

Part Number: CIDCH
Dimensions: 13 13/16” x 2 1/4”
Material: cast iron
Weight: 3.0

==> All Charbroil Burners.

464232004 Cooking Grids

Click for photos

Heavy duty stainless steel cooking grid for Charbroil model 464232004.

304 commercial grade stainless
Solid 5/16” stainless rods
Sold individually
Made in USA.

Part Number: CLA52932S
Dimension Front-to-Back: 16 5/8”
Dimension Side-to-Side: 12 1/4”
Material: solid 304 stainless steel rod
Weight: 6.4

Click for photos

Cast iron cooking grid for Charbroil model 464232004. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-63P-CI (Replaces Charbroil 80000293)
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 11 3/4”
Material: cast iron
Weight: 7.15

==> All Charbroil Cooking Grids.

464232004 Heat Plates

Click for photos

SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Charbroil model 464232004. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0143-X3
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 4 3/16”
Material: stainless steel
Weight: 2.4

Click for photos

Stainless steel heat plate/Flame Tamer for Charbroil model 464232004.

Part Number: CBHP4 (Replaces Charbroil 80000273)
Dimension Front-to-Back: 15 1/16”
Dimension Side-to-Side: 4 5/16”
Material: stainless steel
Weight: 0.7

==> All Charbroil Heat Plates.

464232004 Igniter Components

Click for photos

Electrode assembly. Includes electrode with wire, collector box, and mounting bolt with nut. Wire connects to spark generator with flat female spade connector, which is typically used with electronic (battery operated) ignitors (see Ignition 101 in our help center).

Part Number: 00653 (Replaces Charbroil 80000653)
Material: ceramic
Weight: 0.1

==> All Charbroil Igniter Components.

464232004 Knobs and Handles

Click for photos

Universal black control knob. Counter-clockwise bezel.

Off position D-Value: Selectable
Knob diameter: 2 1/16”
Socket diameter: 8mm
Knob shaft: None

Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

Click for photos

Black control knob for Fire Magic Custom, Regal, and Gourmet grills.

Off position D-Value: 6 o'clock
Knob diameter: 2”
Socket diameter: 8mm
Knob shaft: None

Part Number: 01700 (Replaces Charbroil 80000035)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

==> All Charbroil Knobs and Handles.

464232004 Accessories

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Click for photos

Aluminum foil grilling trays. Package of three.

Heavy duty aluminum foil
Re-usable
Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

==> All 464232004 Accessories.
