Charbroil 463811905 Grill Parts

Porcelain steel cooking grid for Charbroil model 463811905. Porcelain enameled, glossy finish. Sold individually.

Part Number: 55801
Dimension Front-to-Back: 14 23/32”
Dimension Side-to-Side: 26 5/8”
Material: porcelain steel wire
Weight: 6.2

Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-39
Dimension Front-to-Back: 11”
Dimension Side-to-Side: 25”
Material: carbon steel
Weight: 4.0

Stainless steel Flame Tamers for Charbroil model 463811905. Sold individually, number required varies. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0035 (Replaces Charbroil 4500291)
Dimension Front-to-Back: 25 7/8”
Dimension Side-to-Side: 5 1/2”
Material: stainless steel
Weight: 1.4

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Universal push-button igniter. Round male connector. Includes locking nut.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: UP-4B (Replaces Charbroil 4506709)
Weight: 0.3

Universal 2 3/4” adaptor wire with a round female end and a male spade end that has a protective cover.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03199C
Weight: 0.05

Collector Box and electrode for Charbroil top ported TBBC & TLBBC burners.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-28B
Weight: 0.2

Black control knob.

• Off position D-Value: 9 o'clock
• Knob diameter: 1 3/4”
• Socket diameter: 8mm
• Knob shaft: None

Part Number: 04470 (Replaces Charbroil 4154470)
Dimensions: 1 7/8” x 1 7/8”
Material: plastic
Weight: 0.1

Chrome steel bottom warming rack for Charbroil 8000 series U-burner grills. Was used with top rack 06449 that is no longer available.
Warning:No longer made to work with upper warming rack. Does not have eyelet holes on right and left sides of warming rack to support the upper warming rack.

Part Number: 02125 (Replaces Charbroil 4152125)
Dimensions: 26 1/4” x 10 1/2”
Material: chrome steel wire
Weight: 1.14

BBQ'er choice porcelain grill briquets. The finest available.

• Self-Cleaning Porcelain Briquettes.
• Made of fired porcelain for even heat transfer.
• Virtually indestructible.
• About 56 pieces covers approximately 310 square inches.
• Made in USA.

NOTE: MHP model TJK requires two (2) bags.

Part Number: BQ-3A
Weight: 4.2

Durable 2 5/16” round briquettes

• Self-cleaning
• Control flare-ups while holding an even heat pattern.
• About 53 pieces, covers approximately 275 sq. inches.
• Fits all gas grills

Part Number: BQ-5
Weight: 7.2

Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

Wundersmoke Mesquite Chips. These unique mesquite wood smoking chips add distinctive flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-5
Weight: 1.0

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
