Charbroil Signature 463372017 Grill Parts

stainless steel burner for Charbroil model 463372017.

Part Number: 10081
Dimensions: 17 3/4” x 0 5/8”
Material: stainless steel
Weight: 0.4

stainless steel cross-over burner
This part is currently out of stock, but more are already on the way and expected to arrive May

Part Number: 05595
Dimensions: 7 7/16” x 0 3/4”
Material: stainless steel
Weight: 0.1

matte finish cast iron cooking grid for Charbroil model 463372017.

Part Number: 60063
Dimension Front-to-Back: 18 3/16”
Dimension Side-to-Side: 22 1/4”
Material: matte cast iron
Weight: 13.4

stainless steel Heat Tent for Charbroil model 463372017.

Part Number: 90061
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 2 1/16”
Material: stainless steel
Weight: 0.6

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.

• 1.5 volt
• Has four(4) spark outlets (male spade connector)
• Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03344
Dimensions: 2” x 2 1/2”
Weight: 0.5

Ignition electrode.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04450
Dimensions: 3 5/16” x 0 7/8”
Weight: 0.1

Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.

• Requires minimum 3/8” mounting hole
• Single 1 3/8” probe
• Threaded portion of probe stops at 1/2” from base
• See photo for details

Part Number: 00012
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
