Charbroil Gas2Coal 463370516 Grill Parts

Stainless Steel tube burner for Charbroil model 463370516.

Part Number: CBP11
Dimensions: 14 7/16” x 1”
Material: stainless steel
Weight: .40

Burner crossover tube.

Part Number: 05590
Dimensions: 7 1/4” x 0 3/4”
Material: stainless steel
Weight: 0.1

Cast iron cooking grid for Charbroil model 463370516. Porcelain treated, matte finish. Sold individually, number required varies.

Part Number: 66124-1PC
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 8 5/16”
Material: cast iron
Weight: 3.75

Cast iron cooking grid for Charbroil model 463370516. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.

Part Number: CG-74P-CI
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 8 1/4”
Material: cast iron
Weight: 8.90

cast iron cooking grid, SOLD INDIVIDUALLY for Charbroil model 463370516.

• Sold individually.
• Number required varies.
• Porcelain enameled cast iron, flat matte finish.

Part Number: 10225-T536
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 8 1/4”
Material: Cast iron
Weight: 7.6

Cast iron cooking grids for Charbroil model 463370516. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8” x 8 1/4”
• Overall dimensions: 16 7/8 x 23 3/4”

Part Number: CG-74P-CI-X3
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 24 3/4”
Material: cast iron
Weight: 26.7

Stainless steel Heat Tent for Charbroil model 463370516.

Part Number: 94021
Dimension Front-to-Back: 14 1/2”
Dimension Side-to-Side: 3 1/2”
Material: stainless steel
Weight: 0.6

Electrode, gas collector box, and wire. The connecting wire has a flat female spade connector, which is typically used with electronic (battery operated) ignitors (see Ignition 101 in our help center).

NOTE: This electrode is also sometimes used with push-button or rotary piezo ignitors, such as our part# 03100 and 03120, which have round connectors. When connecting 01472 electrode to ignitors with round connectors, use short wire part# 03199C to convert the electrode wire from a femal spade connector to a female round connector.

Part Number: 01472
Material: ceramic
Weight: 0.1

Small AA battery powered push button spark generator.

• 1.5 volt
• Has two (2) terminals (male spade connector)
• Uses a single AA battery (not included)
• 03610 and 03620 wires are commonly used with this igniter (not included)
• Requires 7/8” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03342
Weight: 0.3

Universal 2 1/2” adaptor wire with a round female end and a male spade end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.

• Requires minimum 3/8” mounting hole
• Single 1 3/8” probe
• Threaded portion of probe stops at 1/2” from base
• See photo for details

Part Number: 00012
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

HOW TO GRILL The Complete Illustrated Book of Barbecue Techniques. Steve Raichlen presents a full-color, step-by-step technique book that gets to the core of the grilling experience by showing and telling exactly how it's done. With more than 1,000 photographs, if features over 100 techniques and recipes, from how to set up a three-zone fire to how to grill a perfect prime rib, to grilling pizza, shellfish, vegetables, tofu, fruit, and s'mores.

Part Number: 0-7611-2014-9
Dimensions: 8” x 9 1/4”
Material: Paperback
Weight: 3.0

Polished stainless steel turner with an ergonomic soft grip grey handle and red accents.

Part Number: 43108
Dimensions: 16
Material: stainless steel
Weight: 0.10

Bamboo Appetizer 7” Skewers - pack of eight. Limited to supplies on hand.


Part Number: 11040
Dimensions: 7
Weight: 0.4

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Porcelain Coated Round Topper.
11” diameter x 2.5” deep porcelain coated wok with stainless steel handles and perforations. Rolled edge for rigidity and safety.

Part Number: 98130
Material: porcelain steel
Weight: 1.0

Extra Wide Nylon Grill Brush

Brush anywhere on the grill, deep into the corners, between the grids, and in broad strokes along the surface. The triangular shaped head of this brush is ideal for cleaning anywhere. 17 in. overall length with a 6. in. wide head. Nylon bristles, wire shaft and resin handle.

*For use on a cool grill.

Part Number: 77643
Weight: 0.5
