Charbroil 463270310 Grill Parts

Stainless steel burner for Charbroil model 463270310.

Part Number: CBP5 (Replaces Charbroil G515-2200-W1)
Dimensions: 15 7/8” x 1”
Material: stainless steel
Weight: 1.0

Stainless steel cross over tube. Channels gas between burners.

Part Number: CBCO2 (Replaces Charbroil G515-0015-W1)
Dimensions: 6 7/16
Material: stainless steel
Weight: 0.08

Reversible, heavy cast iron cooking grids for Charbroil model 463270310. Porcelain treated, flat matte finish. SOLD INDIVIDUALLY

Part Number: 66652-1PC
Dimension Front-to-Back: 18 1/4”
Dimension Side-to-Side: 13 1/8”
Material: matte cast iron
Weight: 10.0

Cast iron cooking grid for Charbroil model 463270310. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-65P-CI
Dimension Front-to-Back: 18 1/4”
Dimension Side-to-Side: 13 1/8”
Material: cast iron
Weight: 9.4

Cast iron cooking grids for Charbroil model 463270310. SET OF TWO (2) panels.

• Porcelain treated, matte finish
• Each panel measures 18 1/4” x 13 1/8”
• Overall dimensions: 18 1/4” x 26 1/4”

Part Number: CG-65P-CI-X2 (Replaces Charbroil G515-0059-W1)
Dimension Front-to-Back: 18 1/4”
Dimension Side-to-Side: 26 1/4”
Material: cast iron
Weight: 18.8

SET OF FOUR/4 PACK Flame Tamer, stainless steel for Charbroil model 463270310. Made in USA.

NOTE: Sometimes shipped with protective vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0141-X4
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 3.92

Stainless steel heat plate/Flame Tamer for Charbroil model 463270310.

Part Number: CBHP2 (Replaces Charbroil G501-0008-W1)
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 0.7

Universal 2 3/4” adaptor wire with a round female end and a male spade end that has a protective cover.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03199C
Weight: 0.05

Electrode, gas collector box, and wire. The connecting wire has a flat female spade connector, which is typically used with electronic (battery operated) ignitors (see Ignition 101 in our help center).

NOTE: This electrode is also sometimes used with push-button or rotary piezo ignitors, such as our part# 03100 and 03120, which have round connectors. When connecting 01472 electrode to ignitors with round connectors, use short wire part# 03199C to convert the electrode wire from a femal spade connector to a female round connector.

Part Number: 01472 (Replaces Charbroil G515-0014-W1)
Material: ceramic
Weight: 0.1

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152 (Replaces Charbroil G515-0017-W1A)
Dimensions: 17 3/4” x 1”
Weight: 0.1

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger switch.

Note: Some original ignitors (spark generators) that 03352 replaces had an integrated/built-in ground wire which is not present on this part (03352). If the ignitor you are replacing has an integrated/built-in ground wire, you will also need our ground wire part 03621. Inspect your system.

• 1.5 volt
• Has five (5) spark outlets (male spade connector)
• Has two (2) male spade connectors for the button/trigger switch part 03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 2 5/8”

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/trigger switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03352 (Replaces Charbroil G515-0030-W2)
Dimensions: 3 3/8” x 2”
Weight: 0.7

Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.

• Requires minimum 3/8” mounting hole
• Single 1 3/8” probe
• Threaded portion of probe stops at 1/2” from base
• See photo for details

Part Number: 00012 (Replaces Charbroil G515-0031-W1)
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
